- Page 1 COM100-B COM Express Carrier Board User’s Manual A26130901 Chapter 1 Introduction www.dfi .com...
-
Page 2: Copyright
Copyright FCC and DOC Statement on Class B This publication contains information that is protected by copyright. No part of it may be re- This equipment has been tested and found to comply with the limits for a Class B digital produced in any form or by any means or used to make any transformation/adaptation without device, pursuant to Part 15 of the FCC rules. -
Page 3: Table Of Contents
Table of Contents USB Ports................18 Audio ..................19 I/O Connectors ..............19 S/PDIF Connector ..............19 Copyright ..........2 Cooling Fan Connectors ............. 20 Digital I/O Connector ..............20 Trademarks ..........2 LVDS LCD Panel Connector ............21 LCD/Inverter Power Connector ........... 21 FCC and DOC Statement on Class B ..2 SATA (Serial ATA) Connector ............. -
Page 4: Warranty
Warranty Static Electricity Precautions 1. Warranty does not cover damages or failures that arised from misuse of the product, It is quite easy to inadvertently damage your PC, system board, components or devices even inability to use the product, unauthorized replacement or alteration of components and before installing them in your system unit. -
Page 5: About The Package
About the Package The package contains the following items. If any of these items are missing or damaged, please contact your dealer or sales representative for assistance. • One COM100-B board • One SATA data cable • One SATA power cable •... -
Page 6: Chapter 1 - Introduction
Chapter 1 Chapter 1 - Introduction Specifications Graphics • Display ports Supported COM • Mini form factor - 1 DisplayPort Express Module - 1 24-bit single channel LVDS Damage Free • Legacy Super I/O support (optional) Intelligence - Monitors 5V/1.5V/12V/3.3V Audio •... -
Page 7: Chapter 2 - Hardware Installation
Chapter 2 Chapter 2 - Hardware Installation Block Diagram Board Layout Smart Battery Charger SIO_Fan PCIE x1 GLAN DC-in System_Fan Jack Panel Power Select (JP14) PCIE Audio Codec Mini PCIE x1 LVDS LCD Panel Backlight Brightness Power Select SATA 3.0 Switch 5 (JP19) COM 1... -
Page 8: Mechanical Drawing
Chapter 2 Mechanical Drawing 10.16 0.00 22.86 44.14 91.14 154.94 159.84 Chapter 2 Hardware Installation www.dfi .com... -
Page 9: Jumper Settings
Chapter 2 USB Mode Select Jumper Settings USB Power Select USB 0,1 (JP3) 1-2 On: +5V (default) USB 2,3,4,5 (JP2) 2-3 On: +5V_standby JP11 JP3 (for USB 0,1) and JP2 (for USB 2,3,4,5) are used to select the power of USB ports. Select- ing +5V_standby will allow you to use a USB keyboard to wake up the system. -
Page 10: Clear Cmos
Chapter 2 Clear CMOS Mini PCIe3 Signal Select 1-2, 4-5, 7-8, 10-11 On: Mini PCIe 1-2 On: Normal (default) JP12 2-3 On: Clear CMOS 2-3, 5-6, 8-9, 11-12 On: mSATA (default) The JP12 is used to select the Mini PCIe signal. If you encounter the following situations, you can reconfigure the system with the default values stored in the ROM BIOS. -
Page 11: Mini Pcie3 Power Select
Chapter 2 Mini PCIe3 Power Select Panel Power Select 2 4 6 JP14 1-2 On: +12V 2 4 6 3-4 On: +5V 2 4 6 1-2 On: +3.3V 5-6 On: +3.3V JP13 (default) (default) 2-3 On: +3.3V_standby The JP14 is used to select the power supplied with the LCD panel. The JP13 is used to select the power supplied with the Mini PCIe. -
