ENMET Corporation
PO Box 979
Ann Arbor, MI 48106-0979
www.enmet.com
Manual Part Number
80003-500
MCN-13-002, 04/29/13
ISA-60M
with MRI-5175
O
PERATION AND
M
ANUAL
Andersen Medical Gas
12 Place Lafi fi tte
Madisonville, LA 70447
https://www.TheMedicalGas.com
https://www.Shop.TheMedicalGas.com
1-866-288-3783
M
AINTENANCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISA-60M and is the answer not in the manual?

Questions and answers

Summary of Contents for ENMET ISA-60M

  • Page 1 ENMET Corporation PO Box 979 Ann Arbor, MI 48106-0979 www.enmet.com ISA-60M with MRI-5175 PERATION AND AINTENANCE ANUAL Manual Part Number 80003-500 MCN-13-002, 04/29/13 Andersen Medical Gas 12 Place Lafi fi tte Madisonville, LA 70447 https://www.TheMedicalGas.com https://www.Shop.TheMedicalGas.com 1-866-288-3783...
  • Page 2: Table Of Contents

    1.3 Check Order ..................................1 1.4 Serial Numbers..................................1 2.0 Instrument Features .................................. 2 2.1 ISA-60M Exterior Features ..............................2 2.2 Display ISA-60M Front Panel Features ..........................2 2.3 MRI-5175 Exterior Features ..............................2 2.3 Circuit Board Features ................................. 4 3.0 Installation ....................................5 3.1 Mounting of Instrument ...............................
  • Page 3 Mounting Dimensions ..................5 EMOTE ENSOR Figure 5: ISA-60M Relay, Input and Output Terminals ..................... 6 Figure 5A: MRI-5175 Input and Output Terminals ....................7 Figure 6: ISA-60M Operational Display ........................9 Figure 7: ISA-60M Operation Menu Flow Chart ...................... 10 Figure 8: ISA-60M Maintenance Menu Flow Chart.
  • Page 4: Introduction

    The shipping company may offer optional insurance coverage. ENMET only insures shipments with the shipping company when asked to do so in writing by our customer. If you need your shipments insured, please forward a written request to ENMET Customer Service.
  • Page 5: Instrument Features

    The exterior and panel of the sensor/transmitter is shown in Figure 1. The MRI-5175 features are as follows: Feature Description Enclosure Fiberglass-reinforced polyester approximately 5” square, with non-magnetic hardware. Entrance for wiring to ISA-60M control unit Strain Relief Mounting Flanges Flanges with holes for mounting the enclosure to a vertical surface. MENU Switch...
  • Page 6: Figure 1: Isa-60M & Mri-5175 External Features

    Mounting Flanges 2 places Strain Relief Strain Relief Visual O2 Power/Fault LED Alarm LED MENU Power/Fault XXX %O2 by vol. Switch SELECT Switch Menu Select Sensor Audio Alarm (Optional) Mounting Flanges -XXXX 4 places Figure 1: ISA-60M & MRI-5175 External Features...
  • Page 7: Circuit Board Features

    (6 places) Digital Communication Terminals (3 types) Primary Detector Channel 1 Horn Terminal Aux Terminals Optional (2 places) Audio Fuse Holder Alarm Hole Plugs (2 places) Ground Screw J21 Power Input Terminal J23 Strain Relief Figure 2: ISA-60M Interior Features...
  • Page 8: Installation

    The holes in the flanges are 0.31 inch in diameter and form a 6 x 10.75 inch rectangle. See Figure 3. It is recommended to use #8 drywall anchors and screws for mounting the ISA-60M to a drywall/sheetrock surface. Non-magnetic mounting hardware is required for control panels located in the magnet room.
  • Page 9: Power Supply

    See Figure 1. Follow state and local guidelines when selecting appropriate strain relief, conduit and wiring. Remote Sensor: Each must be connected to a 4-20mA input inside the ISA-60M. UL listed type CM, PLTC or TC cable shall shielded be used for wiring between the MRI-5175 and the ISA-60M control panel.
  • Page 10: Isa-60M Relay Contacts

    ISA-60M ENMET Corporation Table 1: Wiring ISA-60M to MRI-5175 ISA-60M MRI-5175 Channel 1, J16 Channel 1, J4 D– +24V (1) Power +24V GND (2) Ground mA (3) Signal Channel 2, J18 Channel 2, J4 +24V Power +24V Ground Signal Channel 3, J19...
  • Page 11: 4-20Ma Outputs

    Wiring requirements are the same as for the relays. 3.4.4 Digital Outputs The RS232 & RS485 connections are used for firmware updates and digital communications. The ISA-60M is designed to operate as a modbus slave. Contact the ENMET for further information on wiring for the digital outputs.
  • Page 12: Operation

    4.1 Normal Operation Condition With the ISA-60M installed as described in Section 3, and in clean air, the POWER green LED is on, the display is lit, and the information on the display is as shown in Figure 6, for the sensor(s) installed in the ISA-60M. The red alarm and fault LEDs are not lit.
  • Page 13: Display

