Ezmax EZMP-4200 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Copyright © 2005 EZMAX. All rights reserved.
Advance permission of EZMAX is required to use User's Guide, photos,
the related documents and software of the product. Any violation may
follow the legal measures.
The contents of the User's Guide are subject to change without prior
notice for further improvement of the product.
EZMAX
http://www.ezmax.co.kr

Table of Contents

Before Use
Product & Accessories ............................. 2
PC System Requirements ....................... 3
Safety Precautions .................................. 4
Features .................................................. 5
Designation of Parts
Side View of the Product ......................... 8
Function Icons in Display .......................... 9
Preparation
Installing USB Driver ................................10
Connecting Player to PC ........................12
Manually Installing USB Driver .................13
Using Removable Disk .............................16
Disconnecting USB Cable ........................19
Upgrading Firmware.................................21
Installing LDB Manager ..........................23
Using LDB Manager ...............................24
Basic Functions
Basic Operation ......................................29
Power On/Off .........................................32
Playback Music File ................................33
Using Navigation .................................. 36
Voice Recording/Listening .................... 37
................... 38
Listening to FM Radio .......................... 41
Function Menu
Menu Setting ........................................ 46
Music File Playback ............................. 47
.................................... 48
Detailed Menu Setting .......................... 51
Playback Mode Setting ........................ 52
Sound Setting ...................................... 53
Display Setting ..................................... 55
Timer Setting ....................................... 57
Encoding Setting .................................. 59
Setting ................................................. 60
Others
About Battery ....................................... 63
HOLD Setting Method .......................... 64
Troubleshooting ................................... 65
Specifications ....................................... 67
Service (A/S) ........................................ 68
Warranty .............................................. 69
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZMP-4200 and is the answer not in the manual?

Questions and answers

Related Manuals for Ezmax EZMP-4200

Summary of Contents for Ezmax EZMP-4200

  • Page 1: Table Of Contents

    Copyright © 2005 EZMAX. All rights reserved. HOLD Setting Method ......64 Troubleshooting ........65 Advance permission of EZMAX is required to use User’s Guide, photos, Basic Functions Specifications ........67 the related documents and software of the product. Any violation may Basic Operation ........29...

  • Page 2: Product & Accessories

    Products & Accessories PC System Requirements Basic requirements s hould be satisfied to use this player on yo ur PC. Make sure to c heck the follo wing recommendatio ns before its use: Pentium 200MHZ or above Windows 98SE / ME / 2000 / XP (Windows 98SE - Install Drive r) Mac OS 9.0 / 10.0 USB Port (2.0 s upported)

  • Page 3: Safety Precautions

    Safety Precautions Features Listening Cautions… Multi-Codec Player The output of the product guarantees the best sounds at its proper volume. As Multi-codec pla yer supporting MP3, WMA, ASF(a udio), OGG, WAV format. listening with a volume set at a high position for a long time may damage your sense of hearing, make sure to listen to the music at a proper volume.

  • Page 4: Front/Rear View Of The Product

    Features Front/Rear View of the Product FM Radio Conveniently enjoy the FM radio with a variety of functions such as the manual/automa tic frequency searc h, automatic tune to the radio station, and the station p reset. Easy Navigation Tree structure allows you to manage and search a specific song more conve niently. Lyric Display(LDB) You can easily edit, save a nd display the lyrics of a song in 3 lines on the large display.

  • Page 5: Side View Of The Product

    Side View of the Product Function Icons in Display...

  • Page 6: Installing Usb Driver

    Installing USB Driver Installing USB Driver Make sure to install the USB driver before connecting it to the PC. Click “Ne xt”. When there appears “Add New Ha rdware Wizard”, press the “Cancel” button and install Upgrade Manager. If you install Upgrade Manager, the USB driver will be a utomatically installed. ►...

  • Page 7: Connecting Player To Pc

    (Make sure to use only USB cable supplied w ith the MP3 Player.) If there doesn’t appear “EZMAX EZMP-4200 USB Device" in “Disk Drive” o f Device Manager or “USB Mass Storage Device”(Except Window 98SE) in Universal Serial Bus Controller, or if there does a ye llow exclamation mark or “Unknown Device”, the...
  • Page 8 Manually Installing USB (Win 98SE) Manually Installing USB For Windows 98SE Double c lick the device with a exclamation or q uestion mark. Click ‘Next’ in the subsequent windows. Designate the path for searching the driver file to \Upgrade Manager\Drivers of CD Drive.

