WPEA-111N/W WiFi Module OEM General User and Installation Guide
I. OEM Usage Instructions
Installation
The WPEA-111N/W is a Half Mini PCI-E module contains Atheros AR9280 and SiGe
SE2593 as its front end module. The area around WPEA-111N/W should be free of
any components that may be in contact to the module unintentionally.
Operating Conditions
Operating temperature 0° - 60°C
Storage temperature -20° - 70°C
Input: 3.3VDC 0.67A
Dimensions: 26.65 mm x 29.85 mm x 3.3 mm
Weight: <= 9g.
RF Exposure Warning
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This device's external antenna must be installed in accordance with provided
instructions and it must be operated with a minimum of 20 cm spacing between antennas
and all persons' bodies (excluding extremities of hands, wrists and feet) during wireless
mode of operation. Further, this transmitter must not be co-located or operated in
conjunction with any other antenna or transmitter.
II. Notice of FCC Regulatory Compliance
This module has been tested and found to comply with the FCC Part15 Rules. These limits
are designed to provide reasonable protection against harmful interference in approved
installations. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation. Modifications or changes to this equipment not expressly
approved by Amp'ed RF Technology Inc. may void the user's authority to operate this
equipment.
III. Modular Approval
FCC ID: TVE-0600101
In accordance with FCC Part 15, the WPEA-111N/W is listed above as a Limited Modular
Transmitter device. In support of the Modular Transmitter Approval, the followings are stated:
