1. INTRODUCTION
SV-iP5A/iV5 inverter can be controlled and monitored by the sequence program of the PLC or other
master module. The option card provides a terminal block for an RS-485/Modbus-RTU interface. Drives or
other slave devices may be connected in a multi-drop fashion on the RS-485/Modbus-RTU network and
may be monitored or controlled by a single PLC or PC.
1.1. Features
Inverter can be easily applicable to Factory Automation because operation and monitoring is available by
User-program.
* Parameter setting and monitoring is available via computer.
(Ex: Freq. Command, Run/Stop etc.)
* Interface type of RS485 reference:
1) Allows the drive to communicate with any other computers.
2) Allows one computer to control up to 31 drives with multi-drop link system.
3) Noise-resistant interface.
Users can use any kind of RS232/485 converters. The specifications and performances of converters
depend on the manufacturers, but the basic functions are the same. Refer to the converter manual for
detailed specifications and instructions on how to use.
1.2.

Before Installation

Before installation and operation, this manual should be read thoroughly. If not, it could cause personal
injury or damage other equipment.
2. SPECIFICATION
2.1.

Performance specification

Communication method
Transmission form
Applicable inverter
Converter
Number of inverters connected
Transmission distance
note1)
The number of inverters to be connected is up to 31.
note2)
The specification of length of the communication cable is max. 1200m. To ensure stable
communication, limit its length below 700m.

2.2. Hardware Specifications

Items
Installation
Power Supply
Items
Use option connector on the inverter control board
Control B/D From inverter power supply
Comm. B/D From control board (insulated)
Specifications
RS485 (RS232/485 converter)
Bus method, Multi-drop Link System
SV-iP5A/iV5 series
Converter with RS232 card embedded
Maximum 31 drives connectable
Max. 1200m (Less than 700m recommended)
Specifications
2
note1)
note2)
