- Page 1 COM333-I COM Express Carrier Board User’s Manual Preliminary Version A47100832 Chapter 1 Introduction www.dfi .com...
-
Page 2: Copyright
Copyright FCC and DOC Statement on Class B This publication contains information that is protected by copyright. No part of it may be re- This equipment has been tested and found to comply with the limits for a Class B digital produced in any form or by any means or used to make any transformation/adaptation without device, pursuant to Part 15 of the FCC rules. -
Page 3: Table Of Contents
Table of Contents BMC SPI1 Interface Mode Select ..............16 BMC 2nd Boot Watchdog Timer Select ............16 BMC MAC#1 Interface Type Select .............. 17 BMC VGA Select ..................17 Rear Panel I/O Ports ................. 18 Copyright ......................2 Graphics Interface ..................18 COM (Serial) Ports .................. -
Page 4: Warranty
Warranty Static Electricity Precautions 1. Warranty does not cover damages or failures that arised from misuse of the product, It is quite easy to inadvertently damage your PC, system board, components or devices even inability to use the product, unauthorized replacement or alteration of components and before installing them in your system unit. -
Page 5: About The Package
About the Package The package contains the following items. If any of these items are missing or damaged, please contact your dealer or sales representative for assistance. • One COM333-I board • One Serial ATA data cable (Length: 500mm) Optional Items •... -
Page 6: Chapter 1 - Introduction
Chapter 1 Chapter 1 - Introduction Specifications ENVIRONMENT Temperature Operating: 0 to 60°C EXPANSION Interface B1: 2 x PCIe x4 or 1 x PCIe x8 (Gen 3) B2: 2 x PCIe x4 or 1 x PCIe x8 (Gen 3) Storage: -40 to 85°C B3: 2 x PCIe x4 or 1 x PCIe x8 (Gen 3) Humidity Operating: 5 to 90% RH... -
Page 7: Chapter 2 - Hardware Installation
Chapter 2 Chapter 2 - Hardware Installation Board Layout BMC UART1 Port Mode Select (JP30) COM 2 BMC UART1 Driver’s/Receiver’s eSPI Female HDR Power Rail Select (JP31) Debug Battery SPI Flash BIOS Disable BMC UART1 2 3 4 System System Fan2 Fan1 LC4064ZE... -
Page 8: Function Test Jumper
Chapter 2 Function Test Jumper Jumper Settings Battery Low Indicator USB Power Select 2 3 4 2 3 4 USB 3.0 Ports 2,3 (JP2) USB 3.0 Ports 0,1 (JP1) 1-2 On: Battery low test 1-2 On: +5V (default) 1-2 Off: Normal (default) 2-3 On: +5VDU This jumper is used to simulate the signal status that indicates the external battery is low. -
Page 9: Usb 2.0 Port 3 Select
Chapter 2 USB 2.0 Port 3 Select 10G PHY Capability Select 2 3 4 1-2 On: MDIO only (default) 2 3 4 2-3 On: 1-3, 2-4 On: MDIO or I USB 2.0 Port 3 to Rear I/O Connector 1-2 On: MDIO only 3-5, 4-6 On: (default) -
Page 10: Pcie Lane Select
Chapter 2 PCIe Lane Select PCIe Lane 12 Select 2 3 4 2 3 4 1-2, 4-5, 7-8, 10-11 On: PCIe Lane 12 to BMC JP18 (default) JP10 JP14 JP11 JP15 JP12 JP16 2-3, 5-6, 8-9, 11-12 On: PCIe Lane 12 to Multiplexer JP13 JP17 (Refer JP11 also) -
Page 11: Tpm_Pp On Cb Select
Chapter 2 TPM_PP on CB Select ESPI- Enable Select 2 3 4 2 3 4 1-2 On: 1-2 On: LPC BUS Enable (default) JP20 JP21 2-3 On: 2-3 On: Off (default) ESPI- BUS Enable The JP20 is used to select to turn on or off the TPM_PP on CB. The JP21 is used to select to enable LPC BUS or ESPI- BUS. -
Page 12: Bios Boot Location Select
Chapter 2 BIOS Boot Location Select PIN 0~3 DIO Output/Input Select 2 3 4 2 3 4 JP22 2-3 On, JP23 2-3 On: SPI0 on Module (default) 2-3, 5-6, 8-9, 11-12 On: LED on (default) JP23 JP22 2-3 On, JP23 1-2 On: SPI0 on Carrier JP22 1-2, 4-5, 7-8, 10-11 On:... -
