<<< Switching >>>
This device is true bypass and uses electronic relay-based switching. Audio will not pass
without power.
<<< Power Requirements >>>
• Current Draw: 76mA
• This device take a standard 9 volt DC power supply with a 2.1mm negative center barrel. We
always recommend pedal-specific, transformer-isolated wall-wart power supplies or multiple
isolated-output supplies. Pedals will make extra noise if there is ripple or unclean power.
Switching-type power supplies, daisy chains and non-pedal specific power supplies do not filter
dirty power as well and let through unwanted noise. DO NOT RUN AT HIGHER VOLTAGES!
<<< Tech Specs >>>
• Input Impedance: 1M Ohm
<<< Warranty >>>
This device has a limited lifetime warranty. If it breaks, we will fix it. Should you encounter any
issues, please email info@earthquakerdevices.com.
www.earthquakerdevices.com
©2018 EarthQuaker Devices LLC
• Output Impedance: <1K Ohm
O P E R A T I O N M A N U A L
Advertisement
Related Manuals for EarthQuaker Devices Transmisser
Summary of Contents for EarthQuaker Devices Transmisser
- Page 1 This device has a limited lifetime warranty. If it breaks, we will fix it. Should you encounter any issues, please email info@earthquakerdevices.com. www.earthquakerdevices.com O P E R A T I O N M A N U A L ©2018 EarthQuaker Devices LLC...
- Page 2 It does not do spring. It does not do a wood paneled rumpus room with 1" thick carpet. Darkness: This controls the tone of the It will not recreate the classic sounds of the 60’s, 70’s and 80’s. The Transmisser will create an reverberated signal; darker clockwise, lighter ultimate soundscape-y backdrop to your all-night guitar freak-out.
