- Page 1 ® ® Help Alert Emergency Call ® Solutions Staff Duress Pendant User Guide PN 0510-0332-A Released 05/07/09 Users must read this Guide before using the Product. ® 3125 North 126th Street, Brookfield, WI 53005 Phone: 800.669.9946 Web: www.rft.com...
- Page 2 Copyright 2009 by RF Technologies, Inc. All Rights Reserved. No Part of this work may be reproduced or copied in any form or by any means without written permission from RF Technologies, Inc.
- Page 3 Compliance Federal Communication Commission (FCC) Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.
- Page 4 RF Technologies, Inc. for all installations. Failure to use the components and supplies specified by RF Technologies, Inc. may result in equipment and/or system failure. SYSTEM MAINTENANCE AND TESTING—It is the responsibility of the facility to establish and facilitate a regular maintenance schedule for your system.
-
Page 5: Table Of Contents
Introduction ....... 1 Help Alert E-Call Solution ....1 Intended Audience . - Page 6 Contents This page intentionally left blank. Staff Duress Pendant (0510-0332-A) - User Guide...
-
Page 7: Preface
The Help Alert E-Call Solutions allow doctors, nurses and other staff members to discreetly send a distress call when assistance is needed. The Help Alert software is displayed on a monitor with the facility floor plan visible for accurate location notification. -
Page 8: Additional Detailed Documentation
RF Technologies Technical Publications team at techpubs@rft.com. Product Warranty Product Warranty information can be found on the Help Alert E-Call Solution Documentation CD-ROM or with your original system proposal and invoice. Staff Duress Pendant (0510-0332-A) - User Guide... -
Page 9: Chapter 1 Using And Staff Duress Pendant
Chapter 1 Using and Staff Duress Pendant Introduction The Staff Duress Pendant is a wireless, mobile device that allows staff members to discreetly send a distress call when assistance is needed. When the system receives the call, the facility floor plan is displayed on the monitor for accurate location data. The Staff Duress Pendant sends periodic updates of its status to the Server via a check-in packet. -
Page 10: To Call For Assistance
Chapter 1: Using and Staff Duress Pendant To Call for Assistance Firmly press and hold the red button on the Pendant (for at least one second). A red light illuminates while the button is depressed. When the light goes out, release the button. The light blinks green briefly to indicate successful communication, then flashes red in 10- second intervals to indicate that the Pendant is in an alarm state and transmitting data packets. -
Page 11: Led Light Behavior
Green—illuminates for 10 seconds Every 10 10 seconds Acknowledged Alarm event on the to indicate that the Pendant is seconds Help Alert software. scanning for nearby Reference tags. Software sent acknowledged packet to alarmed Pendant. Staff Duress Pendant (0510-0332-A) - User Guide... - Page 12 Chapter 1: Using and Staff Duress Pendant Staff Duress Pendant (0510-0332-A) - User Guide...
-
Page 13: Chapter 2 Maintenance
Chapter 2 Maintenance Replacing the Pendant Battery The Staff Duress Pendant uses two AAA 1.5v lithium batteries. The battery holders are found in the rear of the Pendant, on both sides of the circuit board. To replace the batteries in the Pendant Use your fingers or plastic tool to pray open the back cover of the Pendant. -
Page 14: Cleaning & Caring For The Pendant
Chapter 2: Maintenance Cleaning & Caring for the Pendant CAUTION: Use of non-approved cleaners can cause permanent damage to the Pendant and will void any and all warranties. Remove the Pendant from the lanyard or belt clip. Pre-clean the Pendant using an approved cleaner. •... -
Page 15: Chapter 3 Specifications
Chapter 3 Specifications Specifications Environmental Specifications Dimensions 62.5 mm x 50 mm x 16.3 mm (with lanyard add 6.4 mm) Weight 1.6 ounces Power Two AAA 1.5v lithium batteries Color Blue Operating Temperature 40-125 degrees Celsius Radio Specifications Standard Compliance IEEE 802.11b, Wi-Fi Frequency Range 2.412 - 2.462 GHz... - Page 16 RF Technologies, Inc. 3125 North 126th Street, Brookfield, WI 53005 Phone: 800.669.9946 Web: www.rft.com...