Page 13: Vcc5_In Power Select
Chapter 2 VCC5_IN Power Select ATX/AT Mode Select (Power_OK) 2 3 4 2 3 4 1-2 On: PWR_OK from ATX PS PWR_OK JP26 (default) 1-2 On: +5V_standby (default) JP27 2-3 On: PWR_OK from BMC GPO 3-4 On: +5V 1-X: No PWR_OK when in AT Mode 5-6 On: NC The JP27 allows you to select the PWR_OK connection state when setting power at ATX or AT The JP26 is used to select the power rail for module VCC5_IN pins when in ATX or AT mode. -
Page 14: Ps_On Select
Chapter 2 PS_ON Select Clear CMOS JP29 2 3 4 2 3 4 1-2 On: Normal (default) 1-2 On: ATX Mode Auto PWR_ON 2-3 On: (default) JP28 Clear CMOS 2-3 On: AT Mode Always ON The JP28 allows you to select the ATX mode auto power on or AT mode always on. If you encounter the following situations, Note: a) CMOS data becomes corrupted. -
Page 15: Bmc Uart1 Port Mode Select
Chapter 2 BMC UART1 Port Mode Select BMC UART1 Driver’s/Receiver’s Power Rail Select JP31 JP30 1-2 On: 1-2 On: 2 3 4 3V3 (Normal) 2 3 4 Normal UART 2-3 On: 3VDU (debug) 2-3 On: (default) Debug mode (default) The JP31 is used to select the driver’s/receiver’s power rail of the BMC UART1. The JP30 is used to select the mode of BMC UART1 port. -
Page 16: Bmc Spi1 Interface Mode Select
Chapter 2 BMC SPI1 Interface Mode Select BMC 2nd Boot Watchdog Timer Select 2 3 4 2 3 4 To select BMC SPI1 interface mode, please use pins 1 and 2 of finger switch SW1. To enable or disable BMC 2nd boot watchdog timer, please use pin 3 of finger switch SW1. BMC 2nd Boot Watchdog Timer Select SW1 Pin 3 BMC SPI1 Interface Mode Select... -
Page 17: Bmc Mac#1 Interface Type Select
Chapter 2 BMC MAC#1 Interface Type Select BMC VGA Select 2 3 4 2 3 4 1-2 On: Disable VGA 1-X On: Normal VGA/2D (default) This jumper is used to disable BMC integrated VGA. To select BMC MAC#1 interface type, please use pin 4 of finger switch SW1. BMC MAC#1 Interface Type Select SW1 Pin 4 RMII/NCSI... -
Page 18: Rear Panel I/O Ports
Chapter 2 Rear Panel I/O Ports Graphics Interface The display port consists of the following: 1G RJ-45 1G MGMT BMC UART1/Debug 10G RJ-45 • 1 VGA port LAN 1 LAN 3,4 2 3 4 10G SFP+ USB 3.0 USB 3.0 LAN 1,2 The rear panel I/O ports consist of the following: •... -
Page 19: Com (Serial) Ports
Chapter 2 COM (Serial) Ports BMC UART 1/Debug COM1 COM2 DCD- COM 2 BMC UART1/Debug 2 3 4 COM 1 1 2 3 4 5 DTR- 6 7 8 9 DSR- BMC UART1: RS232 RTS- CTS- The serial ports are asynchronous communication ports with 16C550A-compatible UARTs that can be used with modems, serial printers, remote display terminals, and other serial devices. -
Page 20: Lan Ports
Chapter 2 LAN Ports USB Ports 2 3 4 2 3 4 1G RJ-45 LAN 1 1G MGMT LAN USB 2,3 USB 0,1 10G SFP+ LAN 2 USB 3.0 10G RJ-45 LAN 4 10G RJ-45 LAN 3 10G SFP+ LAN 1 USB allows data exchange between your computer and a wide range of simultaneously acces- sible external plug-and-play peripherals. -
Page 21: I/O Connectors
Chapter 2 Digital I/O Connector I/O Connectors LPC Connector 2 3 4 2 3 4 The 8-bit Digital I/O connector (4-bit GPI and 4-bit GPO) provides powering-on and control functions to the connected external devices. The pin functions of the connector are listed as the followings: The Low Pin Count Interface was defined by Intel Corporation to facilitate the industry’s... -
Page 22: Sata (Serial Ata) Connectors
Chapter 2 SATA (Serial ATA) Connectors Cooling Fan Connectors 2 3 4 2 3 4 Power System Fan 1 Sense Ground System Fan 2 SATA 3.0 SATA 0 SATA 1 The Serial ATA connectors are used to connect Serial ATA devices. Connect one end of the Se- The fan connectors are used to connect cooling fans. -
