- Page 1 Quick Start Guide...
- Page 2 You have now joined the community of GymAware users who are all benefitting from using the best power monitoring equipment available. At Kinetic we value your feedback on our products and hope that you will contact us with any questions or comments you may have.
- Page 3 What’s in the Box? The GymAware Kit POWERTOOL CHARGER INDICATOR LEDs TETHER SLOT VELCRO STRAP TETHER MINI USB CONNECTOR...
-
Page 4: What's In The Box
What’s in the Box? The PowerTool Each GymAware kit contains: • PowerTool device • Wall charger with mini USB charger cable TETHER • Hard carry case • Quick start guide Optional extras available from the online shop: VELCRO • Ceiling mount bracket STRAP •... -
Page 5: Initial Setup
Initial Setup Download the GymAware App from the iTunes store Log on to the iTunes store and download the appropriate free GymAware App. Note: For the latest GymAware features make sure your iOS device is running the latest software. Manual Pairing - Bluetooth Pairing Follow these steps for Bluetooth pairing of the PowerTool and an iOS device for iOS devices which have not been previously paired. - Page 6 Initial Setup - Manual Pairing Make sure Bluetooth is ON. The LED will change from The PowerTool name should As this is the first connection orange to green and will start now appear on the iOS’ between the PowerTool and In this setting, wake up the flashing.
- Page 7 When successfully paired the PowerTool will beep twice and the green LED will change to a continuous orange LED. Select the GymAware App - either Lite or Online/Pro You are now ready to GO! Press the iOS Home button to return to the main screen.
- Page 8 Previously Paired Device Previously Paired PowerTool and iOS Device Reconnecting your iOS device to GymAware PowerTool Skip to Section 4 if you have just Manually Paired your device Select the Settings App Turn on your iOS device and Make sure Bluetooth is ON...
- Page 9 If you stop pulling the tether the PowerTool will revert back to accepting new connections, indicated by green You can now stop pulling the tether as the GymAware App flashing LED. will automatically open. You will need to follow Step 2 - Manual Pairing.
- Page 10 Once the PowerTool is connected the angle sensor needs to be zeroed. Do this before connecting your PowerTool to the weight stack/bar. Make sure the PowerTool tether is Select the GymAware App - Select Test Subjects (This is not attached and fully retracted into...
- Page 11 This message will appear. Once you have pressed OK you will be taken to this screen Press OK (GymAware Lite) In the GymAware App By default Angle Measurement is set to ON Now connect the tether to the Go to Settings...
-
Page 12: On The Floor
PowerTool Setup On the Floor Positioning of the PowerTool for optimal performance. Use the magnetic feet of the PowerTool to hold it firmly in position. Aim to position the PowerTool so that it is vertically The PowerTool should be On the gym floor place the under the path of the lift positioned adjacent and away PowerTool on a small weight to... - Page 13 PowerTool Setup Attaching the Velcro Strap Thread the Velcro strap around the bar with the fuzzy side to the outside. Position the Velcro strap inside the collar of the bar. This way you dont need to remove it when Go through the buckle and back Ensure the fuzzy side is on the you change weights.
- Page 14 PowerTool Setup Pin-loaded weights machine The PowerTool can be attached to any pin-loaded weights machine. Place PowerTool on a small Thread the pin through the Return the pin to the weight You are now ready to GO! weight close to the weight Velcro strap.
- Page 15 PowerTool Setup Ceiling Mount The GymAware PowerTool can be mounted above the lifting platform as an alternate position. You will need to purchase a ceiling bracket and mount it using the additional mounting screws provided. Screw the PowerTool to the...
-
Page 16: Troubleshooting
Trouble Shooting PowerTool Hardware ISSUE: Battery Warnings PowerTool emits two long beeps and The red LED starts flashing when the The PowerTool continuously beeps and switches off when tether pulled. tether is not being pulled. the red LED flashes when the tether is not being pulled The PowerTool battery needs recharging. - Page 17 Trouble Shooting Bluetooth ISSUE: Pairing Unsuccessful First allow the PowerTool to If this doesn’t work, forget the enter sleep mode. PowerTool device from the device list - see over the page. It will go to sleep when there is no connection from an iOS Once it is forgotten you can device and no movement of pair the device manually and...
- Page 18 Sometimes you may need or want to reset your PowerTool. For example, the device becomes unresponsive with the LEDs on, OR you have accidently auto-connected to the wrong iOS device and want a quick disconnect. To watch the video tutorial visit: http://kinetic.helpdocsonline.com/#reset-powertool To perform a Hard Reset...
- Page 19 Trouble Shooting PowerTool Hardware ISSUE: Resetting the PowerTool Full Reset There may be an occasion when the PowerTool isnt working correctly. You will need to do a Full Reset - this requires a paperclip and is only available on PowerTools with the mini-USB port. •...
- Page 20 Trouble Shooting Bluetooth ISSUE: Forgetting the device Select the PowerTool from the Select “Forget this Device” Select “Forget Device” The PowerTool will have device list - as above GA #241. disappeared from the device Click on the (i) list. You now need to manually pair (See Part 2 of the manual)
- Page 21 Now, turn the iOS device back on by pressing the power button and go back to Initial Setup. The iOS device will need a complete power down. NOTE: If problems persist please contact Kinetic on +61 2 6162 1770 or help@kinetic.com.au...
- Page 22 GymAware Software Options GymAware PowerTool FREE Lite Online* Pro* Video capture All the features of All the features of Meta export GymAware Lite and GymAware Online and Language support Maximum 50 sets Squad management Analysis reports Real-time results Unlimited data...
