- Page 1 i-Q350LX PCE SensorSMART™ Installation and Operation Manual...
- Page 2 IDENTEC SOLUTIONS shall not under any circumstances be liable to any person for any special, incidental, indirect or consequential damages, including without limitation, damages resulting from use of or reliance on information presented herein, or loss of profits or revenues or costs of replacement goods, even if informed in advance of the possibility of such damages.
- Page 3 The user(s) of these products are cautioned to only use accessories and peripherals approved, in advance, by IDENTEC SOLUTIONS. The use of accessories and peripherals, other than those approved by IDENTEC SOLUTIONS, or unauthorized changes to approved products, may void the compliance of these products and may result in the loss of the user(s) authority to operate the equipment.
- Page 4 ATEX Certification Equipment or protected system intended for use in potentially explosive atmosphere directive 94/9/EC. Compliance with the essential health and safety Requirements has been assured by compliance with the following standards: EN 60079-0:2012, EN 60079-11:2012 EPS 14 ATEX 1 668 X Ex ia IIC T4 II 1 G -20°C ≤...
- Page 5 This product contains components that are sensitive to electrostatic discharges. Please observe the special instructions for their protection. Incorrect handling can damage the unit and cause the invalidation of the warranty. Minimum safety precautions against electrostatic discharge: Establish earth contact before you touch the unit. For example, touch the earthing screw on the unit. Even better: Use an antistatic ribbon and earth yourself permanently for the time you handle the unit.
-
Page 6: Table Of Contents
Contents SAFETY INSTRUCTIONS ....................7 PREFACE ........................9 2.1........................ 9 REPARATIONS 2.2....................9 COPE OF OCUMENT 2.3......................9 ESPONSIBILITY 2.4........................9 PDATES 2.5. —V ................9 COPE OF ELIVERY ISUAL NSPECTION 2.6....................9 SSOCIATED OCUMENTS INTRODUCTION ...................... -
Page 7: Safety Instructions
The system described in this manual is for exclusive operation of trained employees. Only qualified personnel that have knowledge of the potential dangers involved should perform the installation, settings, maintenance and repair of the units used. Operational Safety The correct and safe use of these systems assumes that operating and service personnel follow the safety measures described in the manual alongside the generally acceptable safety procedures. - Page 8 If it is necessary to check the isolating properties of the field wiring, the assemblies (electronic units and sensors) should be disconnected. Earth the test units. IDENTEC SOLUTIONS does not accept the return of products where the regulations concerning the ESD precautions and protective packaging materials were not followed. ESD – Electrostatic Discharge EMC –...
-
Page 9: Preface
IDENTEC SOLUTIONS reserves the right to make changes and updates to the content contained herein. It is the user’s responsibility to contact the service department for any possible changes or updates to operating and maintenance procedures. -
Page 10: Introduction
The IDENTEC SOLUTIONS’ SensorSMART Platform is the latest development in asset management, localization and process optimization. Developed to deliver the last mile in industrial communication, the SensorSMART Platform fulfills a niche not previously addressed by available networks. The SensorSMART Platform takes the complexity out of managing assets, personnel safety monitoring and/or the tracking of valuable cargo and the need for multiple technologies. -
Page 11: System Components -Sensors
The SensorSMART Platform infrastructure features mobile readers (i-CARD), fixed readers (i-PORT) and exciters (i-MARK). Network sensors offer the highest functionality within the SensorSMART Platform. Robust and reliable, SMARTsensors monitor temperature, humidity, light, shock, tilt, motion, push button, digital input, Hall sensor, etc. The SDK (software development kit) is an easy to use framework that allows developers high level access without requiring in depth knowledge of sensor or reader protocols, timing or implementations. -
Page 12: System Components -Readers
IDENTEC SOLUTIONS’ antennas are distinguished by their compact design. A variety of antennas can be used, depending on application. The antennas are differentiated by characteristics such as polarization, apex angle, and gain. -
Page 13: Linear Polarized Antennas
Orientation Diagrams: Elliptical polarized antenna Elevation Azimuth For this antenna, the maximum transmit power setting is: A-9185: -8 dBm 3.5.2. Linear Polarized Antennas Because of the smaller apex angle (60º), this antenna is more suited to selective data collection and restriction of read zones. Depending on the direction of mounting, the antenna’s field is either vertically or horizontally polarized, requiring the sensor to have the same orientation. - Page 14 Orientation Diagrams: Linear polarized antenna Elevation Azimuth Vertical Polarization Horizontal Polarization Antenna Orientation For this antenna, the maximum transmit power setting is: W-900R: -12 dBm...
