Ezmax EZMP-4100 User Manual

Digital audio player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Cop yright © 2005 EZMAX. All rights reserved.
Advance permission of EZMAX is required to use User's Guid e, photos,
the related documents a nd softwa re of the product. Any vio lation ma y
fo llow the legal mea sures.
The contents o f the Use r's Guide are subj ect to change without prior
notice for further improvement of the p roduct.
EZMAX
http://www .ezmax.co.kr

Table of Contents

Before U se
Product & Accessories ............... ..............2
PC System Requireme nts .......... ..............3
Safety Pre cautions ... .................. ..............4
Features . .................. ................. ...............5
Designation of Parts
Front/Rear View of the Product ... ..............7
Side View of the Produ ct ............ ..............8
Function Ic ons in Display............. ..............9
Preparation
Installing U SB Driver.. .................. ............10
Connecting Player to P C ............ ............12
Manually In stalling US B Driver.... .............13
Using Rem ovable Disk................. ............16
Disconnec ting USB Ca ble............ ............19
Upgrading Firmware... .................. ............21
Installing L DB Manage r ............. .............23
Using LDB Manager . .................. ............24
Basic F unctions
Basic Ope ration ........ .................. ............29
Power On/ Off ........... .................. ............32
Playback Music File .. .................. ............33
Using Navigation ................. .................. 36
Voice Recording/ Listening ... .................. 37
.. .................. 38
Listening to FM R adio ......... .................. 41
Using FM Transm itter .......... .................. 46
Fun ction Menu
Menu Setting .... .................. .................. 47
Music File Playback ............ .................. 48
Mana ging File . .................. ................. .49
Detai led Menu S etting ......... .................. 52
Playb ack Mode S etting ....... .................. 53
Soun d Setting ... .................. .................. 54
Displa y Setting .. .................. .................. 56
Timer Setting .... .................. .................. 58
Enco ding Setting ................. .................. 60
Settin g ............. .................. ................... 61
Others
Built-i n Battery C harging .... .................. .64
HOLD Setting Ho ld ............. .................. 65
Troub leshooting .................. .................. 66
Speci fications .... .................. .................. 68
Servic e (A/S) .... .................. .................. 69
Warra nty ........... .................. .................. 70
