Operation

Mode Functions

Scrolling Through the Mode Function
By scrolling through the Mode function, you will be able to select or turn on
preferred features of your microTALK
Mode function, your radio features will be displayed in the same
predetermined order:
Channel
Mode Button
VOX on/off
VOX sensitivity
CTCSS code setting 38 codes for setting
DCS code setting
Note: * Only Channels 1 to 8 are available by default. Channels 9 to 16
need to be activated by user before they can be selected.
Channels 9 to 16 should only be used in countries where these
frequencies are allowed by government authorities.

Privacy Codes

Your microTALK ® radio incorporates two advanced coded squelch systems
that can help to reduce interference from other users on any given channel.
CTCSS (Continuous Tone Coded Squelch System) provides 38 privacy codes
and DCS (Digitally Coded Squelch) provides 83 privacy codes. This provides
a total of 121 Privacy Codes. Either system can be used on all channels, but
both systems cannot be used on the same channel at the same time.
For ease of use and to reduce interference from other users, the 16 channels
of your radio have been customized, see Channel and Default Privacy
Code Table.
7
radio. When scrolling through the
®
16 channels with default privacy code*
On or off shown on LCD
5 levels
83 codes for setting
Channel and Default Privacy Code Table
Channel Freq.(MHz)
1 446.00625
2 446.01875
3 446.03125
4 446.04375
5 446.05625
6 446.06875
7 446.08125
8 446.09375
9 446.10625
10 446.11875
11 446.13125
12 446.14375
13 446.15625
14 446.16875
15 446.18125
16 446.19375
You can change your radio Privacy Codes in order to work with other
radios with different privacy codes or radio without privacy codes. See
page 9 and 10 for procedures.
Note: *Only Channels 1 to 8 are available by default. Channels 9 to 16
need to be activated by user before they can be selected.
Channels 9 to 16 should only be used in countries where these
frequencies are allowed by government authorities.
Privacy Code
Type Number
DCS 1
DCS 11
DCS 22
DCS 33
DCS 44
DCS 55
DCS 66
DCS 77
DCS 1
DCS 11
DCS 22
DCS 33
DCS 44
DCS 55
DCS 66
DCS 77
