- Page 1 USER GUIDE gymaware.com January 2019...
- Page 2 We value your feedback on our products and hope that you will contact us with any questions or comments you may have. This user guide is designed to get you up and running; there are some great GymAware set up tutorials available on YouTube: search for “GymAware Setup”.
-
Page 3: What's In The Box
What’s in the Box? The GymAware PowerTool LE VELCRO STRAP Each GymAware kit contains: LED INDICATORS SERIAL # • GymAware PowerTool LE device • Wall charger with mini USB charger cable CHARGING TETHER • First Aid kit INDICATOR • Quick start guide •... -
Page 4: Get Started
Download the GymAware App from the iTunes Apps store Search for GymAware in “iPad only Apps” Note: GymAware PowerTool LE will only work with App v2.3 and above. For the best experience make sure your iPad is running the latest version of iOS. - Page 5 Welcome Launching the in-App Help The very first time you open the App, you will see a series of introduction slides. Help is available throughout the App by tapping the yellow “?” Once HELP mode is on, tap on an element to learn more and then tap the “X” when you are finished learning to return to the active state of the App.
- Page 6 Basic App Guide Using the Dial Interface With any of the input fields you can rotate the dial to update values or use the double tap to bring up the key pad.
- Page 7 The default mode is Free Run when not logged into the Cloud. To change modes, tap the arrow top left of the screen to reveal the Squad List tab. Select GymAware Lite. Three demo athletes will be revealed. Up to 10 demo athletes can be registered and all data and videos can be exported as a csv via email.
- Page 8 2. GymAware Lite continued. 3. GymAware Cloud The GymAware Cloud license is a paid account. Make sure that you are connected to 3G/4G or WiFi is enabled and active. Use your details as supplied in the Getting Started email to login.
-
Page 9: General App Settings
Basic App Guide General App Settings Access the General, Audio/Speach and Camera settings from one main area at the Prepare or Setup screen. Settings are accessed by tapping the cog icon: Options include - • Audio and speech options: Customisable target sounds •... -
Page 10: Recording Modes
Basic App Guide Recording Modes By default, Auto-Rec mode is enabled. Access the recording modes from either the PREPARE or SETUP screens. The icon is the COG shaped icon next to the PREPARE or RECORD button (depending on which screen you are in). To enter the recording mode settings, tap the COG icon. - Page 11 Basic App Guide SETUP screen (GymAware Lite/Cloud) SQUAD selector Tap on the Squad tab or arrow at the top of the screen to reveal the squad list. After selecting the squad the athletes are displayed. Tap on an athlete to select them.
- Page 12 Basic App Guide PREPARE Screen To return to the setup screen press the BACK button located at the bottom of the screen. Use this screen as a final check of parameters and position athlete. In this view the LEADERBOARD tab is hidden.The BAR GRAPH tab has been swiped open to display the results in this form.
-
Page 13: Review Screen
Basic App Guide REVIEW Screen By tapping the REVIEW ATHLETE button you can switch between setup and review modes. Only athletes and exercises which have collected data sets will be displayed. PARAMETER LOCK In REVIEW mode, all sets collected for each exercise are able to be reviewed. - Page 14 Basic App Guide Targets and Ranges The targets module appears when you use GymAware Lite or GymAware Cloud. The dial colour will change depending on which target is selected. Squad Target (Green Zone) Applicable to all athletes within the squad. Changing the Squad Target will automatically update across any iPad logged into the Cloud with a WiFi connection.
- Page 15 PowerTool Setup On the Floor Positioning of the PowerTool for optimal performance. Note: The magnetic feet of the PowerTool hold it in position. Aim to position the PowerTool so that it is vertically The PowerTool should be On the gym floor place the under the path of the lift.
- Page 16 PowerTool Setup Pin-loaded weights machine The PowerTool can be attached to any pin-loaded weights machine. Place PowerTool on a small Thread the pin through the Return the pin to the weight You are now set and ready to weight close to the weight Velcro strap.
-
Page 17: Ceiling Mount
PowerTool Setup Ceiling Mount The GymAware PowerTool can be mounted above the lifting platform. You need to purchase a ceiling bracket and mount it using the additional mounting screws provided. Attach the bracket to the Ceiling mount in use attached ceiling. -
Page 18: Troubleshooting
Trouble Shooting Online Help - GymAware.zendesk.com iOS and PowerTool Communication Restart the iOS There are occasions where you may find your PowerTool PowerTool connects to the iOS device, then omits one long beep is not behaving as it should. It may not be responding and switches off. - Page 19 Further information/tutorials are available - who is good at changing lightbulbs and follow the instructions at gymaware.zendesk.com - We have even made a video which we gymaware.zendesk.com recommend watching. NOTE: If problems persist visit gymaware.zendesk.com or contact Kinetic on (+61 2) 6162 1770 office@kinetic.com.au...
- Page 20 Trouble Shooting PowerTool Hardware - What do the indicator LED’s mean? or firmware upgrade...
- Page 21 • Take care when plugging the wall charger in that you don’t push the charging port up or down as it can break the port. • Also, whilst on wall chargers, ensure you are using only the GymAware charger you purchased with the unit. Other similar chargers have a much higher charge capacity and will fry the main circuit board.
- Page 22 Constantly in data collection mode, with targets and ranges able to be set. Provide real-time feedback - data display is constant. GymAware Lite Experience the full features of the GymAware App with 10 demo athletes. Collect and review results across generic lift types. Basic export to csv.
- Page 23 GymAware Feature Free Run Lite Cloud Free to all users Free to all users Real-time feedback Set targets and ranges Results saved to iPad Basic CSV export Detailed CSV export Review results on iPad Video Preset VBT zones Internet connection required...
- Page 24 LIFT YOUR GAME • VELOCITY BASED TRAINING • FATIGUE MONITORING • ACCURATELY MEASURE POWER OUTPUT • DESIGNED FOR TEAMS • VALIDATED AND RELIABLE Tel (+61) 02 6162 1770 Email: sales@gymaware.com gymaware.com...
