- Page 1 MONITOR WITH DVD RECEIVER KW-V950BW MONITOR WITH RECEIVER KW-M855BW INSTRUCTION MANUAL • Updated information (the latest Instruction Manual, system updates, new functions, etc.) is available from <http://www.jvc.net/cs/car/>. © 2019 JVC KENWOOD Corporation B5A-2892-00 (K)
-
Page 2: Table Of Contents
Contents Before Use APPS Precautions ..............4 Apple CarPlay Operation ........25 How to read this manual ......... 5 Android Auto™ Operation ........28 Wireless Mirroring Operation .......30 Basic Operations Spotify Operation .............31 Pandora® Operation ..........32 Functions of the Buttons on the Front Panel ... 6 Turning on the Unit ........... - Page 3 SiriusXM® Controlling Audio SiriusXM® Basic Operation ........44 3-way speaker system setup ........79 Storing Channels in Preset Memory ....46 Speaker / X’over setup ..........80 Preset select ...............46 Controlling General Audio ........82 Direct search ..............46 Equalizer Control ............82 Category/Channel search ........47 Volume Offset ............83 Replay ................47 Zone Control ..............84 TuneMix™...
-
Page 4: Before Use
• When you purchase optional accessories, This condensation on the lens (also called lens check with your JVC dealer to make sure that fogging) may not allow discs to play. In such a they work with your model and in your area. -
Page 5: How To Read This Manual
Simultaneously running multiple applications on your smartphone while screen sharing places heavy demand on the microprocessor of the phone, potentially affecting communication and performance. For best results while pairing with your JVC receiver, please be sure to close any unused applications. English... -
Page 6: Basic Operations
Basic Operations Basic Operations Functions of the Buttons on the Front Panel KW-V950BW KW-M855BW NOTE • The panels shown in this manual are examples used to provide a clear explanation of operations. For this reason, they may be different from the actual panels. -
Page 7: Turning On The Unit
Basic Operations Turning on the Unit Initial Settings Initial setup Press the [FNC] button. Perform this setup when you use this unit first time. Set each item as follows. h The unit is turned on. NOTE • If it is your first time to turn the unit on after installation, it will be necessary to perform Initial setup (P.7). - Page 8 [OEM SETUP] ■ cannot be deactivated. Note that the Security This function requires a commercial adaptor. Code can be set with a 4 to 8 digit number of Consult your JVC dealer for details. your choice. ■ [DEMO] Preparation Set the demonstration mode. Default is “ON”.
- Page 9 Basic Operations Calendar/clock settings Enter a security code with 4 to 8 digits and touch [Enter]. Press the [FNC] button. h Popup menu appears. Touch [ h HOME screen appears. Touch [ Enter the same code again and touch [Enter]. Now, your security code is registered.
-
Page 10: Adjusting The Volume
Basic Operations [Time Format] ● Flick ■ Select the time display format. Slide your finger quickly [12-Hour] (Default)/[24-Hour] to the left or right on the screen to change the page. ■ [Clock] You can scroll a list screen [GPS-SYNC ](Default): Synchronizes the clock by flicking up/down on the time with the GPS. -
Page 11: Popup Menu
• Displays the Screen Adjustment screen. (P.72) • Touch to eject the disc. • Touch for 2 seconds to forcibly eject the disc and then touch [Yes] after the message is displayed. KW-V950BW only • Close the popup menu. KW-M855BW only English... -
Page 12: Home Screen Descriptions
Basic Operations HOME screen descriptions Source selection screen description Most functions can be performed from the HOME screen. You can display icons of all playback sources and options on the source selection screen. To change pages, flick your finger leftward/ rightward on the screen. - Page 13 Bluetooth device or iDataLink phone, the (P.28) current call will be continued. • Displays the Hands Free screen. (P.66) KW-V950BW only When neither Apple CarPlay, Android Auto, nor a Bluetooth Hands-Free phone This can be selected when the AV-IN is set to...
- Page 14 Basic Operations Customize Short-cut source icons To select the playback source on the source control screen on HOME screen You can arrange the positions of the source icons as you like. Press the [FNC] button. h Popup menu appears. Touch [ h HOME screen appears.
