Section 1 - FAMILIARIZATION

CLUTCH
CABLE
COVER
DASH
PANEL
HANDLE
BRACKET
DEPTH
BAR
TINE
COVER
STARTER ROPE
DRAG
SHIELD
MAIN CASE
FILL PLUG
TINE
1.1 INTRODUCTION: This manual covers the recommended operating procedure and routine service
requirements on SNAPPER Intermediate Rear Tine Tiller. It is recommended that all operators of this Tiller
become thoroughly familiar with the controls and proper operation of the unit before operating. Specific
details involving the engine are found in the separate engine owner's manual. Study these manuals before
operating and keep both handy for future reference. Refer to Figure 1 above for location of controls and
other essential components.
HANDLEBAR
WHEEL & TINE
CONTROL BAIL
WHEEL & TINE
SHIFT LEVER
TIRE & WHEEL
TRANSMISSION
CHAIN CASE
FIGURE 1
ENGINE
SPEED
CONTROL
CHOKE
CONTROL
FUEL SHUT
ENGINE
OFF VALVE
AIR
FILTER
HONDA ENGINE CONTROLS
CHOKE
CONTROL
4
FUEL
SHUT OFF
VALVE
ENGINE
SPEED
CONTROL
OIL DRAIN
PLUG
WEIGHT
BOX
STAND-UP
BAR
ENGINE
DRIVE
BELT
GUARD
ENGINE OIL
CHECK/FILL
PLUG