    D – Indicates alarm is in Differential Setting. Function (no D present) – Indicates alarm is in Standard Setting. vL17 vD17 Function ALARM1 Delays Alternating (Seconds) Function mASPAN 30.0 Function Enter Maint Menu Enter Password See Maintenance Menu Diagram Figure 7: ISA-60M Operation Menu Flow Chart...
  • Page 14: Maintenance

    : Never spray a cleaning solution on the surfaces of the ISA-60M or MRI-5175 devices. AUTION Clean the exterior of the ISA-60M and MRI-5175 enclosures with a mild soap solution on a clean, damp cloth. Do not soak the cloth with solution so that moisture drips onto, or lingers on, external surfaces.
  • Page 15: Set 4 -20Ma Transmitter Scale

    5.2.1 Set 4 –20mA Transmitter Scale This section of the maintenance menu is for aligning the external sensor/transmitters MRI-5175 to the ISA-60M controller. This function is normally performed at the factory and is not usually required in the field unless a new transmitter is installed.
  • Page 16: Isa-60M Controller

    11Liter Aerosol Gas Cylinder Assembly on Sensor Figure 9: Calibration MRI-5175 5.2.5 ISA-60M Controller Entering a valid password into maintenance menu, the Scale mA Xmtrs section is the second menu section, if it is installed, enter by pressing the S switch ELECT Press the SELECT switch "mA Xmter Scale: Select Ch1:O2"...
  • Page 17: Set Alarm Points

    OPTION Note: The Alarm 1 differential value is the delay of the ISA-60M staying in alarm condition until after the measured reading has returned past the alarm point by the differential value. Example: If the alarm set point is 19.5 and the differential is 2,...
  • Page 18 ISA-60M ENMET Corporation Example: Set Alarms Flow Chart Displays shown are factory default settings. Λ - O = Press Option Indicates alarm triggered on increasing value of reading S = Press Select Indicates alarm triggered on decreasing value of reading...
  • Page 19: Set Alarm "Delay On

    ISA-60M ENMET Corporation 5.2.7 Set Alarm “Delay On” The alarms may be set to delay activation by 1 second increments. Factory set default value is 5 seconds. After entering a valid password: Press the OPTION switch until; “Maintenance Menu Set Alarm Delay” appears on display.
  • Page 20: Failsafe Configuration

    The ISA-60M is factory set in a failsafe configuration. This means that if power is disconnected to the unit, or the relay fails to properly engage, it fails in such a way that it is in the alarm position. ENMET recommends leaving the relay in a failsafe configuration.
  • Page 21: Exit Maintenance Menu

    : Deactivated channels will not display or respond to connected sensor transmitters. AUTION A fault indication occurs when a transmitter is not connected to an active channel of the ISA-60M. To Activate or deactivate a channel of the ISA-60M: Enter the maintenance menu as described in Section 5.2 and press the switch until Exit maint menu appears.
  • Page 22: Maintenance Mri-5175

    This procedure is required for altitudes above 4500 ft (1372 meters). Due to the reduction of partial pressure at elevations above 4500 ft (1372 meters), the following procedure must be used when installing the ISA-60M monitor. Subsequent calibration should be done using the Standard calibration procedure as the compensation for partial pressure variances will have been accomplished.
  • Page 23: Figure 9: Calibration Mri-5175

    Menu Select (03620-021) SELECT Switch Flow Regulation Bellows Valve/Regulator 11Liter Aerosol Gas Calibration Cover Cylinder Assembly on Sensor : If the calibration process indicates a failure, wait 30 minutes and repeat process or contact ENMET Corporation. Figure 9: Calibration MRI-5175...
  • Page 24: Sensor Replacement

    ISA-60M ENMET Corporation 6.2 Sensor Replacement An Oxygen sensor must be replaced when it can no longer be calibrated. Typical sensor life is 3 to 5 years in a 20.9% oxygen environment. To replace a sensor, perform the following steps: Turn off the electrical power.
  • Page 25: Technical Data And Specifications

    ISA-60M ENMET Corporation 7.0 Technical Data and Specifications 15 Amp fused branch circuit Electrical Power 100-240 VAC 0.9 A 50/60 Hz Board Mounted Fuse FH2, 0.630A, 5 x 20mm (to also be included on shipping box) Storage and Transport Temperature: -20°...
  • Page 26: Replacement Part Numbers

    ENMET shall not be liable for any loss or damage caused by the improper use of the product. The purchaser indemnifies and saves harmless the company with respect to any loss or damages that may arise through the use by the purchaser or others of this equipment.
  • Page 27 734.761.1270 Fax 734.761.3220 Returning an Instrument for Repair ENMET instruments may be returned to the factory or any one of our Field Service Centers for regular repair service or calibration. The ENMET Repair Department and Field Service Centers also perform warranty service work.
  • Page 28 K UPS Account number: ________________________ K Federal Express: K Ground K Express Saver K P-1 K Standard K 2-Day Air K FedEx Account number: ________________________ Would you like ENMET to insure the return shipment? K No K Yes Insurance Amount: $_________________...
