- Page 1 I n s t r u c t i o n s f o r u s e MESH NEBULIZER MODEL: TH-134 MODEL: TH-135 READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE USE M E S H N E B U L I Z E R M O D E L : T H - 1 3 4 • T H - 1 3 5...
-
Page 2: Table Of Contents
Instructions for use TH-134 • TH-135 MESH NEBULIZER MODEL NO.: TH-134 MODEL NO.: TH-135 INSTRUCTION MANUAL INDEX 1. Introduction ..................... Page 4 2. Intended purpose ..................Page 4 3. Precautions ....................Page 4 4. Notice for safety operation ............... Page 6 5. -
Page 3: Introduction
Instructions for use TH-134 • TH-135 1. INTRODUCTION Dear Customer, This manual contains important information you must know about the product. Please read it thoroughly before use. Please keep this manual with you. The Nebulizer’s quality will be diff erent by diff erent medicine characteristic;... - Page 4 Instructions for use TH-134 • TH-135 3. Use this appliance only for its intended use as described in this manual. 4. Do not use cotton swabs or other objects to touch the mesh; otherwise, product will not operate. 5. Do not use diff erent type batteries in the same time.
-
Page 5: Notice For Safety Operation
Instructions for use TH-134 • TH-135 4. NOTICE FOR SAFETY OPERATION To ensure safety, please do follow all rules below: 1. Before using • Use this appliance in the correct manners outlined in this manual. • This appliance had to operate under nominal temperature (10 º C ~ 40 º C), outside the nominal temperature range was not suitable to operate the product. - Page 6 Instructions for use TH-134 • TH-135 • Diff erent patients should use individual clean medical cups and mouth pieces to avoid cross infection. • Some medicine dose not nebulizes well, please consult with your doctor. • This appliance has a low-battery indicator. When the indicator light is green, the power is good for working.
-
Page 7: Name Of Component
Instructions for use TH-134 • TH-135 5. NAME OF COMPONENT 1. Power button: press to turn on or off the appliance. 2. Indicator Light: Indicate the power condition. (Green for normal/Orange for battery weak/Red for exhausted battery) and also showing is there still have medicine inside the medical cup. -
Page 8: How To Use
Instructions for use TH-134 • TH-135 6. HOW TO USE 1. Make sure that all parts such as mouthpiece or mask, medical cup are clean, or clean the above three parts before using. 2. Open the battery cover and put in batteries. -
Page 9: Clean And Maintenance Notice
Instructions for use TH-134 • TH-135 means the batteries are exhausted and the appliance cannot operate properly. Please replace with new battery immediately. • If there is no medicine inside the medical cup, indicator light will turn red and fl ash three times before appliance turning off... -
Page 10: Disinfection
Instructions for use TH-134 • TH-135 8. DISINFECTION Medical cup can be disinfected by boiling in hot water. After 3-4 minutes of boiling, shake off excessive water from the cup and let them dry on a clean, lint free (paper) towel. -
Page 11: The Accessories
Instructions for use TH-134 • TH-135 10. THE ACCESSORIES Model No. Size Child Mask PY-001-MS 87.22 × 64.35 × 57 mm Adult Mask PY-001-ML 124 × 77 × 68.5 mm Mouth Piece PY-001-MP 43 × 27.5 mm Medical Cup (Gray) PY-001-MC 54 ×... -
Page 12: Specifications
Instructions for use TH-134 • TH-135 11. SPECIFICATIONS Model Number TH-134 • TH-135 Power Supply 1.5V × 2 AA Size Alkaline battery or AC adaptor (optional). Input: 100~240 VAC, 0.3-0.15A, 50~60 Hz Output: 3VDC, 1.33A Power Consumption < 2W Active current consumption <... -
Page 13: Symbol Information
Instructions for use TH-134 • TH-135 Reusable parts life Medical cup, Mask, Mouthpiece: 6 months According as reliability test result – One time per day Dimension (L × W × H): 45 × 54 × 122 mm The specifi cations may be changed without prior notice. - Page 14 • B.Well Swiss AG Bahnhofstrasse 24, CH-9443 Widnau, Switzerland ISO9001 & ISO13485 Certifi ed This device complies with European Council Directive 93/42/EEC on Medical Devices...
- Page 15 B.Well Swiss AG Bahnhofstrasse 24, CH-9443 Widnau, Switzerland...