-
Page 15: Source Control Screen Descriptions
Basic Operations Source control screen Artwork & information descriptions You can select whether to display an artwork and song information or only song information There are some functions which can be in more detail. performed from most screens. Touching the artwork area switches to the VU meter. -
Page 16: List Screen
Basic Operations List screen ] / [ ] / [ ] / [ ] Page scroll You can change pages to display more items by There are some common function keys in the pressing [ list screens of most sources. •... -
Page 17: Widget
Widget Widget ● To change the widget format Widget Basic Operation Slide two fingers upward/downward to switch between the big and the split widget mode. Big widget Split widget Photo Frame Widget You can display a slideshow of the image files stored in the USB memory on the HOME screen. -
Page 18: Widget Setup
Widget Widget Setup To Photo Frame Setup Touch [Photo Frame SETUP] on the Set up the widget on the HOME screen. Widget SETUP screen. Press the [FNC] button. Set each item as follows. h Popup menu appears. [Sort Order] ■ Specify a file sorting criterion. -
Page 19: Disc
Disc Disc (KW-V950BW) Playing a disc DVD/VCD Basic Operation Ñ Most functions can be controlled from the Insert a disc source control screen and playback screen. Insert the disc into the slot. NOTE • The screen shot below is for DVD. It may be different from the one for VCD. - Page 20 Disc • [Hide]: Hides the control screen. Indicator Items • [ ] : Repeats the current content. Each time • [IN]: Disc insertion status. you touch the key, repeat modes are switched White: A Disc is inside the unit. in the following sequence; Orange: Disc player failure.
-
Page 21: Music Cd/Disc Media Basic Operation
Disc Music CD/Disc media Basic • [ ] : Randomly plays all tracks in current folder/disc. Each time you touch the key, Operation random mode switches in the following sequence; Most functions can be controlled from the Track random ( ) (Music CD only), Folder source control screen and playback screen. -
Page 22: File Search Operation
Disc File search Operation Function panel (Disc media only) (Disc media only) Touch the left side of the screen to display the function panel. Touch again to close the panel. You can search for a file according to hierarchy. • [ ] : Searches for the previous/next folder. -
Page 23: Dvd Disc Menu Operation
Disc DVD Disc Menu Operation To switch among picture angles ■ Touch [Angle]. Each time you touch this key, picture angles are switched. You can set up some functions using the DVD- VIDEO disc menu. * These keys may not function depending on Touch the framed area during playback. -
Page 24: Dvd Setup
Disc DVD Setup [Screen Ratio] ■ Sets the screen display mode. [16:9 ](Default): Displays wide pictures. You can set up the DVD playback functions. [4:3 LB]: Displays wide pictures in the Letter Touch the framed area during playback. Box format (having black stripes at the top and bottom of screen). -
Page 25: Apps
APPS APPS Apple CarPlay Operation Preparation • To register an iPhone by the connection via the Apple CarPlay is a smarter, safer way to use USB (Black) terminal your iPhone in the car. Apple CarPlay takes – Connect an iPhone via the USB (Black) terminal the things you want to do with iPhone while and operate the iPhone according to the driving and displays them on the screen of... - Page 26 APPS To switch the current screen to the Apple CarPlay screen when connecting your iPhone • Touch [Apple CarPlay] icon on the source selection screen. (P.13) • Touch the following connection message if the message appears. • [ ] : Displays a Bluetooth pairing waiting NOTE dialog.
- Page 27 APPS Ñ Ñ Operation buttons and Use Siri available Apps on the home You can activate Siri. screen of Apple CarPlay Press the [FNC] button for 1 second. You can use the Apps of the connected iPhone. The items displayed and the language used on the screen differ among the connected devices.
-
Page 28: Android Auto™ Operation
APPS Ñ Android Auto™ Operation Connect Android device Wired connection Android Auto enables you to use the functions Connect an Android device via the USB of your Android device convenient for driving. terminal. (P.97) You can easily access route guidance, make calls, listen to music, and access convenient To use the hands-free function, connect the functions on the Android device while driving. - Page 29 APPS Ñ Select an Android device To exit the Android Auto screen Press the [FNC] button. If two or more Android devices have been h Popup menu appears. registered, select the Android device to be used as the Android Auto source. Touch [ Press the [FNC] button.
