- Page 1 Getting started Electrically operated mortise lock Touch-to-open...
- Page 2 Getting started Electronically operated touch-to-open mortise lock Components Planum SE handle set* SE lock * The number and type of components may vary depending on the handle set.
- Page 3 Prior to installation Installation step 1 Carefully read the instruction manual! Drill/mill holes for handle installation Instruction manual Electrically operated mortise lock Touch-to-open NOTE: refer to the separately enclosed handle guide for the dimensions! M A D E I N G E R M A N Y . www.smart-entrance.de...
- Page 4 Getting started Electronically operated touch-to-open mortise lock Installation step 2 Installation step 3 Install the locking plate and the packing Install the lock without battery compartment NOTE: turn the packing to vary the clearance of the safety catch by 1 mm and adapt the contact pressure.
- Page 5 Installation step 4 Installation step 5 Install the handle Insert 4 x AAA 1.5 V micro alkaline batteries NOTE: please refer to the separately enclosed NOTE: ensure correct polarity! handle guide for instructions on handle installation! www.smart-entrance.de...
- Page 6 Getting started Electronically operated touch-to-open mortise lock Installation step 6 Installation step 7 Switch on the lock and close the door within 10 Insert the battery compartment seconds after the audible signal B e e p...
- Page 7 Installation step 8 Installation step 9 Open the SE handle within 20 seconds of the last, Do not touch the SE handle for 20 seconds during slightly longer beep. the calibration process. 9 x be ep The lock is now ready for operation. www.smart-entrance.de...
- Page 8 09.2016_v1...
