Antigravity Batteries VTX20 User Manual

16-volt
Hide thumbs

Advertisement

Quick Links

Download this manual
ANTIGRA VITY BA TTERIES
VTX20
16-VOL T
USER MANUAL
FOR RACE USE ONL Y
2019

Advertisement

loading
Need help?

Need help?

Do you have a question about the VTX20 and is the answer not in the manual?

Questions and answers

Related Manuals for Antigravity Batteries VTX20

Summary of Contents for Antigravity Batteries VTX20

  • Page 1 ANTIGRA VITY BA TTERIES VTX20 16-VOL T USER MANUAL FOR RACE USE ONL Y 2019...
  • Page 2 16-VOL T USER MANUAL CONTENTS: INTRODUCTION SAFETY WARNINGS PRODUCT MODELS Page 1 PRODUCT SPECS CHARGING Page 2 INSTALLATION Page 3 BATTERY CARE & MAINTENANCE TROUBLESHOOTING Page 4 WARRANTY Page 5 CONTACT INFO Page 6 DANGER! IMPORTANT SAFETY INSTRUCTIONS. PRIOR TO USE, READ AND UNDERSTAND PRODUCT SAFETY INFORMATION AND THIS USER MANUAL.

  • Page 3: Thank You

    GUIDELINES Please read all WARNINGS before installing this battery! Antigravity Batteries Lithium-Ion Starter Batteries offer great performance benefits such as massive weight reduction, much higher cranking power, and longer service life than Lead/Acid batteries. They can improve the performance of your vehicle due to the weight reduction, stable voltage and better starting performance. But they are different from Lead/Acid in a few key areas.
  • Page 4 16-VOL T USER MANUAL IMPORTANT! READ FIRST! DANGER! READ AND FULLY UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT. Failure to follow these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, or FIRE, which may result in a SERIOUS INJURY, DEATH, or PROPERTY DAMAGE. Shock.
  • Page 5 ACCESSORIES This product is only approved for use with Antigravity Batteries accessories. Antigravity Batteries is not responsible for user safety or damage when using accessories not approved by Antigravity Batteries. LOCA TION Make sure product is installed correctly.
  • Page 6 THE BA TTERY The built-in lithium-ion battery in the product should be replaced or serviced only by Antigravity Batteries, and must be recycled or disposed of separately from household waste. Do not attempt to service or replace the battery yourself and do not handle a damaged or leaking lithium-ion battery.

  • Page 7: Specifications

    16-VOL T USER MANUAL VTX-20 Models VTX-20-L VTX-20-r LefT negaTiVe TerminaL righT negaTiVe TerminaL Specifications BATTERY TYPE: Lithium Iron-Phosphate (LifePo4) VOLTAGE: 16V (nominal) CASE FORMAT: YTX12 CAPACITY and CRANKING AMPS: see battery label DIMENSIONS: 5.9 x 3.43 x 5.12 inches WEIGHT: 5 lbs MAX CHARGING RATE:...
  • Page 8 Batteries for suggestions on a Charger for your use, or visit our website. Antigravity Batteries 16-Volt Batteries are only for Race Use. Antigravity Batteries will not warranty the use of 16-Volt batteries in Custom Race and/or Total Loss systems. 16-Volt Antigravity Batteries are not to be used in 12-Volt vehicle Systems.
  • Page 9 CHECKING THE BA TTERY Antigravity Batteries do not require maintenance for the most part if they are kept in a good state of charge, but as with any battery, they should be checked once every few months, or weeks as a precaution. Visually inspect the product for any cracks, check the mounting is secure, and check the voltage.

  • Page 10: Troubleshooting

    16-VOL T USER MANUAL Troubleshooting SLUGGISH PERFORMANCE ON INITIAL ST ART IN VERY COLD WEA THER This is a normal effect of Lithium-Ion due to increased “resistance” in very cold weather. The battery is not damaged. A Lithium battery can be self warmed by either a couple quick engagements of the starter, such as a short blip on the starter button, or a short turn of the key to engage the starter for a second only, or by leaving the vehicle lights on for 1-3 minutes.
  • Page 11 REPLACEMENT Antigravity Batteries are only eligible for one warranty replacement of a battery. Once a battery has been repaired or replaced under warranty, the replacement item only holds the remainder of the warranty period from the date of the original purchase of the battery, and covers only physical defects.
  • Page 12 16-VOL T USER MANUAL Warranty (Continued) REGISTERING YOUR BA TTERY You must register your Antigravity Battery product in order to validate the Limited Warranty. You can register the product Online at our Registration page. Complete the requested information and click “send”. Contact Us When you need help or have questions, our knowledgeable support team is here for you! Please feel free to call us during our Office Hours 7:30am-4pm Pacific Time, Monday-Friday;...