-
Page 30: Wireless Mirroring Operation
APPS Ñ Wireless Mirroring Operation Change the device name Press the [FNC] button. You can display the same screen of the h Popup menu appears. Android device on the monitor of the unit using the Wireless Mirroring function of the Touch [ Android device. -
Page 31: Spotify Operation
APPS Spotify Operation Operation keys • [ ] : Displays the Menu screen You can listen to Spotify on this unit by controlling the application installed in the • [ ] : New radio station that relates to the iPhone or Android. artist of the currently being played song is selected and playback starts. -
Page 32: Pandora® Operation
APPS Ñ Selecting a track Pandora® Operation Touch [ You can listen to Pandora® on this unit by h Spotify Station List screen appears. controlling the application installed in the iPhone or Bluetooth device. Select the list type, then select a desired To select the Pandora source, touch the item. - Page 33 APPS Ñ Creates a new station • [D] , [H] : Plays or pauses the content of the current station. Touch [ • [F] : Skips the current song. (Note that this function is disabled when the Touch your desired item. Pandora skip limitation is exceeded.) •...
- Page 34 APPS About Pandora® NOTE • In the application on your device, log in and create an account with Pandora. (If you are not already a registered user, an account can also be created at www.pandora. com.) • Establish an Internet connection. •...
-
Page 35: Usb
Connecting a USB device NOTE • Install the USB device in the place where it will Connect the USB device with the USB not affect safe driving. cable. (P.96) • You cannot connect a USB device via a USB hub and Multi Card Reader. - Page 36 ] / [ Artwork/VU meter [CODEC]/ [ • When a high-resolution source is played, its • Displays/hides artwork area. format information is displayed. • The jacket of the currently playing file is • [ ] : Repeats the current track/folder. Each displayed.
-
Page 37: Search Operation
Ñ Search Operation Link search You can search for a file of the same artist/ You can search music or video files by the album/genre as that in the current track. following operations. Touch [Link Search]. Touch [1]. Touch the desired tag type. You can select Touch [S]. -
Page 38: Ipod/Iphone
HOME screen appears. NOTE Touch [ • Latest compatible list of iPod/iPhone. For details, see www.jvc.net/cs/car/ipod/. Touch [iPod]. (P.13) • By connecting your iPod/iPhone to this unit with the iPod connection cable KS-U62 (optional ● To disconnect the iPod/iPhone connected... -
Page 39: Ipod/Iphone Basic Operation
iPod/iPhone iPod/iPhone Basic Operation Operation keys • 1] : Searches for a track/file. For details on Control screen search operation, see Search Operation (P.40). • E] [F] : Searches for the previous/next track/file. Touch and hold to fast forward or fast backward. -
Page 40: Search Operation
iPod/iPhone Ñ Search Operation Link search You can search for a file of the same artist/ You can search music files by the following album/genre/composer as that in the current operations. track. Touch [1]. Touch [Link Search]. Touch [S]. Touch the desired tag type. You can select from artists, albums, genres and composers. -
Page 41: Tuner
Tuner Tuner Tuner Basic Operation Seek mode Touch to switch seek mode in the following Most functions can be controlled from the sequence: [AUTO1], [AUTO2], [MANUAL]. source control screen. • [AUTO1]: Tunes in a station with good To listen to the Tuner source, touch [Tuner] reception automatically. -
Page 42: Memory Operation
Tuner Memory Operation Selecting Operation Ñ Ñ Auto memory (FM only) Preset select You can store stations with good reception in You can list and select memorized stations. the memory automatically. This function can be used from the remote control. (P.90) Touch [FM]. -
Page 43: Traffic Information
Tuner Traffic Information (FM only) Tuner Setup (FM only) You can listen to and watch traffic information You can set tuner related parameters. automatically when a traffic bulletin starts. Touch [ ] on the left side of the screen. However, this feature requires a Radio Touch [SETUP]. -
Page 44: Siriusxm
SiriusXM® SiriusXM® Control screen SiriusXM® Basic Operation Only SiriusXM® brings you more of what you love to listen to, all in one place. Get over 140 channels, including commercial-free music plus the best sports, news, talk, comedy and entertainment. Welcome to the world of satellite radio. - Page 45 SiriusXM® • Change the text size of the information smaller • [Traffic & Weather] when the “Small Audio Text” is set to “ON” in the For SXV300 * User Interface screen. (P.73) Traffic & Weather Now™ allows you to access the latest report whenever you want to hear NOTE it.