Page 12: Vcc5_In Power Select
Chapter 2 VCC5_In Power Select Super I/O Enable/Disable 1-2 On: 5VSB 1-2 On: Enable (default) 2-3 On: Disable (default) 3-4 On: 5V 5-6 On: NC The JP4 is used to select the power of the COM Express connectors. The JP5 is used to enable or disable the selection of Super I/O. Chapter 2 Hardware Installation www.dfi... -
Page 13: Lcd/Inverter Power Select
Chapter 2 LCD/Inverter Power Select BIOS Select 2 4 6 1-3 On, 2-4 On: Module SPI BIOS 2 4 6 JP18 1-2 On: +12V (default) JP20 3-5 On, 2-4 On: 2 4 6 2-3 On: 1-3 On, 4-6 On: Carrier SPI0 2 4 6 The JP20 is used to determine the BIOS boot device. -
Page 14: Dc-In Voltage Level
Chapter 2 DC-in Voltage Level Backlight Brightness Power Select 1 On, 2, 3, 4 Off: JP19 1-2 On: +5V (default) 2 On 1, 3, 4 Off: 12V (default) 3 On 2-3 On: +3.3V 1, 2, 4 Off: 4 On 1, 2, 3 Off: N.C. -
Page 15: Lvds/Edp Signal Select
Chapter 2 LVDS/eDP Signal Select Dimming Mode Select JP22 1-2 On: PWM Mode (default) JP10 1-2 On: eDP 2-3 On: Voltage Mode 2-3 On: LVDS (default) The JP22 allows you to select the mode for the lightness control of the LVDS panel. The JP10 is used to select the display signal between eDP and LVDS. -
Page 16: Rear Panel I/O Ports
Chapter 2 Rear Panel I/O Ports 5V~19V DC-in USB 2.0 2,3,4,5 COM 1 Line-in/Surround DC-in Line-out Mic-in/ Center+Subwoofer DC-in jack COM 2 DisplayPort USB 3.0 The rear panel I/O ports consist of the following: • 1 5V~19V DC-in jack • 2 Serial COM ports •... -
Page 17: Serial (Com) Ports
Chapter 2 Serial (COM) Ports DisplayPort COM 1 COM 2 COM 1 and COM 2: RS232 DisplayPort DisplayPort is a digital display interface used to connect a display device such as a computer The serial COM ports are RS232 asynchronous communication ports with 16C550A-compatible monitor. -
Page 18: Rj45 Lan Port
Chapter 2 RJ45 LAN Port USB Ports USB 0 USB 1 USB 3.0 USB 2 USB 3 USB 4 USB 5 USB 2.0 The USB device allows data exchange between your computer and a wide range of simultane- ously accessible external Plug and Play peripherals. The onboard RJ45 LAN port allows the system board to connect to a local area network by means of a network hub. -
Page 19: Audio
Chapter 2 Audio I/O Connectors S/PDIF Connector Line-in/Surround Line-out Mic-in/ Center+Subwoofer S/PDIF SPDIF out Front Audio Ground SPDIF in Rear Audio The S/PDIF connector is used to connect external S/PDIF port. Your S/PDIF port may be The system board is equipped with 3 audio jacks. A jack is a one-hole connecting interface for mounted on a card-edge bracket. -
Page 20: Cooling Fan Connectors
Chapter 2 Digital I/O Connector Cooling Fan Connectors Power Ground Sense SIO Fan Ground Power Sense System Fan The 8-bit Digital I/O connector (4-bit GPI and 4-bit GPO) provides powering-on function to external devices that are connected to these connectors. The pin functions of the Digital I/O connector are listed below: Pin Assignment Pin Assignment... -
Page 21: Lvds Lcd Panel Connector
1. To switch output display signal between LVDS and eDP, use JP10. Please refer to the "LVDS/eDP Signal Select" of the "Jumper Settings" section for more information. 2. DFI board's LVDS connector P/N: 346-714000-204G Description: WTB HEADER 40P, 1.25mm, M, H=4.8mm, 180D, SMT, BEIGE, 712-76-40GWE0 (PRINEX) RoHS Chapter 2 Hardware Installation www.dfi... -
Page 22: Sata (Serial Ata) Connector
