Silva 179KR Manual

COMPASS MANUAL
WRIST COMPASSES
HOW TO
NAVIGATE
ORIENTING THE MAP TO NORTH
The easiest way to use a map and compass together is to ori-
ent the map towards North. Simply align the map meridians
with the compass needle so that "up" on the map is pointing
North. Now everything on the map is in the same direction as
on the ground. When travelling along your route, remember to
keep the map oriented at all times. By doing this it will be very
easy to follow your route since turning right on the map also
means turning right on the ground! Properly orienting the map
is quick, easy and the best way to avoid unnecessary mistakes.
EASY AS 1-2-3
THE SILVA 1-2-3 SYSTEM
FIXED HOUSING
1-2-3
Place your compass on the map and
use your thumb to make a straight line
between your current position and
your destination.
Make sure the thumb points
towards your destination.
1-2-3
Turn yourself and the compass until
the compass needle is parallel with
the map meridians and the orange/red
part points north on the map.
1-2-3
Now the thumb will point towards your
destination. Take a landmark and start
moving. Enjoy!
SPECTRA HOUSING
After step 2 - note the coloured refer-
ence point that the needle is pointing at.
In step 3 - your thumb will point to-
wards your destination as long as the
needle points at the
colour marking from
step 2.
BASIC

COMPASS FEATURES

WRIST COMPASSES
With basically the same features and user area as a thumb
compass, but placing an even greater
over accuracy. The wrist compass has no baseplate. It con-
sists solely of a needle capsule strapped at the base of the
thumb. The thumb serves the function of a baseplate when
taking and sighting bearings. The wrist compass can be used
on either left or right hand. It is often used for city/park race
orienteering, MTB orienteering or Adventure racing.
1
2
1
1
WRIST BAND
2 LIQUID FILLED CAPSULE
WRIST BAND
1
With the compass attached to the wrist, you get both
hands free, which gives you more flexibility when holding a
map, scrambling on rocky ground etc. The wrist compass
can be used on either left or right hand. The compass band
is strapped at the base of the thumb; the thumb serves the
function of a baseplate when taking and sighting bearings.
The wrist band is adjustable for optimal fit.
2 LIQUID FILLED CAPSULE
The capsule is filled with anti-static liquid (customized formula) that ensures
clear reading, fast settling time, perfect dampening, stability and accuracy of
the needle.
3 COMPASS NEEDLE
The magnetic needle features a combination of a sapphire jewel bearing and
a hardened steel pivot that minimises friction, which in turn gives rapid and
accurate movements. Magnetic North direction accuracy: 1 degree. The orange
end points to magnetic north!
Our wrist compass needles come in two different versions:
JET needle: The world's fastest needle, highly transparent for extra map visibility.
Steel needle: Swedish high quality, stainless steel, stable and distinct
emphasis on speed
3
4
3
COMPASS NEEDLE
4 SPECTRA SYSTEM™
COLOURED REF. POINTS