-
Page 46: Storing Channels In Preset Memory
SiriusXM® Storing Channels in Preset Direct search Memory You can tune in a channel directly. You can store the current channel in memory. Touch [ ] on the left side of the screen. Touch [Direct Channel]. Tune in the channel you wish to store in the memory. -
Page 47: Category/Channel Search
SiriusXM® Category/Channel search Replay You can specify the desired category and You can replay the last 60 minutes of the select a channel. program from the current channel. Touch [1]. Touch [L] or [Replay] on the function panel. Select a category. ■... -
Page 48: Tunemix
SiriusXM® TuneScan™ To return to live music/content Touch the left side of the screen. TuneScan™ is a feature that plays samples from the starts of multiple buffered songs Touch [Live]. from each of the SmartFavorites channels that predominantly play music selections. TuneMix™... -
Page 49: Traffic & Weather Now
SiriusXM® Traffic & Weather Now™ Content Alerts Traffic & Weather Now™ allows you to access When a broadcast program related to the the latest report whenever you want to hear registered artist, song or team starts, an Alert it. Select your city in the set up menu Select a Content List screen appears to allow you to City for Traffic &... -
Page 50: Sportsflash
SiriusXM® SportsFlash™ SiriusXM Setup SportsFlash™ will notify you when a big play Touch [ ] on the left side of the screen. happens during a game with one of your Touch [SETUP]. favorite sports teams. Choose to tune in and hear the play unfold like it was live. - Page 51 SiriusXM® Ñ Ñ Parental code Parental Control You can set a SiriusXM parental code for Parental Control is a feature that provides the Parental Control. user with the ability to prevent unauthorized access to mature content and user selected Touch [Parental Code] on the SiriusXM channels.
- Page 52 SiriusXM® Touch each channel in the list and set to NOTE ON or OFF. • Touch [All-Channels] to display all channels. • To delete the parental lock channel setting, touch [Disable All] and then touch [YES] on the confirmation screen. Touch each channel on the list and set to ON or OFF.
- Page 53 SiriusXM® Touch each content list item you want to To select a Team check or uncheck. Get alerted when your favorite sports team is playing on another SiriusXM channel with GameAlert™ Touch [My Games]. NOTE Touch the desired league in the list. •...
- Page 54 SiriusXM® Ñ SportsFlash™ setup Touch [ ] twice. Activating SportsFlash Touch [SportsFlash] on the SiriusXM SETUP screen. h SportsFlash is turned on or off. Default is “ON”. Selecting SportsFlash Beep Touch [SportsFlash Beep] on the SiriusXM SETUP screen. h SportsFlash Beep is turned on or off. ■...
- Page 55 SiriusXM® Ñ Selecting Featured Bands Touch [Done]. Update Messages You can set whether to be notified when the featured seasonal theme is updated. Touch [Featured Bands Update Messages] on the SiriusXM SETUP screen. Featured Bands Update Messages is turned on or off. NOTE Ñ...
-
Page 56: Other External Components
Other External Components Other External Components To switch the view camera View Camera Touch [ NOTE h Camera switching keys appear left/right • To connect a camera, see P.95. side. • To use a rear view camera, a REVERSE lead Select a view camera you want to switch. - Page 57 Other External Components Select the view camera to set up. [Rear Camera Interruption] ■ [ON] (Default): Displays the picture from the rear view camera when you shift the gear to the reverse (R) position. [OFF]: Select this when no camera is connected.
