- Page 1 ZLX-BRKT ZLX Wall Mount Bracket ZLX-BRKT en | Installation Note...
- Page 3 Safety Caution! Due to the weight of the speaker system, it is imperative the bracket be properly secured to the wall. The choice of fastener (not supplied) will be determined by the material and construction of the mounting surface. Electro Voice 01 | F01U285494...
-
Page 4: Installation
ZLX-BRKT ZLX Wall Mount Bracket Installation Installing ZLX Mounts The ZLX Wall Mount Bracket is designed for use with all of the ZLX Series loudspeakers. To attach the mounts to a ZLX Series loudspeaker, do the following: Remove the top handle from the loudspeaker by removing the four (4) screws. Keep these screws to assemble the upper mount. -
Page 5: Upper Mount
Upper Mount Upper Mount (down position) (up position) Lower Mount Lower Mount (up position) (up position) ZLX-12P/ZLX-12 ZLX-15P/ZLX-15 Figure 2.2: ZLX Attach Mounts Attach the lower mount with four (4) of the screws from step 2, where the bottom handle was located in the up position. - Page 6 ZLX-BRKT ZLX Wall Mount Bracket Pivot Pin Pivot Pin ZLX-15P/ZLX-15 ZLX-12P/ZLX-12 Figure 2.3: Guide onto U-bracket Guide the lower mount and ensure the lower U-bracket pivot pin is securely placed in the notch. (See Figure 2.3.) The loudspeaker is loosely hung and allows you to position the loudspeaker.
- Page 7 ZLX-15P/ZLX-15 ZLX-12P/ZLX-12 Figure 2.5: Secure Loudspeaker ZLX Wall Mount Bracket–Horizontal Installation To horizontally wall mount a ZLX Series loudspeaker, do the following: Caution! Due to the weight of the speaker system, it is imperative the bracket be properly secured to the wall.
- Page 8 ZLX-BRKT ZLX Wall Mount Bracket ZLX-15P/ZLX-15 ZLX-12P/ZLX-12 Figure 2.6: Guide onto U-bracket—Horizontal Guide the lower mount and ensure the lower U-bracket pivot pin is securely placed in the notch. (See Figure 2.6) The loudspeaker is loosely hung; gently allow the loudspeaker to rest against the mounting surface.
- Page 9 Attach the U-bracket to the wall using fasteners suitable for the wall material (not supplied). Follow the Installing ZLX Mounts installation instructions but install the upper and lower mounts on the opposite handles. Note: the upper mount will be attached to where the lower handle was located and the lower mount will be attached to where the upper handle was located.
-
Page 10: Technical Data
ZLX-BRKT ZLX Wall Mount Bracket Technical data Quantity Description U-bracket Upper mount Lower mount Screws Table 3.1: Components Dimensions (H x W x D): Net Weight: Shipping Weight: Table 3.2: Specifications 01 | F01U285494 Electro Voice... - Page 11 Bosch Security Systems, Inc 12000 Portland Avenue South Burnsville MN 55337 www.electrovoice.com © Bosch Security Systems, Inc, 2013...