Page 23: I 2 C Header
Chapter 2 C Header SMBus Header 2 3 4 2 3 4 C_DATA C_Clock 3V3 DU SMBUS_Data SMBus 3.3V DU SMBUS_CLK SMBUS_Alert# The 1-channel I C bus interface conforms to the version 2.1 I C bus specification. It operates The SMBus (System Management Bus) connector is used to connect the SMBus device. It is a as a master or slave device and supports a multi-master bus. -
Page 24: Power Connectors
Chapter 2 Power Connectors Battery +12V Ground 2 3 4 Ground +12V 2 3 4 12 24 Battery +3.3VDC Connector +12VDC +5VDC +12VDC +5VDC +5VSB +5VDC PWR_OK +5VDC +5VDC PS_ON# +3.3V +3.3VDC -12VDC +3.3VDC +3.3VDC Use a power supply that complies with the ATX12V Power Supply Design Guide Version 1.1. An ATX12V power supply unit has a standard 24-pin ATX main power connector that must be inserted into the 24-pin connector. -
Page 25: Front Panel Connector
Chapter 2 Front Panel Connector Pin Assignment Pin Assignment 2 3 4 N.C. LED Power N.C. HDD Power PWR-LED LED Power HD-LED Signal Signal Ground Ground ATX-SW RESET RST Signal Signal N.C. N.C. 12 11 Front Panel ATX-SW RESET HD-LED PWR-LED HD-LED - Hard Drive LED This LED will light when the hard drive is being accessed. -
Page 26: Expansion Slots
Chapter 2 Expansion Slots COM Express Connectors 2 3 4 2 3 4 COM Express Connectors (Type 7) PCIe 5 (PCIe x4) PCIe 9 (PCIe x4) PCIe 1 (PCIe x8) PCIe 6 (PCIe x4) PCIe 10 (PCIe x4) PCIe 2 (PCIe x8) PCIe 11 (PCIe x4) PCIe 7 (PCIe x4) PCIe 3 (PCIe x8) - Page 27 Chapter 2 Row A Row B Row C Row D GND (FIXED) GND (FIXED) GND (FIXED) GND (FIXED) GBE0_MDI3- GBE0_ACT# GBE0_MDI3+ LPC_FRAME#/ESPI_CS0# USB_SSRX0- USB_SSTX0- GBE0_LINK100# LPC_AD0/ESPI_IO_0 USB_SSRX0+ USB_SSTX0+ GBE0_LINK1000# LPC_AD1/ESPI_IO_1 GBE0_MDI2- LPC_AD2/ESPI_IO_2 USB_SSRX1- USB_SSTX1- GBE0_MDI2+ LPC_AD3/ESPI_IO_3 USB_SSRX1+ USB_SSTX1+ GBE0_LINK# LPC_DRQ0#/ESPI_ALERT0# GBE0_MDI1- LPC_DRQ1#/ESPI_ALERT1# USB_SSRX2-...
- Page 28 Chapter 2 Row A Row B Row C Row D USB0+ USB1+ 10G_PHY_MDC_SCL0 10G_PHY_MDIO_SDA0 VCC_RTC ESPI_EN# 10G_INT0 10G_INT1 RSVD USB0_HOST_PRSNT GBE0_SDP SYS_RESET# 10G_KR_RX0+ 10G_KR_TX0+ LPC_SERIRQ/ESPI_CS1# CB_RESET# 10G_KR_RX0- 10G_KR_TX0- GND (FIXED) GND (FIXED) GND (FIXED) GND (FIXED) PCIE_TX5+ PCIE_RX5+ PCIE_RX16+ PCIE_TX16+ PCIE_TX5- PCIE_RX5- PCIE_RX16-...
- Page 29 Chapter 2 Row A Row B Row C Row D SPI_POWER NCSI_CLK_IN PCIE_RX28+ PCIE_TX28+ SPI_MISO NCSI_RXD1 PCIE_RX28- PCIE_TX28- GPO0/SD_CLK (opt.) NCSI_RXD0 SPI_CLK NCSI_CRS_DV PCIE_RX29+ PCIE_TX29+ SPI_MOSI NCSI_TXD1 PCIE_RX29- PCIE_TX29- TPM_PP NCSI_TXD0 TYPE10# SPI_CS# RSVD RSVD SER0_TX NCSI_ARB_IN PCIE_RX30+ PCIE_TX30+ SER0_RX NCSI_ARB_OUT PCIE_RX30- PCIE_TX30-...
-
Page 30: Sdio (Optional)
Chapter 2 SDIO (optional) Switches 2 3 4 2 3 4 BMC AST2500 Chip Level Reset BMC AST2500 SOC Level Reset Reset Sleep Power SDIO (optional) Note: This expansion port is used to insert a Secure Digital Input/Output (SDIO) or Multimedia Card The Sleep and Lid functions are supported only when your operating system supports (MMC) device. -
Page 31: Leds
Chapter 2 LEDs Inphi Configure Pin-Plug 2 3 4 Debug LED 2 3 4 BMC AST2500 Heart Beat LED Indicator LED for Non-Type 7 Module Inserted Indicator LED for Type 7 Module Inserted Indicator LED for Type 6 Module Inserted CS4227 SDA (1.8V) CS4227 SCL (1.8V) Thermal Trip LED... -
Page 32: Espi Female Header
Chapter 2 eSPI Female Header eSPI Female Header 2 3 4 The eSPI female header is reserved for future EXT-module. Chapter 2 Hardware Installation www.dfi .com...
