Summary of Contents for CommBox Tilt Trolley
- Page 2 Please note: If you have received a paper copy of the instruction guide, please contact CommBox Support for an electronic copy of the guide. This will enable you to expand out the photos for better recognition of Parts and Procedures.
- Page 3 This Flat Panel Convertible Trolley has been designed as a generic product and some of the fasteners, holes and procedures may not apply to your products individual needs. Mounting some of the items to this product will require you to consult the manufactures instructions, Do so accordingly! During the build-up of the FPMC there are a number of areas that lifting of parts etc can have adverse effects on personnel and parts if guidelines are not strict ly...
- Page 4 Step 1 : Remove bolts from part 020 and using 4 12x30mm bolts and 12mm nylock nuts secure parts 020 to parts 001. Once castors are secured, using a soft blow hammer, knock in the plastic end caps 008 into the ends of 001. Note: the lockable castors go to the rear (shorter end) Step 2: Align parts 001 with 005 as shown.
- Page 5 Step 3: Using 8 8x20mm CHB’s loosely secure parts 004 to 005 4off 8x20mm CHB at each Minimum of two people required for this step Step 4: Aligning the control cable of 013 to the inside, secure both columns to the base structure using 8x 6x25mm bolts.
- Page 6 Step 5: Once 013 are in position and tight, all remaining bolts can be tighten up. Step There is a second mounting hole for the 8x20mm CHB from the side (higher than shown here). The second 8x20mm CHB that secures the cable tray assembly is shown below.
- Page 7 Step 7: Then push one 10x 40mm bolt in through the actuator and part 007 as shown. Once all bolts are in, secure the 8x20mm CHB’s from Step 6. (do not over tighten the 1 0mm nut) Step 8: Using parts 002, 018, one 10x 30mm CHB bolt & 10mm nylock nut per side place two 018 washers between parts 002 &...
- Page 8 Step 9: Place the cable tray structure 006 onto the lift columns 013. The fixing screws should be lined up as shown in the upper mounting position.
- Page 9 Ensure the columns cables are pushed through the large hole in parts 006. Step 9: Using 8 6x25mm bolts secure parts 006 to 013 (lift Columns) as shown above Step 1 0: Using 4x12mm bolts and 4mm nylock nuts secure the control box (part 010) to the cable tray 017.
- Page 10 Step 1 1 : Then secure part 015 (power board), using 4x8mm bolts and nylock nuts to part 017. Step 1 2: Secure part 003 (lap top tray) to part 017 using 2x 8x20mm CHB’s, 2x 8mm washers and nylock nuts. Step 1 3: Plug the actuator 013/ 011 extension leads into the actuator leads.013 actuators (column) plug into #1 &...
- Page 11 Step 15: Secure part 000 onto parts 002 using 4 8x20mm CHB’s (push bolts from the outside towards the inside of the trolley). This part must remain loose and movable. To be secured during a later step. NOTE: The 2 images above show the cradle mounted in the lower position. The cradle should be level with the vertical actuators Step 16: Temporarily plug the Control Head into the powerboard.
- Page 12 Step 16: Secure the remaining 000 bracket to the top row of the panels VESA mount using either the panels supplied hardware or two of the 8x12/ 20mm bolts and 8mm washers. Apply the foot brackets for the remainder of the assembly. Step 1 7: Using a minimum of two people raise the panel and locate part 000 onto the cut-outs in parts 002.
-
Page 13: Additional Notes
Error E01 : The E01 error will appear if the actuators get themselves out of sync. If you get the E01 error follow the initial ising procredure in step 20. For any other errors please contact CommBox support on 02 9975 6001, or alternatively you can log it through the website here.