  • Page 9: Using Removable Disk

    Using Removable Disk Using Removable Disk Since the player is detected as a removable disk on the part of PC, you ca n easily Export File(Upload) upload, download, or delete music files or folders in Windows Explorer without a 1) Connecting the USB cable to the Player allows the Player to be separate manager program.

  • Page 10: Disconnecting Usb Cable

    Using Removable Disk Disconnecting USB Cable Format Player After completing file transfer, disconnect the USB cable in the following way. 1) Formatting in the Windows ① Select the removable disk, and then right-click the mouse to Right-click the removab le hardware icon on the taskbar of the desktop , select Format(Select “FAT”...

  • Page 11: Upgrading Firmware

    Disconnecting USB Cable Upgrading Firmware Download the latest version of firmware at o ur website (www.ezmax.co.kr) Click “OK” to co nfirm the device to s top. and unzip it (unzipped to 4 files.) Copy the unzipped latest firmware files into C:\Program Files\EZMAX\EZMP-4200 folder.

  • Page 12: Installing Ldb Manager

    Upgrading Firmware Installing LDB Manager Click ”Start” to proceed Firmware Upgrade. Select “Data Area Formatti ng” Insert the Installation CD into CD-ROM Drive and click setup.e xe in the folde r to delete all the files in the sys tem. of LDB Manage r.

  • Page 13: Using Ldb Manager

    Using LDB Manager Using LDB Manager Enter Lyrics(Auto Search) LDB Manager is a program that a utomatically e nters the lyrics in MP3 music files Select the MP 3 file to e nter the lyrics in the file list window, and press ①...
  • Page 14 Using LDB Manager Using LDB Manager Enter Lyrics (Manual Search) Delete Lyrics ① Select the file to enter the lyrics a nd click the button on the top menu. Select the MP3 file to delete lyrics and press the button to delete their information.

  • Page 15: Basic Operation

    Using LDB Manager Basic Operation ③ Press Pla yback in the preview window and press the S YNC setting b utton at the point where there s hould appear one line of lyrics editing window. Display - Displays the operating status of the product.. ④...
  • Page 16 Basic Operation Basic Operation - W hen listening to the FM radio, press short to move to the VOL + previous frequency while keep pressing to automatically search for - Each press on the button will increase the volume step by step. the previous station.

  • Page 17: Power On/Off

    Power ON/OF Playback Music File Power ON You can p lay back a music file or files recorded in the player in the PLAY menu. ◎ Press PLAY short to turn the power ON, and there will appear the logo on Press MENU short to move to the menu mode.
  • Page 18 Playback Music File Playback Music File (3) BOOKMARK PLAY Searching For File - Press MENU to enter into BOOKMARK PLAY where you can see the bookmark During the pla yback, press the button to play back the previous/next files. file. - Press PLAY to pla y back BOOKMARK files alone.

  • Page 19: Using Navigation

    Using Navigation Voice Recording/Listening Use the functio n of Na vigation to easily search for the file you want. Recording Voice During the playback or in the pause status , press and hold REC to record voice. Press and hold MENU to move to the Navigation mode. Press it again to stop recording.

  • Page 20: Mp3 Encoding/Listening

    MP3 Encoding/Listening MP3 Encoding/Listening Bit Rate Setting One jack of the line-i n shall be connected to the output port of an external acoustic In the MENU mode, use the MENU b utton and button to select unit, a nd the other jack(USB port) line-in port of the...

  • Page 21: Listening To Fm Radio

    MP3 Encoding/Listening Listening to FM Radio Encoding In the MENU mode, select FM RADIO menu and press the MENU button to move When the music for encoding is played back from an external device, press and to FM RADIO mode. hold the REC button on the part of the pla yer to start encoding.
  • Page 22 Listening to FM Radio Listening to FM Radio Search for Saved Frequency(PRESET mode) Manually Save Frequency Press the PLAY butto n to display the PRESET sc reen. After finding the freq uency you wa nt, press and hold the MENU button to displa y Move to the frequenc y you want using butto n.

