- Page 1 Innoband SC00 Innoband Sense Commander (Z-Wave / Ethernet Wireless Gateway) User Manual Version 0.1...
- Page 2 User Manual Innoband SC00 Information in this document is subject to change without notice and does not represent a commitment on the part of Innoband Technologies, Inc. The software described in this document is furnished under a license agreement and may be used or copied only in accordance with the terms of the license agreement. It is against the law to copy the software on any other medium except as specifically allowed in the license agreement.
-
Page 3: Table Of Contents
....................5 LED Descriptions (TBD) ..................6 Install your new device ..................7 Install the Hardware ................... 7 Create User Account at Sense Cloud..............7 Log Into Sense Commander ................. 8 Log Into Sense Cloud Server ................11 Perform Z-Wave Device Inclusion..............12 Perform Z-Wave Device Exclusion ..............14... -
Page 4: Getting Started
This Sense Commander is designed to control the Z-Wave devices when it's properly connected to an Ethernet network. This Ethernet network can be a LAN (local area network) or WAN (wide area network). -
Page 5: Physical Outlook
Devices can be removed from the Z-Wave network by a similar “Exclusion” process of button strokes. Summary: Function Description Inclusion Add a Z-Wave device (e.g. Dimmer) to Z-Wave network Exclusion Remove a Z-Wave device (e.g. Dimmer) from Z-Wave network Reset Restore Sense Commander to factory default... -
Page 6: Led Descriptions (Tbd)
LED Descriptions (TBD) The table below provides a summary of LED functions. Please refer to applicable user’s guides on applicable Z-Wave devices for inclusion and exclusion procedures. Function Description LED & Siren Status Power Indicate if the unit is properly LED: solid green powered Ethernet... -
Page 7: Install Your New Device
Install your new device Innoband’s SC00 Sense Commander gateway is designed for dry indoor environment only. Please follow these steps below to properly set up the unit. Install the Hardware 1. Unpack Sense Commander from the package. 2. Use the supplied Ethernet cable and connect the Commander’s Network port to an available port on the home network’s Ethernet Router. -
Page 8: Log Into Sense Commander
Log Into Sense Commander 1. If applicable, turn on a computer that is wire or wirelessly connected to the same Ethernet router. 2. Download the gateway discovery utility application at: http://www.innobandsense.com/images/SenseDiscovery.rar http://www.innobandsense.com/images/SenseDiscovery.zip. 3. Open the downloaded file, run Setup.exe to install the application on the computer. - Page 9 browser (such as Internet Explorer, Google Chrome, Apple Safari, FireFox) on the computer. In the URL field, enter the Gateway IP address found using the utility above.) 10. When prompted, enter ‘admin’ as the User Name and leave the Password field blank, and click on ‘Log In”.
- Page 10 15. Click the “Reset” button and proceed with resetting the gateway. Wait until it’s completed. 16. Click on the “Gateway Setting” tab. 17. Replace the default account and password with the New Account created earlier at www.innobandsense.net. Click ‘Save’, and then ‘Exit’. 18.
-
Page 11: Log Into Sense Cloud Server
3. On the Sign in page, select ‘Use existing account’ and enter the new account’s information, click ‘Log in’. 4. If a green “Found New Gateway Version” banner is displayed on the upper right of the screen, a newer firmware is available for download and installed on Sense Commander. -
Page 12: Perform Z-Wave Tm Device Inclusion
6. Look for the count down on the screen to complete. 7. At the completion of the count down, your Sense Commander gateway will be up to date. Click on ‘Back to Home’ to return to the main menu. - Page 13 press and hold the Inclusion button (item #1 on page 5) on the Commander until the In/Exclusion LED start blinking in red. This allows the Commander to enter into “inclusion mode” for 30 seconds. 5. Secondly, on the Z-Wave device, configure the device into ‘inclusion mode’ by pressing and releasing the programming / inclusion / tamper switch quickly 3 consecutive times.
-
Page 14: Perform Z-Wave Tm Device Exclusion
1. Install the batteries into the Z-Wave device, or connect it to a wall outlet. 2. Make sure the Z-Wave device to be paired with the Sense Commander is no more than 3 feet from the Commander. (The Z-Wave device can be moved to its permanent location after the ‘inclusion’... -
Page 15: Using Sense Commander
Using Sense Commander PC Browser App 1. Launch a new browser session on a computer. 2. In the URL field, enter www.innobandsense.net. 3. On the Sign in page, select ‘Use existing account’ and enter the account’s information, click ‘Log in’. -
Page 16: Run And Edit Scenes
When finished, click on ‘X’ to return to the ‘View Events’ page. 6. When the sensor status changes (i.e. door is opened, motion sensor detects movement), the devices shown in the ‘View Events’ page will be shown in red. Run and Edit Scenes 1. - Page 17 2. To program a scene, log into www.innobandsense.net and click on ‘Run / Edit Scene’ on the main menu. 3. Click on ‘Add Scene’ button on the lower left. 4. Input the desired name in the ‘Scene Name’ text box. Click on the ‘Add Command’ to add the first sensor action.
- Page 18 ‘Passive’ sensor devices such as motion sensor or window sensor will not be shown on the list.) 6. Once a device is selected, a list of available commands will be shown. Select the desired command for the sensor device from the list of commands. 7.
-
Page 19: Define And Configure Triggers
Define and Configure Triggers 1. There are times where a series of commands need to be carried out when a certain ‘condition’ is met. For example, the siren should sound when a door is opened, or when movement is detected by the motion sensor. These conditions can be defined under the ‘Trigger’... - Page 20 4. Input the desired name in the ‘Trigger Name’ text box. 5. Select the desired notification method under the Notify dropdown box. 6. Click on the ‘Add Command’ to add the first triggering condition. 7. Under the ‘When’ section, select the desired device, the desired command, and value. 8.
-
Page 21: Android App
Android App 1. Download the Innoband Sense Android app by searching for ‘Innoband’ in the Google Play Store. 2. Upon installation, launch the Innoband Sense app. 3. Log in using the account created. 4. From the main menu, view device status or control the individual sensor device in the ‘View Events’... -
Page 22: Troubleshooting
Troubleshooting Symptom Possible Cause Recommendation Device Inclusion Device has been paired with Perform device exclusion cannot be completed another gateway. procedure, then repeat the inclusion process again. The Siren is defective Contact Innoband for product support and RMA... -
Page 23: Certifications
Certifications This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 24 Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being. When replacing old appliances with new once, the retailer is legally obligated to take back your old appliance for disposal at least for free of charge.
-
Page 25: Warranty
Warranty Innoband warrants that equipment furnished will be free from defects in material and workmanship for a period of one year from the confirmed date of purchase of the product new from the retail location. Upon written notice of any such defect, the manufacturer will, at its option, repair or replace the defective item under the terms of this warranty, subject to the provisions and specific exclusions listed herein. - Page 26 Registration Card Innoband SC00 Registration Name: Company: Address: City/State/Zip: Phone: E-mail: Serial Number: Purchased from: Date of Purchase: Please cut out the above Product Registration Card and send in with a self-addressed stamped envelope Innoband Technologies, Inc. 2526 Qume Dr. Ste 21...
-
Page 27: Contact Information
Contact information We would more than love to help if you have further technical questions, please visit our Website at http://www.innoband.com or send E-mail to support@innoband.com Company Address Innoband Technologies, Inc 2526 Qume Dr. Ste 21 San Jose, CA 95131...
