Arrim ONE USER MANUAL (iOS)

Quick Start

Turn on / off Arrim ONE
Press on/off Switch to turn on Arrim ONE
Press on/off Switch for 3 seconds to turn off Arrim ONE. And it will be automatically shut off in 3
minutes after last measurement.
Charging
Use the Micro-USB charging cable in the package to charge Arrim ONE. When it is charging, blue
LED is on.
It takes one hour to fully charge Arrim ONE. You can check the battery status in Arrim ONE app.
Arrim ONE has over-charge protection, so it will not be damaged if it is charged for longer.
Laser Status
OFF
Rest
Activated
No light. Arrim ONE is off.
Dim light. Arrim ONE is turned on, but no connected to mobile
device via bluetooth
Bright Red. Arrim ONE is turned on and connected, ready to go.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Arrim ONE and is the answer not in the manual?

Questions and answers

Related Manuals for AR Arrim ONE

Summary of Contents for AR Arrim ONE

  • Page 1: Quick Start

    Quick Start Turn on / off Arrim ONE Press on/off Switch to turn on Arrim ONE Press on/off Switch for 3 seconds to turn off Arrim ONE. And it will be automatically shut off in 3 minutes after last measurement. Charging Use the Micro-USB charging cable in the package to charge Arrim ONE.
  • Page 2 1. Download Arrim ONE app to your mobile device. • Please search Arrim ONE on Apple App Store, and download it. Arrim ONE supports iPhone 6S or later, and iPad 2017 or later. Please check the entire compatible list in Appendix.
  • Page 3 • Insert Arrim ONE to the mobile device. Laser is facing out. If your phone case is too thick to fit Arrim ONE, you can use an adapter as the extension. The adapter can also allow the Arrim ONE be compatible with both iOS device and Android device with Type -C port.
  • Page 4 • Arrim ONE connects the mobile device via Bluetooth, so please make sure your mobile device’s bluetooth is turned on. You can go to Setting / Bluetooth to turn it on. • Open Arrim ONE app. When you first time open Arrim ONE, it will ask permission to access the Camera. Please click “OK”...
  • Page 5 • Press on/off switch on the rear end to turn on Arrim ONE. PRESS HERE • Arrim ONE will be connected automatically with the mobile device via Bluetooth. The laser will be on, and you can see a bright red laser dot.
  • Page 6 • To achieve better accuracy, Arrim ONE requires a calibration before measuring. Just aim the laser to a wall / floor, and make sure the distance between Arrim ONE and wall / floor is between 2 ft - 9 ft (0.5 m - 3 m), and tap the calibration button on the right bottom...

  • Page 7: User Interface

    Function & Setting Tap to enter Function & Setting, you can select different functions, set unit system/format and check the Arrim ONE battery status Measure Tap to define a virtual point, which is at same location of laser dot in real world.
  • Page 8 Function & Setting Interface...
