- Page 1 Instruction manual Electrically operated mortise lock Touch to open...
- Page 2 OPERATING INSTRUCTIONS Touch to open electric mortise lock Original operating instructions | 06-2017_v1...
-
Page 3: Table Of Contents
Content 1 General 1.1 Performance Description as per the Building Product Ordinance 1.2 EC Declaration of Conformity 2 Description of the Electric Door Lock 2.1 Technical Data 2.2 Hole Drawings 2.3 Function 3 Security 3.1 Intended Use 3.2 Unintended Use 4 Installation 4.1 Fitting the Mortise Lock with Closing Button (Optional) 4.2 Fitting the Mortise Lock Without Closing Button... -
Page 4: General
• Countersunk screw, fully threaded 4.5 x 30 - T20 • Countersunk screw, fully threaded 3.5 x 25 - T15 Parts required for fitting: • SE-certified door handle from the BGT Pollmeier GmbH supply program (see section 7) Optional accessories: • Closing button... -
Page 5: Performance Description As Per The Building Product Ordinance
Touch to open - EES2 2. Use: Motorised actuation of the latch in single-leaf, interior wooden doors 3. Manufacturer: Baugruppentechnik Pollmeier GmbH, Hövelrieger Str. 26, D-33161 Hövelhof 4. Authorised person: . / . 5. System for evaluation and verification of performance: 6. -
Page 6: Ec Declaration Of Conformity
1.2 EC Declaration of Conformity EC Declaration of Conformity BGP 01-2017 pursuant to the EC Machinery Directive 2006/42/EC Baugruppentechnik Pollmeier GmbH, Hövelrieger Str. 26, 33161 Hövelhof, Germany, hereby declares in sole responsibility that the following machine Designation: Touch to open... -
Page 7: Technical Data
2.1 Technical Data Electrically operated mortise lock Strike plate 11,2 12,1 13.8 Door lock dimensions: Width: 84 mm / depth: 20 mm / height: 209 mm Strike plate dimensions: Width: 8.4 mm / depth: 20 mm / height: 120 mm Weight: 443 g incl. batteries / 397 g without batteries Protection class: IP 20 Power supply:... -
Page 8: Hole Drawings
OPERATING INSTRUCTIONS Touch to open electric mortise lock 2.2 Hole Dimensions Hole milling dimensions for mortise lock 20.2... - Page 9 Milling dimensions for closing button Hole depth up to lock mortise Ø 11.5** * Only applies to honeycomb filling and tubular inlay. With solid wood: Ø 12 mm...
-
Page 10: Function
– The door weight must not exceed 100 kg. – Only use handles licensed by Baugruppentechnik Pollmeier GmbH in conjunction with the electric mortise lock as the function cannot otherwise be guaranteed (see section 7). – Always use the same handle design on both sides of the door. -
Page 11: Unintended Use
3.2 Unintended Use Any use of the electric mortise lock other than the intended use will void your warranty. Baugruppentechnik Pollmeier GmbH accepts no liability for any damage caused in this way. For this reason, you must comply with the following directions: Caution! Use of the electric mortise lock in doors that are located on an identified... -
Page 12: Fitting The Mortise Lock With Closing Button (Optional)
OPERATING INSTRUCTIONS Touch to open electric mortise lock 4.1 Fitting the Lock with Closing Button Before fitting, check all parts for completeness and signs of damage. If you see any damage that could impair the lock's functionality, do not fit the lock under any circumstances! Fitting must be performed by a skilled person. - Page 13 4. Now insert the four-pin connector upright into the socket on the electronic mortise lock. The connector and socket are coded, allowing only one opportunity to 4,5 x 30 insert it (see Fig. 2). If the connector is not easy to insert, do not use force but rotate it once on its axis and and try again.
-
Page 14: Fitting The Mortise Lock Without Closing Button
OPERATING INSTRUCTIONS Touch to open electric mortise lock 4.1 Fitting the Mortise Lock Without Accessories Before fitting, check all parts for completeness and signs of damage. If you see any damage that could impair the lock's functionality, do not fit the lock under any circumstances! Fitting must be performed by a skilled person. -
Page 15: Inserting Batteries
4.2 Inserting Batteries Caution! Never insert an empty battery holder into the lock. On closing the door, the lock would immediately engage; in this case, opening is only possible via emergency release. 1. Insert four new 1.5 V AAA Micro Alkaline batteries into the compartment. -
Page 16: Operation And Maintenance
OPERATING INSTRUCTIONS Touch to open electric mortise lock 5 Operation and Maintenance An acoustic signal will indicate any need to intervene during operation or installation. The following overviews show the various audible signals and their meanings. All audible signals during installation Type of audible signal Operating state Request... -
Page 17: Troubleshooting
5.1 Troubleshooting If the lock unexpectedly fails to work, first check the following points: Malfunction Possible cause Possible solution Lock beeps twice Batteries exhausted Replace batteries (see 5.4) periodically approx. every 5 min. and the latch remains in the lock Noise on opening/closing Foreign body on latch or in strike Clean, carefully remove object (see 5.3) -
Page 18: Emergency Release
Touch to open electric mortise lock If it proves impossible to resolve the problem, please remove the lock and contact Baugrup- pentechnik Pollmeier GmbH. Expert staff is available to help you. 5.2 Emergency Release Emergency door release is not necessary in normal operation and with proper use. Safety mechanisms have been installed in the lock that provide for automatic unlocking if normal operation is compromised. -
Page 19: Cleaning
In the event of emergency, if you cannot remove the door handle on the inside of the hinge, prise open the door, applying serious force around the handle area (see Fig. 3, p. 12). With 1 kN of force, the safety clip on the latch will yield and the door will open (see Fig. 4, p. 12). - Page 20 OPERATING INSTRUCTIONS Touch to open electric mortise lock attention to correct polarity (see Fig. 2) 3. You can then insert the battery holder into the lock and close by applying light pressure; the holder latches audibly. Fig. 2 4. Before the lock is ready for use, it needs to calibrate.
-
Page 21: Removal & Disposal
6 Removal and Disposal To remove the door, switch off the lock, remove the handle and, using suitable tools, remove the screws from the lock and the strike plate. You can now remove the parts from the door or the frame. Then remove the batteries as described in section 4.2. Caution! Never store the lock for an extended period of time with the batteries fitted.