Chapter 2 SATA (Serial ATA) Connector LPC connector 14 13 5VSB SERIRQ CLK_48M LAD2 LAD3 FRAME# LAD0 RST# LAD1 SATA 3.0 The Serial ATA connector is used to connect Serial ATA device. Connect one end of the Serial The Low Pin Count Interface was defined by Intel Corporation to facilitate the industry’s tran- ®... -
Page 23: Expansion Slots
Chapter 2 Expansion Slots Mini PCIe Slot The Mini PCIe socket is used to install a Mini PCIe card. Mini PCIe card is a small form factor PCIe card with the same signal protocol, electrical definitions, and configuration definitions as the conventional PCIe. -
Page 24: Front Panel Connector
Chapter 2 Front Panel Connector Pin Pin Assignment Pin Pin Assignment PWR-LED N.C. LED Power N.C. HDD Power LED Power HD-LED Signal Signal ATX-SW Signal Ground RESET Ground RST Signal N.C. N.C. RESET HD-LED Front Panel PWR-LED ATX-SW HD-LED - HDD LED This LED will light when the hard drive is being accessed. -
Page 25: Com Express Connector
Chapter 2 COM Express Connector COM Express Connectors (Type 10) The COM Express connectors are used to interface the carrier board with a COM Express board. Refer to the following pages for the pin functions of these connectors. Chapter 2 Hardware Installation www.dfi... - Page 26 Chapter 2 Chapter 2 Hardware Installation www.dfi .com...
-
Page 27: Switches
Chapter 2 Switches Serial Interface Connector Serial Interface 0/1 (Rx/Tx) The serial interface connector is used for 2 serial ports supported by Tx and Rx signals. Power Sleep Reset Note: The Sleep and Lid functions are supported only when your operating system supports ACPI. -
Page 28: I 2 C Connector
Chapter 2 C Connector SMBus Connector N.C. N.C. C_Clock C_DATA 3V3 Standby SMBus The 1-channel I C bus interface conforms to the version 2.1 I C bus specification. It operates as a master or slave device and supports a multi-master bus. 3V3SB SMB_CLK SMB_DATA... -
Page 29: Hdd Power Connector
Chapter 2 HDD Power Connector Battery Ground Ground +12V HDD Power Battery The lithium ion battery powers the real-time clock and CMOS memory. It is an auxiliary source of power when the main power is shut off. The HDD power connector supplies power to the SATA drive. Connect one end of the provided Safety Measures power cable to the HDD power connector and the other end to your storage device. -
Page 30: Smart Battery Charger Connector
Chapter 2 Smart Battery Charger Connector Standby Power LED Smart Battery Charger Connector Standby Power LED This LED will lit red when the system is in the standby mode. It indicates that there is power on the system board. Power-off the PC then unplug the power cord prior to installing any de- The smart batery charger connector is used for the function of power management and vices. -
Page 31: Edp (Embedded Displayport) Connector
Chapter 2 eDP (Embedded DisplayPort) Connector Pins Function Pins Function N.C. eDP Panel PWR N.C. eDP_Lane_3- eDP_Lane_3+ eDP_Lane_2- eDP_Lane_2+ eDP Hot Plug eDP GND eDP_Lane_1- eDP GND eDP_Lane_1+ eDP GND eDP GND eDP_Lane_0- Panel Backlight On/Off Control eDP_Lane_0+ Panel Inverter Brightness Voltage Control N.C. -
Page 32: Chapter 3 - Supported Software
Audio Driver Please download drivers, utilities and software applications required to enhance the perfor- To install the driver, download “COM100-B Audio Driver” zip file at our website. mance of the system board at https://www.dfi.com/product/index/240#download . 1. Setup is ready to install the driver.
