Summary of Contents for Pollmeier SE Touch-to-open
- Page 1 Instruction manual Electric glass door lock Touch-to-open...
- Page 2 OPERATING INSTRUCTIONS Touch to open electric glass door lock Operating instructions draft | 09-2017_v1...
-
Page 3: Table Of Contents
Content 1 General 1.1 Performance Description as per the Building Product Ordinance 1.2 EC Declaration of Conformity 2 Description of the Electric Glass Door Lock 2.1 Technical Data 2.2 Function 3 Security 3.1 Intended Use 3.2 Unintended Use 4 Installation 4.1 Installation of the Door Hinges 4.2 Installing the Glass Door Lock 5 Operation and Maintenance... -
Page 4: General
OPERATING INSTRUCTIONS Touch to open electric glass door lock 1 General Please read through these operating instructions carefully before fitting or using the product. They contain important instructions on safety which help to avoid risks, errors and malfunctions. Keep the instructions in a safe place. The manufacturer's warranty is voided in any case of change, extension and modification (mechanical or electrical) of the electric glass door lock, opening the casing, or damage caused by use of force. - Page 5 Touch to open - EGS1 2. Intended use: Motorised actuation of the latch in single-leaf, interior glass doors 3. Manufacturer: Baugruppentechnik Pollmeier GmbH, Hövelrieger Str. 26, D-33161 Hövelhof 4. Authorised representative: . / . 5. System for evaluation and verification of performance: 6.
-
Page 6: Ec Declaration Of Conformity
1.2 EC Declaration of Conformity EC Declaration of Conformity BGP 09-2017 pursuant to the EC Machinery Directive 2006/42/EC Baugruppentechnik Pollmeier GmbH, Hövelrieger Str. 26, 33161 Hövelhof, Germany, hereby declares in sole responsibility that the following machine Designation: Touch to open electric... -
Page 7: Technical Data
2.1 Technical Data Electric glass door lock Outside of the hinge Emergency release On/off switch Electric glass door lock Inside of the hinge Emergency release catch Battery compartment Outside of the hinge door lock dimensions: Width: 145mm / depth: 15mm / height: 62mm Inside of the hinge door lock dimensions: Width: 129mm / depth: 15mm / height: 62mm Weight:... -
Page 8: Function
– The door weight must not exceed 60 kg. – Only use design trim panels licensed by Baugruppentechnik Pollmeier GmbH in conjuncti- on with the electric glass door lock as the function cannot otherwise be guaranteed (see section 7). -
Page 9: Unintended Use
Any use of the electric glass door lock other than the intended use will void your warranty. Baugruppentechnik Pollmeier GmbH accepts no liability for any damage caused in this way. For this reason, you must comply with the following directions: Caution! Use of the electric glass door lock in doors that are located on an identified escape and emergency route or in smoke or fire protection doors is... -
Page 10: Installation Of The Door Hinges
OPERATING INSTRUCTIONS Touch to open electric glass door lock 4.1 Installation of the Door Hinges Before fitting, check all parts for completeness and signs of damage. If you see any damage that could impair the lock's functionality, do not fit the lock under any circumstances! Fitting must be performed by a skilled person. - Page 11 the height of the grub screw in the sash hinge. Use the grub screws to secure the hinge pins against sliding out. 4. Remove the protective films from the adhesive strips on the inside of the cover caps "H" and stick the cover caps to the middle of the clamping plates.
- Page 12 OPERATING INSTRUCTIONS Touch to open electric glass door lock 4.2 Installation and Commissioning of the Glass Lock Before fitting, check all parts for completeness and signs of damage. If you see any damage that could impair the lock's functionality, do not fit the lock under any circumstances! Fitting must be performed by a skilled person.
- Page 13 4. Take the battery compartment connector and insert it upright into the socket on the electronic glass lock. The connector and socket are coded, allowing only one oppor- tunity to insert it (see Fig. 4). If the connector is not easy to insert, do not use force but rotate it once on its axis and and try again.
-
Page 14: Operation And Maintenance
OPERATING INSTRUCTIONS Touch to open electric glass door lock 5 Operation and Maintenance An acoustic signal will indicate any need to intervene during operation or installation. The following overviews show the various audible signals and their meanings. All audible signals during installation Type of audible signal Operating state Request... -
Page 15: Troubleshooting
If it proves impossible to resolve the problem, please remove the lock and contact Baugrup- pentechnik Pollmeier GmbH. Expert staff is available to help you. -
Page 16: Emergency Release
OPERATING INSTRUCTIONS Touch to open electric glass door lock 5.2 Emergency Release Emergency door release is not necessary in normal operation and with proper use. Safety mechanisms have been installed in the lock that provide for automatic unlocking if normal operation is compromised. -
Page 17: Cleaning
5.3 Cleaning Due to protected installation and the wear-free design, cleaning is only rarely required. To clean, wipe the lock and the strike plate with a dry cloth. Do not use chemicals, cleaning agents, solvents or objects for mechanical cleaning! Carefully remove any metal chips on the latch or strike plate with a soft cloth or a brush. -
Page 18: Removal & Disposal
OPERATING INSTRUCTIONS Touch to open electric glass door lock the front of the lock. If the screw heads on the back of the trim panel engage in the keyhole-shaped openings in the lock, push the design trim panel in the direction of the glass edge and it will noticeably engage (see Fig.
