Neck pickup
EMG 85
Bridge pickup
EMG 81
3-way switch settings
1
2
Neck
Bridge
Neck Vol
Bridge Vol
Tone
3-Way
Tone
Switch
For technical or warranty questions please email: tech@schecterguitars.com
Diagram copyright Schecter Guitar Research 2011
EMG
EMG
3
9-Volt
9-Volt
battery
battery
Hellraiser Special C-1
Wiring Diagram
3
2
3-way
switch
Ring (battery ground)
2
Bare
White
1
Bare
White
Master
tone
25k
Output Jack
= ground. This symbol
is found where any ground connection
should be soldered.
Bridge
volume
25k
Neck
volume
25k
Tip (hot output)
Sleeve (ground)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Schecter Hellraiser Special C-1
Summary of Contents for Schecter Hellraiser Special C-1
-
Page 1: Wiring Diagram
Ring (battery ground) Sleeve (ground) Neck Vol Bridge Vol Output Jack Tone 3-Way Tone = ground. This symbol Switch is found where any ground connection For technical or warranty questions please email: tech@schecterguitars.com should be soldered. Diagram copyright Schecter Guitar Research 2011... - Page 2 Strings 6-String Guitar* Tuning: E-A-D-G-B-E Gauge: .046-.036-.026-.017-.013 .010 (EB Regular Slinky #2221) *Changing to different string gauges and/or alternate tunings may require minor neck/bridge adjustments for optimal performance. For Schecter setup tips refer to Schecter Setup Guide.
- Page 3 This model is equipped with a Graph Tech Black TUSQ XL nut. The Black TUSQ XL delivers a rich and balanced tone with big open lows and a noticeable increase in overall sustain followed by a very balanced output from your strings. Laboratory-proven to enhance harmonic content up to 200% and sustain up to 16% and is engineered for maximum vibration transfer.
