Connection Diagram - Sony BRAVIA 43XG83 Series Reference Manual

Connection Diagram

For more information on connections, refer to the Help Guide by pressing HELP on the remote control.
Conditional Access
Module
VCR/Video game equipment/DVD
player/Camcorder/External Box*²
*1
DVD player with
component output
Audio System with HDMI
Optical Audio Input Device
Digital still camera/
Camcorder/USB storage
media
Headphone/Audio
System/Subwoofer
Digital still camera/
Camcorder/USB storage
media/USB HDD device
HDMI Device
Audio System with ARC/
HDMI Device
HDMI Device
IR Blaster
Router
< 14 mm
Cable/Antenna/External
Box
Satellite
< 7 mm
< 1.5 mm
GB
7
GB