-
Page 58: External Audio/Video Players (Av-In)
Other External Components NOTE [None] • Touch [Initialize] and then touch [Yes] to set all Touch [Enter]. marks to their initial default position. Ñ To adjust the parking guidelines External audio/video players (AV-IN) NOTE • Install the rear view camera in the appropriate position according to the instruction manual Connect an external component to the supplied with the rear view camera. -
Page 59: Oem Features Operation
Other External Components OEM Features Operation • Displays the control screen of the Bluetooth streaming source provided for the vehicle. By connecting this unit to the bus system of the vehicle using an iDataLink (commercially • Displays information about the Radar Detector. -
Page 60: Bluetooth Control
Bluetooth Control Bluetooth Control Using the Bluetooth function allows you to use Audio player: various functions such as listening to the audio A2DP (Advanced Audio Distribution Profile) file and making/receiving a call. AVRCP (V1.6) (Audio/Video Remote Control Profile) Sound codec Information for using SBC, AAC Bluetooth®... - Page 61 Bluetooth Control Press the [FNC] button. Touch [ ] on the Select Device screen. h Popup menu appears. Touch [ h HOME screen appears. Touch [ h Bluetooth pairing waiting dialog appears. NOTE • You can also register an iPhone on the Apple CarPlay Device List screen.
-
Page 62: Bluetooth Setup
Bluetooth Control Select the function you want to use. Touch [ HFP [Hands Free1]/[Hands Free2]/[No ■ h SETUP screen appears. Connection.] Touch [Bluetooth]. Select the hands-free number to connect. A2DP/SPP [Audio/App] ■ Select if you want to use the audio player app in your smartphone over A2DP, and the other apps in your smartphone over SPP. - Page 63 Bluetooth Control Touch the device name to check. NOTE • If the icon is lighted, it means that the unit will use that device. • You cannot select an Android device connected as an Android Auto device. Set each profile as follows. [þ...
-
Page 64: Playing The Bluetooth Audio Device
• [ ] : Touch to attenuate/restore the sound. JVC Streaming DJ Bluetooth audio devices can be switched easily to play music. See JVC Streaming DJ (P.65). ] / [ • [ ] : Repeats the current track/folder. Each time you touch the key, repeat modes are... - Page 65 • Touching [ ] displays the Bluetooth device connection setup screen. (P.62) • Touching [ ] on the left of the connected device ( ) disconnects this device. • : Device used normally. • : Device used for JVC Streaming DJ. English...
-
Page 66: Using The Hands-Free Unit
Bluetooth Control Ñ File search Using the Hands-Free Unit Touch [1]. You can use the telephone function by connecting the Bluetooth telephone to this Touch the desired file or folder. unit. NOTE • While Apple CarPlay or Android Auto is connected, the Bluetooth Hands-Free function and two Bluetooth devices connections cannot be used. - Page 67 Bluetooth Control ● Select the cell-phone to use Call using the phonebook When you connect two cell-phones 1) Touch [ ] to select the phone Touch [ you want to use. Touch [ ● Bluetooth SETUP Select the initial. 1) Touch [ Bluetooth SETUP screen appears.
- Page 68 Bluetooth Control Ñ Voice Recognition Call using the preset number You can access the voice recognition function Touch [ of the cell-phone connected to this unit. You can search the cell-phone phonebook Touch the name or phone number. by voice. (The functionality depends on the cell-phone.) Press the [FNC] button for 1 second.
- Page 69 Bluetooth Control Ñ Receive a call ● Adjust the receiver volume Press the [–] or [+] button. Touch [ ] to answer a phone call or ] to reject an incoming call. ● Mute your voice Touch [ ] to mute or not to mute your voice. ●...
- Page 70 Bluetooth Control Ñ Phone number preset ■ [Delete] To delete a preset number, touch [Delete] You can register frequently used phone and then touch [OK] on the confirmation numbers in this unit. screen. Ñ Touch [ Phonebook transfer Touch [Edit]. You can transfer phonebook data from your Bluetooth smartphone using PBAP.
-
Page 71: Hands-Free Setup
Bluetooth Control Hands-Free Setup [Bluetooth HF/Audio] ■ Select the speakers to output the sound from the cell-phone (such as phone call voice and You can make various settings for the Hands- ringing tone) and Bluetooth audio player. Free function. [Front]: Outputs sound from the front Press the [FNC] button. -
Page 72: Setup
Setup Setup Monitor Screen Setup System Setup You can adjust the image quality of video, Press the [FNC] button. menu screen, etc. h Popup menu appears. Press the [FNC] button. Touch [ h Popup menu appears. Touch [Screen Adjust]. h HOME screen appears. Touch [ h Screen Adjustment screen appears. -
Page 73: User Interface Setup
Setup User Interface Setup [Parking Assist Display] ■ When an ADS adapter is connected, you can display information about obstacles around You can setup user interface parameters. the car. Press the [FNC] button. [ON]: Always displays information. h Popup menu appears. [Dyn.] (Default): Displays information when the sensor detects obstacles. - Page 74 Setup Ñ Ñ Customize Favorite key Customize popup menu functions You can jump to your favorite function easily from [Favorite] icon. You can register a function for each of the function key1 to 3. Function key1 key2 key3 NOTE • [Favorite] icon may be disabled on some screens depending on the registered function.
