SPECIFICATIONS
No.
Components
1
S5U1C33001H
2
USB cable
3
AC cable
4
Target system interface cables
(30 pins, 10 pins, 4 pins)
5
Target system connectors
(30 pins, 10 pins, 4 pins)
6
Target system power supply
cable (6 pins)
7
Target system power supply
connector (6 pins)
OPERATING ENVIRONMENT
No.
Items
1
Operating temperature
2
Storage temperature
3
Operating humidity
4
Storage humidity
5
Resistance to vibration
Table 14 Specifications
Items
183 mm (W) × 125.7 mm (L) × 36.6 mm (H)
Dimensions
Input voltage
100 V to 240 V AC (50 Hz/60 Hz)
Power consumption
10 W, max.
Length
2 m
Connectors
S5U1C33001H side: Standard-B type
Host PC side: Standard-A type
Length
1.8 m
Plug type
Bipolar with ground
Length
Approx. 15 cm
Connectors
30-pin (L angle): SL01-30L3 (KEL)
10-pin (straight): J3654-6002SC (3M)
10-pin (L angle): J3654-5002SC (3M)
4-pin (straight): HKP04M5S (Honda)
4-pin (L angle): HKP04M5LS (Honda)
Length
Approx. 15 cm
Connector
6-pin (L angle): IL-6P-S3FP2 (JAE)
Table 15 Operating Environment
Specifications
5 to 35°C
-10 to 60°C
35 to 80%
20 to 90%
2
Operating:
0.25 m/S
2
Transportation: 1 m/S
S5U1C33001H
Specifications
(Ver. 4)
Remarks
Rubber feet included
Shielded cable
Remarks
No condensation