  • Page 23: Recording/Playback Fm Radio

    Listening to FM Radio Recording/Playback FM Radio Recording FM Radio Deleting All Saved Frequencies During the FM receiving, press and hold the REC butto n to start FM radio In the MENU mode, select F ILE MANAGE and p ress the MENU butto n. broadcasting.

  • Page 24: Menu Setting

    Music File Playback Menu Setting Press the MENU button sho rt to mo ve to the MENU mode. In the MENU mode, select the PLAY menu Press the butto n to move MENU item and press the MENU butto n short to select the me nu you want.

  • Page 25: Managing File

    Managing File Managing File Deleting File Formatting In the File Manage me nu, select File Delete and press the MENU button. In the File Manage me nu, select the Format and press the MENU button. Use the VOL+/- button to select the file to delete. Select CONFIRM with button a nd press the MENU button.

  • Page 26: Detailed Menu Setting

    Detailed Menu Setting Managing File In the MENU mode, select the Settings. Deleting Saved FM Radio Frequency Select the detailed me nu tha t you want to move using the butto n In the File Manage menu, select Preset Delete, and then press the MENU and then press the ME NU button.

  • Page 27: Playback Mode Setting

    Playback Mode Setting Sound Setting Select the Play Mode in the Settings. In the SE TTINGS menu, select SOUND. Select the sound mode you want with the VOL+/- butto n, and then press the Plays back all the songs in order only once MENU button.

  • Page 28: Sound Setting

    Sound Setting Display Setting A user can adjust up to 8 levels for eac h frequency dependi ng on its 5 areas. Select the DISPLAY in the SETTINGS. ◎ button to move horizontally and Select the detailed setting with VOL+/- button and press the MENU b utton. –...

  • Page 29: Timer Setting

    Timer Setting Display Setting Play Time Setting Select Timer in the Settings. Set the time that there appears on the display with the VOL+/- button. : displays the current playback time. NORMAL TIME Select the detailed items with VOL+/- button and then press the MENU button. : displays the remaining playback time.

  • Page 30: Encoding Setting

    Timer Setting Encoding Setting Current Time Setting In the Settings, select the Encoding. Press the MENU butto n to display the time setting screen. Select the detailed setting with VOL+/- button and press the MENU button. Set the AM/PM using VOL+/- button. Bit Rate Setting Set the encoding bit rate you want with button.

  • Page 31: Setting

    Setting Setting In the Settings, select the Mode Setting. Country Setting Set a la nguage of an applicable country. Select a language you want with VOL+/- b utton. Select the detailed item with V OL+/- button and then press the MENU button. If you set a language, the bandwidth of FM radio frequency of the applicable country will be changed too.

  • Page 32: About Battery

    Setting About Battery STUDY Function Setting How to Insert Battery ◎ You can the time with the button. 15, 30, 45, 60 seconds are a vailab le. Whe n the time is set and if you press the button d uring play, it will be played back from the time adding the time se t in the current playback time.

  • Page 33: Hold Setting Method

    HOLD Setting Method Troubleshooting If you think the player fails, check the fo llowings: ◎ If you use the func tion of hold, you can preve nt a mal-func tion by a button while ◎ the player is pla yed d uring player opera tion, including an unnecessary Power may be not turned on.

  • Page 34: Troubleshooting

    Specifications Troubleshooting No sound or noise is heard during the playback. Memory In-built memory 256MB / 512MB / 1GB / 2GB DISP LAY 128x64 OLED Two Color (Blue, Yellow) • Check if the music file is stored in the memory. MPEG 1/2/2.5 La yer3, WMA, ASF(Audio only), MP3 Encoding •...

  • Page 35: Service A/S

    2. You can receive free A/S’s for 1 year after the date of purchase of this product(even if it is within a wa rranty period, we may charge for repairing Website: www.ezmax.co .kr / www.ezo liver.com items that are not included in free services.).
  • Page 36 FCC Compliance THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED UNAUTHORIZED MODIFICATIONS TO THIS...

Table of Contents