-
Page 75: Special Setup
Setup Ñ Adjust the date and time Special Setup manually You can setup special parameters. Touch [Clock] on the User Interface screen. Press the [FNC] button. h Popup menu appears. Select [Manual]. Touch [ Touch [Time Zone] on the User Interface screen. -
Page 76: Display Setup
Setup Ñ Software Information [OSD Clock] ■ Select if you want to display the clock while You can confirm the software version of this the screen is off, or while watching DVD unit. video and video files (USB, Disc media), etc. Touch [Software Information] in the “ON”... - Page 77 Setup To select wallpaper color To register an original image You can load an image from the connected Touch [Wallpaper Color] on the Wallpaper USB device and set it as the wallpaper image. Customize screen. Before starting this procedure, it is necessary to connect the device which has the image to Select a wallpaper color.
-
Page 78: Av Setup
Setup AV Setup • If you select USB, iPod, Tuner, Disc (Music CD/Disc media), Spotify, Pandora or Bluetooth audio as the main source, you You can set AV parameters. cannot select USB or iPod as the AV output Press the [FNC] button. source. -
Page 79: Controlling Audio
Controlling Audio Controlling Audio You can adjust various settings such as audio 3-way speaker system setup balance or subwoofer level. Select the appropriate crossover network Press the [FNC] button. mode for the speaker system used (2-way or h Popup menu appears. 3-way speaker system). -
Page 80: Speaker / X'over Setup
Controlling Audio Speaker / X’over setup [Location] (Only for Front, Rear) ■ Select the speaker position you have installed. Press the [FNC] button. [Tweeter] (Only for Front) ■ h Popup menu appears. You can set up the tweeter when you are selecting front speakers. - Page 81 Controlling Audio Ñ Crossover network setup Only when “Subwoofer” is set to a mode other than “None” in [Speaker Setup]. You can set the crossover frequency of speakers. When Speaker network is set to 3-way: Touch [X over]. Touch the speaker to set up. [FREQ] (High Pass) ■...
-
Page 82: Controlling General Audio
Controlling Audio Controlling General Audio Equalizer Control You can adjust equalizer by selecting the Press the [FNC] button. optimized setting for each category. h Popup menu appears. Press the [FNC] button. Touch [ h Popup menu appears. h HOME screen appears. Touch [ Touch [ h HOME screen appears. -
Page 83: Volume Offset
Controlling Audio Volume Offset [Bass EXT] (Bass Extend Settings) ■ When turned on, the frequencies lower than 62.5 Hz is set to the same gain level (62.5 Hz). Finely adjust the volume of the current source to minimize the difference in volume between [SW Level] ■... -
Page 84: Zone Control
Controlling Audio Zone Control Set each source as follows. You can select different sources for front and rear positions in the vehicle. Press the [FNC] button. h Popup menu appears. Touch [ h HOME screen appears. Touch [ [Zone Select] ■... -
Page 85: Sound Effect
Controlling Audio Sound Effect ■ [K2] Turn ON/OFF the K2 function. Technology to extrapolate and supplement You can set sound effects. with proprietary algorithm, the high- Press the [FNC] button. frequency range that is cut off when h Popup menu appears. encoding. -
Page 86: Listening Position / Dta
Controlling Audio Listening Position / DTA Position DTA control You can fine-adjust your listening position. Listening Position / DTA allows you to improve Touch [Adjust]. the sound field depending on the position of the seat you sit. Touch [Delay]. Listening Position / DTA allows you to set Touch [T] or [U] to adjust the delay time of “Listening Position”... - Page 87 Controlling Audio Ñ Ñ Front Focus Front Focus fine adjustment You can focus the imaginary sound image on Touch [Adjust]. the front of the selected seat. Touch [Delay]. Touch [Front Focus] in the Position / DTA screen. Set each parameter as follows. Select a front focus position.
