Step 6; See Figure 6:
Install right and left Rear Posts (10 & 11)
and right and left Rear Boxing Posts (12 & 13).
NOTE: When properly installed Rear Post
latch plates will face forward with the notch to
the outside
.
A. Insert a 1/4" x 3/4" bolt outwards through the
Rear Cross Bar, right Rear Post and then the
right Boxing Post,. Add a nut. Tighten enough
to keep the parts upright.
B. Repeat step 6A on the left side with left
Posts.
Step 7; See Figure 7:

Install Top Frame (14)

A. Place the top frame onto the bent ends of
the posts.
B. Insert eight bolts up through the Rear
Boxing Posts, the Rear Posts, Top Frame
Braces and the Front Posts. Add nuts. Do not
tighten at this time.
11
13
Figure 6
Figure 7
10
12
14
