Schecter Hellraiser C-1 Quick Start Manual page 2

c
d
radius
Bridge Pickup
Name:
EMG 81TW
Model No:
81TW
Construction:
Humbucker/Single Coil
Magnet:
Ceramic
Output:
Impedance 10K
Description: The dual-mode design allows for
maximum flexibility, with the original
81 providing all the crunch and
aggressiveness it's famous for and
an all new single-coil that features
a fatter tone with plenty of punch
and clarity. Either mode is
accessed through a push/pull pot
for versatility. Dual internal
preamps, one tuned for single-coil
mode and the other for dual-coil
mode, give the 81TW two distinct
sounds while delivering EMG's well
known noise cancelling technology
in both modes.
Strings
a
6-String Guitar*
Tuning: E-A-D-G-B-E
Gauge: .046-.036-.026-.017-.013 .010
(EB Regular Slinky #2221)
*Changing to different string gauges and/or
alternate tunings may require minor neck/bridge
adjustments for optimal performance. For Schecter
setup tips refer to Schecter Setup Guide.
Hellraiser C-1
Neck Specs:
Scale Length: 648mm/25.5"
A: Width at Nut- 42mm
B: Width at Last Fret- 56mm
b
C: Thickness at 1st Fret- 20mm
D: Thickness at 12th Fret- 22mm
Radius: 355mm/14"
Neck Pickup
Name:
EMG 89
Model No:
89
Construction:
Humbucker/Single Coil
Magnet:
Alnico V
Output:
Impedance 10K
Description: Featuring two pickups in one,
the 89 is loaded with alnico V
magnets and has separate
preamps each providing custom
outputs for both dual coil and
single coil modes. In dual coil
mode, the sound is rich, warm
and powerful, but still very clear
and is similar to the 85. The
single coil mode, accessed via
the push pull pot, delivers the
traditional Strat single coil
sound: bright, airy, and chimey,
and is similar to the SA.