-
Page 88: Audio Setup Memory
Controlling Audio Audio Setup memory Audio Control settings can be memorized. The memorized settings can be recalled at any time. Press the [FNC] button. h Popup menu appears. Touch [ h HOME screen appears. Touch [ h SETUP screen appears. Touch [Audio]. -
Page 89: Remote Control
Remote control Remote control This unit can be operated using the remote Battery Installation control. The remote control is the optional accessory (RM-RK258). # WARNING CR2025 (+side) • Do not ingest the battery, Chemical Burn Hazard • Use a commercially available button battery The remote control supplied with this product (CR2025). - Page 90 • For the tuner and SiriusXM sources, allows you to enter the preset number. KW-V950BW only – If the preset number is single digit, press the number. – If the preset number is double digits, press continuously the numbers within 3 seconds.
-
Page 91: Connection/Installation
Connection/Installation Connection/Installation ignition key. If you connect the ignition wire to Before Installation a power source with a constant voltage supply, such as with battery wires, the battery may be Before installation of this unit, please note the drained. following precautions. •... - Page 92 Connection/Installation • Do not press hard on the panel surface when installing the unit to the vehicle. Otherwise scars, damage, or failure may result. • Reception may drop if there are metal objects near the Bluetooth antenna. Ñ Installation procedure 1) To prevent a short circuit, remove the key from the ignition and disconnect the ¤...
-
Page 93: Installing The Unit
Connection/Installation Installing the unit NOTE • Use the supplied GPS antenna. Using the GPS 5 or 6 antenna other than the supplied one may cause a Car Bracket drop in positioning accuracy. • Depending on the type of car, reception of the GPS satellite signals might not be possible with an inside installation. - Page 94 Connection/Installation Ñ Connecting wires to terminals Fuse (15A) Speaker impedance: 4-8 Ω White To front left speaker White/Black Gray To front right speaker Gray/Black Green To rear left speaker Green/Black Connect to the vehicle’s Accessory 1 parking brake detection switch harness.
- Page 95 Connection/Installation Ñ Ñ 3-way speaker system setup Connecting the system and external components Subwoofer Preout Mid Range Preout Tweeter Preout When connecting to an external amplifier, connect its ground wire to the car’s chassis to avoid damaging the unit. Preout RCA Cable AV Audio output (ø3.5 mini jack) (Sold separately)
- Page 96 Connection/Installation Ñ Securing the USB extension Accessory 7: GPS Antenna cable Use the supplied GPS antenna. Using the GPS antenna other than the supplied one may Secure the USB extension cable with insulating cause a drop in positioning accuracy. tape or the like so that its connectors are not disconnected.
- Page 97 Connection/Installation Ñ Ñ Connecting an Android Connecting the camera smartphone Front view camera Android smartphone Left Side View Camera and Right Side View Camera Micro USB to USB cable Accessory 9 Accessory 3 (Gray) (1 m) Accessory 2 (Black) (1 m) Front view camera input (Yellow) USB (Gray) terminal...
-
Page 98: Troubleshooting
Pull out the antenna all the way. h Eject the disc and try inserting it again. Contact the The antenna control wire is not connected. JVC dealer if this indicator continues blinking or the h Connect the wire correctly. See Connecting the disc cannot be ejected. - Page 99 Turn the power off and on again. If the “Error 07−67” SXM Ch Unsubscribed message does not disappear, contact your nearest The currently selected channel is not subscribed to. JVC dealer. h In the U.S.A., visit www.siriusxm.com or call No Device (USB device) 1-866-635-2349 if you have questions about your...
- Page 100 Troubleshooting Ñ Apple CarPlay The speed sensor must be connected to use Apple CarPlay wirelessly. Please verify the proper connections or plug in by USB to use Apple CarPlay. The speed pulse is not detected when the Apple CarPlay is started by connecting wirelessly or when the iPhone compatible with wireless Apple CarPlay is registered in [Apple CarPlay Device List].
