Net And Post Set - JOOLA Infinity Instruction Manual

10.
IMPORTANT: Install track cover (4 qty)
over the angled bar. Align the hole on the track
cover, the logo side panel, and the angled track
bar and affix the 6mm x 45mm screw (4 qty).
11.
Completed Table.
All assembly instructions are described with all
bolts and parts from the outside looking inward.
NET ASSEMBLY
1.
Make sure the table is folded down in play
position. To do so, release the safety latch and
carefully lower each table half.
2.
Attach one net clamp to the middle edge of
where the the table halves would meet. Repeat
this with the other net clamp on the opposite
side. Slide the Net post into the slot on one
side of the table, and do the same for the other.
Make sure the white fabric of the net is on top.
Take the string and attach it to the base of the
net post securely.
ASSEMBLY INSTRUCTIONS
USAGE INSTRUCTIONS
Unfolding the Table:
When unfolding the table, the first step is to lock the casters. Then take caution
so that all areas around you are clear. Please remember, the table is very
heavy. If you are worried that it may be too heavy, it is recommended that
at least two people unfold the table. To unfold the table, pull on both locking
rings. By pulling on the locking rings, it releases the lock plunger from the lock
position so that the table surface is able to fold down into play position. After
unlocking the table, slowly lower the table half down. Do the same for the other
half. Then install the net and post set and enjoy your Infinity Table Tennis Table.
Folding the Table:
To fold the table into storage position, the first step is to lock the casters. Next,
ensure that the net and post set have been removed from the table. Failure
to do so could cause damage to the table hen trying to fold the table with the
net and post set still attached. Please remember that the table is very heavy.
Ensure that you have enough ceiling height to raise the table half. If you are
worried that the table will be too heavy for you to lift, it is recommended that at
least two people fold the table. Raise the table half to the vertical position until
you hear a loud clicking noise. Then inspect the two white side logo plates to
ensure that the locking plungers are extruding from the plate. If they are not,
please gently but carefully rock the table half until the plunger extrudes from the
hole. Do the same for the other half.
Playback Position:
Playback position is achieved by unfolding one half of the table and folding the
other half. Make sure that the folded half has the locking plungers in place.
Always use the locking casters and place them in lock position when the table
is in playback position for added safety.
Leveling:
The Infinity table comes with leveling feet. Spin the leveling feet to the correct
height to make the table level.
Using the locking casters
When the table is in storage position, or in play position, please remember to
always lock the casters for added safety.
