LOG

Pressing the SEL button while viewing the LOG Lead-in screen accesses the dive log. The log stores Information from the latest 24 Dive and/or
Gauge mode dives for viewing.
> If no dives are recorded, the message NONE YET 0 DIVE will be displayed in the log.
> After exceeding 24 dives, the most recent dive is stored while the oldest is deleted.
> Dives are numbered from 1 to 24 starting each time a dive is activated in either Dive (or Gauge) mode. After the post dive 24 hour period has
elapsed and the unit shuts off, the first dive of the next activation period will be recorded as dive #1.
> I n the event that dive time (DIVE-T) exceeds 999 min, the data at the 999 interval is recorded in the Log upon surfacing of the unit.
NOTE: New data will automatically overwrite the oldest data in memory when the memory becomes full. The Veo 4.0 Log and
Diverlog + Download data is stored separately in different partitions of the memory. The Log only stores a short summary of
each dive. Alternately, the Diverlog + Download function stores much larger files for each dive. For this reason, it is normal to
see dives stored in the Veo 4.0's onboard Log that have already been overwritten in the Diverlog + Download Partition. If you
do not remember to log or download your dives, they will be lost when the memory overwrites. See the Diverlog + Download
section of this manual for instructions on downloading dives.
next item in
Main Menu
max tissue loading,
blank if Gauge
dive
max depth
highest PO
2
reached during
the dive
© Pelagic, 2019
LOG LEAD-IN
access
log
LOG DATA 1
pre dive Surface Interval
hr:min, - : - - if first dive during
the activation period
max ascent
rate
Dive Time,
max 999 min
to Data 2
LOG DATA 3
% O
2
at end of dive, - - if the dive
entered Violation Gauge
Mode
gas mix
FO (% O
2
back to
Main Menu
blank if DIVE,
or GAUGE icon
for Gauge dive
blank or VIO
for a violation
dive
next dive
recorded
lowest
temperature
Saturation
)
2
NOTE: Log Data 3 only displays for nitrox dives; it is
bypassed if the dive was an air dive.
19
VEO 4.0 OPERATING MANUAL
LOG PREVIEW
date
of dive
time dive
started
dive #
enter dive
record
LOG DATA 2
recorded elevation of
dive location,
SEA (or EL 2 - EL7)
to Data 3
or back to
Log Preview