-
Page 101: Appendix
Appendix Appendix Playable Media and Files You can play various kinds of media and files on this unit. Ñ List of playable discs (KW-V950BW) Disc types / Standard Support Remark DVD Video DVD Audio × DVD-VR × DVD-R* • MP3 / WMA / AAC / WAV / FLAC / Vorbis / MPEG-1 / MPEG-2 / MPEG-4 / H.264 / WMV / MKV playback... - Page 102 Appendix Ñ About files The following audio and video files are supported. ■ Playable Audio files Format Bit rate Sampling frequency Bit count AAC-LC (.m4a) MPEG-2/MPEG-4 AAC LC 8 – 320kbps, VBR 16 – 48 kHz 16 bit HE-AAC(V1,V2) MP3 (.mp3) MPEG-1/MPEG-2 Audio 8 –...
-
Page 103: Region Codes In The World
Appendix Region Codes in the World The DVD players are given a region code according to the country or area it is marketed, as shown in the following map. ■ DVD disc marks ■ Operation regulatory marks With this DVD, some functions of this unit such as the play function may be restricted depending on the location where the DVD is Indicates a region number. -
Page 104: Dvd Language Codes
Appendix DVD Language Codes Code Language Code Language Code Language Afar Interlingua Kirundi Abkhazian Interlingue Romanian Afrikaans Inupiak Russian Amharic Indonesian Kinyarwanda Arabic Icelandic Sanskrit Assamese Italian Sindhi Aymara Japanese Sangho Azerbaijani Javanese Serbo-Croatian Bashkir Georgian Singhalese Byelorussian Kazakh Slovak Bulgarian Greenlandic Slovenian... -
Page 105: Specifications
: 98.5 dB : RGB striped arrangement Dynamic Range (KW-M855BW) Back Lighting : 89 dB : LED ■ Wireless Mirroring section ■ DVD player section (KW-V950BW) Mode D/A Converter : Sink : 24 bit/32 bit Copyright protection Audio Decoder : HDCP2.2... - Page 106 Appendix ■ Bluetooth section ■ Video section Technology Color System of External Video Input : Bluetooth Ver.5.0 : NTSC Frequency External Video Input Level (RCA jacks) : 2.402 – 2.480 GHz : 1 Vp-p/75 Ω Output Power External Video Input Level (mini jack) : Power Class2 : 1 Vp-p/75 Ω...
- Page 107 : 12V DC car battery Installation Dimensions (W × H × D) : 178 × 100 × 155 mm 7 × 3-15/16 × 6-1/8 inch Weight KW-V950BW : 2.1 kg (4.63 lbs) KW-M855BW : 1.7 kg (3.75 lbs) NOTE • Although the effective pixels for the liquid crystal panel is given as 99.99% or more, 0.01% of pixels...
-
Page 108: About This Unit
• The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any • This product includes "Ubiquitous QuickBoot use of such marks by JVC KENWOOD Corporation is TM" technology developed by Ubiquitous Corp. under license. Other trademarks and trade names are Ubiquitous QuickBoot TM is a trademark of those of their respective owners. - Page 109 Appendix that the following conditions are met: CAUSED AND ON ANY THEORY OF LIABILITY, – Redistributions of source code must retain the WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT above copyright notice, this list of conditions and (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING the following disclaimer.
- Page 110 This product contains a CR Coin Cell Lithium Battery JVC KENWOOD Corporation which contains Perchlorate Material – special handling 2967-3, ISHIKAWA-MACHI, may apply. HACHIOJI-SHI, TOKYO, JAPAN See www.dtsc.ca.gov/hazardouswaste/perchlorate. THIS PRODUCT COMPLIES WITH DHHS RULES 21 CFR SUBCHAPTER J IN EFFECT AT DATE OF MANUFACTURE. Location: Top plate (KW-V950BW)
- Page 111 Appendix ■ Información acerca de la eliminación ■ Informação sobre a eliminação de de equipos eléctricos y electrónicos pilhas al final de la vida útil (aplicable a los Este produto não deve ser eliminado como lixo doméstico geral. Devolva a pilha usada ao revendedor países que hayan adoptado sistemas ou entidade autorizada para que a mesma seja independientes de recogida de...