-
Page 15: 1/2-Wave Whip Antenna
3.5.3. 1/2-Wave Whip Antenna Dimensions Orientation Diagrams Elevation Azimuth Vertical Polarization Horizontal Polarization For this antenna, the maximum transmit power setting is: Rod antenna: -3 dBm... -
Page 16: 1-Wave Rod Antenna
3.5.4. 1-Wave Rod Antenna Overall Dimensions: 425 × 90 mm Mounting proposal Antenna diagram vertical For this antenna, the maximum transmit power setting is: Rod antenna: -3 dBm... -
Page 17: Tag Mounting Techniques
Tag Mounting Techniques Dimensional Drawing Side view to assembled tag Metal holder All dimensions in mm. Assembly and mounting The tag is delivered already preassembled and there is no need to disassemble the tag when metal band mounting is used. If however the screw mounting option is used, contact your local IDENTEC representative to ask for procedure and special tool. -
Page 18: Tag Identification
Now the lower aluminum part can be mounted either mounted to a flat surface by using screws (blue arrows) or onto a piped by using a metal strap (red arrow). After mounting the aluminum part, the tag and the aluminum holder can be assembled. Use the special tool and tighten the tag clockwise in the aluminum part. -
Page 19: Initial Operation, Configuration Of The Tag
Important Note Do not open the housing! Configuration is done using the built-in air interface of the i-Q350. The Response mode of the i-Q350 offers the following features for configuration: Broadcast mode can be configured for simultaneous operation. In this case the tag responds to commands from a reader as well as broadcasts configurable data in a regular interval. -
Page 20: Ping Rate
Note: These settings can be found in the Tag Configuration software tool in the section “Broadcast” Active: Activates or de-activates the broadcast function that regularly sends out messages. Broadcast Interval: 0 = no broadcast messages are sent, value > 0 = Broadcast interval in seconds. This can be set in steps of 0.5 sec, from 0.5 sec up to 300 sec. - Page 21 Example This example shows 3 tags (A, B, C) that are simultaneously triggered by a marker loop (LF marker) and are configured to burst 3 times. The timeslot (Time between Bursts) is set to the default value of 40 ms. The last row shows how the random use of the timeslot avoids collision between the tags.
-
Page 22: Maintenance
When installed correctly the SensorSMART System will operate virtually maintenance free for many years. However, in the event maintenance is required only trained and authorized personnel are permitted to perform the updates, changes and maintenance necessary. Remove dust with a brush or compressed air. If there are fatty or oily substances use a soft cloth moistened with a mild rinsing agent. -
Page 23: Returns
Parts or main components returned for repair or exchange must be handled with great care. PC cards must be returned in the appropriate ESD-protecting packaging material. Please follow the RMA policy under: http://cdn.identecsolutions.com/wp-content/uploads/2012/06/IMS_PD-OPS- 014_Hardware_Return_and_Repair_Policy_03e.pdf Return to: IDENTEC SOLUTIONS AG Service Department Millennium Park 2 6890 Lustenau AUSTRIA... -
Page 24: Technical Data
Communication Broadcast 350 Operation Mode Transmits Sensor ID and user data in pre-defined interval Read Range up to 100m (330ft) Compatibility i-PORT M350, i-CARD CF 350 and i-PORT 4-350 Operating Frequency 868 MHz (EU) or 920 MHz (NA) Transmit Power <1mW Communication Response 350 Operation Mode... - Page 25 Mechanical Data Dimensions 53mm x 23.5mm ( 2.09 in x 0.93 in) Enclosure Material Steel holder, Plastic enclosure Enclosure Rating IP 67 & IP69k Weight 60 grams (2.1 ounces) Order Code i-Q350LX PCE 455492...
