WWW.SparkLAN.com
Wireless LAN 802.11g NIC Series
User's Guide
Version 1.0
0
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NIC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sparklan NIC Series

  • Page 1 WWW.SparkLAN.com Wireless LAN 802.11g NIC Series User’s Guide Version 1.0 User’s Guide...
  • Page 2 WWW.SparkLAN.com Copyright statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording, or otherwise without the prior writing of the publisher. March. 2003 User’s Guide...
  • Page 3: Table Of Contents

    WWW.SparkLAN.com .Contents 1. Introduction ....................... 3 2. Wireless LAN Basics ....................4 3. Installation for Windows platform ................5 3.1. Installation Overview …………………………………………………………………………………..6 3.2. Install Procedure for Windows XP………………………………………………………. 3.3. Install Procedure for Windows 98/ME/2000……………………………………………. 4. Configuration Utility ....................17 4.1 Link Information …………………………………………………………………………………………19 4.2 Availiable Network…………………………………………………………………………...
  • Page 4: Introduction

    WWW.SparkLAN.com 1. Introduction Thank you for purchasing your Wireless LAN, Wireless LAN 802.11g Adapter. This Quick Installation Guide will assist you with the installation procedure. The package you have received should contain the following items: • Wireless LAN 802.11g Adapter •...
  • Page 5: Wireless Lan Basics

    WWW.SparkLAN.com 2. Wireless LAN Basics Wireless LAN (Local Area Networks) systems offer a great number of advantages over a traditional, wired system. Wireless LANs (WLANs) are more flexible, easier to setup and manage and often more cost effective than their wired equivalence. Using radio frequency (RF) technology, WLANs transmit and receive data over the air, minimizing the need for wired connections.
  • Page 6: Installation For Windows Platform

    WWW.SparkLAN.com 3. Installation for Windows platform The following section will assist you in installing wireless LAN Adapter successfully. You will first install software (Utility) and then insert / attach the Wireless LAN Adapter to your system, and finally set the network properties to accommodate resource sharing and select the type of wireless network that you wish to install.
  • Page 7: Installation Overview

    WWW.SparkLAN.com 3.1. Installation Overview Here are some steps you will perform in establishing your wireless network connection: Install the Access Point at first. AP is needed in case of Infrastructure network mode. Install the software using the Install CD. Install the Wireless LAN Card (WIRELESS LAN 802.11g Adapter). Install the network protocol(s) required to communicate on your network.
  • Page 8: Install Procedure For Windows Xp

    WWW.SparkLAN.com 3.2. Install Procedure for Windows XP Note: Do not insert the WLAN Adapter until you are asked to do so, failure of which may result in unsuccessful installation of your WLAN device. 1. Insert the given Installation CD in the CD-ROM and then click on the Setup. Follow the instruction to finish the installation.
  • Page 9 WWW.SparkLAN.com Click “ Continue Anyway ” for next step. After copy the file to your system, then the setup is finish. User’s Guide...
  • Page 10: Install Procedure For Windows 98/Me/2000

    WWW.SparkLAN.com 3.3. Install Procedure for Windows 98/ME/2000 Note: Do not insert the WLAN Adapter until you are asked to do so, failure of which may result in unsuccessful installation of your WLAN device. Please follow the following steps one by one in order to install the WLAN Adapter successfully.
  • Page 11 WWW.SparkLAN.com 4. Accept the license agreement. Accept the license agreement. Click Yes to accept. Click Yes to finish the setup. User’s Guide...
  • Page 12 WWW.SparkLAN.com 5. Insert / attach Wireless LAN 802.11g Adapter to your system Windows will recognize the WLAN adapter and auto detect the driver, if the system did not find the driver automatically, please install the driver manually. Click Yes to finish the installation. User’s Guide...
  • Page 13 WWW.SparkLAN.com 6. Click the right button of mouse on My Computer Properties Hardware Device Manager. Check whether it has WLAN adapter in one of the sockets or not. If you find SparkLAN Wireless Network PC Card in one of the sockets, it means the card is detected properly. Click right button of mouse on the Network Neighborhood.
  • Page 14 WWW.SparkLAN.com 8. Select Properties from the pop up menu. For Windows 98 the network’s properties box appears. * For Windows ME and 2000, please select the Local Area Connection’s properties to check the following menu. 9. Click on the General tab and then click on the Install button. Select Network Component Type box appears.
  • Page 15 WWW.SparkLAN.com 10. Select Network Protocols box appears. From the list of network protocols list, select NetBEUI, then click OK. 11. The NetBEUI protocol is now installed. After clicking on OK return back to Network Component Type box. 12. Repeat the step 9 and 10 to add IPX/SPX protocol. User’s Guide...
  • Page 16 WWW.SparkLAN.com 13. Click on the TCP/IP option for setting the IP address for your computer. You can select either Obtain an IP address automatically or Use the following IP address setting. If your choice is the second one then enter the IP value, Subnet masking, DNS, Domain/ Workgroup name, and Gateway Address values.
  • Page 17 WWW.SparkLAN.com Uninstall Procedure Step 1: If you want to uninstall the WLAN adapter, just simply click Start Menu Program Wireless Network Uninstall, it shall uninstall all related programs. Step 2: Restart your Computer. User’s Guide...
  • Page 18: Configuration Utility

    WWW.SparkLAN.com 4. Configuration Utility Wireless LAN 802.11g Wireless LAN adapter uses its own management software. All functions controlled by user are provided by this application. Usually this application starts automatically, or click icon from Start Menu to start the Utility application. A new icon - should appear in your Icon tray.
  • Page 19 WWW.SparkLAN.com User can navigate through “sheets”, by clicking tabs. “X” button will minimize window. To provide more information, click “More…” button. Below description explains the use and meanings of the various screen messages. User’s Guide...
  • Page 20: Link Information

    WWW.SparkLAN.com 4.1 Link Information - Connected To Network This field is used to display the current status of connection. When the state shows “Connected to Network“ means normal flow of operation in Infrastructure mode. The PC is connected to access point.
  • Page 21 WWW.SparkLAN.com - Current Channel and Transmit Rate Shows the channel of the radio and transmit rate being currently used for an active connection. This value has no meaning when the radio is “Scanning” - Link Quality The Link Quality bar graph is only active when the node is in Infrastructure Mode. The bar graph displays the quality of the link between the node and Access Point.
  • Page 22: Availiable Network

    WWW.SparkLAN.com 4.2 Availiable Networks The Connections Tab shows current status of available APs within the network. User may select profile or ESSID from above list, click “Connect” to connect with the AP. Click “Refresh” to rescan the network, this utility with site survey function, it will detect and list all available APs within network.
  • Page 23: Profile Setting

    WWW.SparkLAN.com 4.3 Profile Setting Profile Setting allows user to create profiles for different network environments. Click “Add” button to create new profiles. “Edit” for editing current exist profile. Click “Delete” button if you wish to delete profiles. Network Type This field allows you to select from a list of supported Network “Modes”. The modes displayed will have two values: “Peer to Peer”...
  • Page 24 WWW.SparkLAN.com Peer to Peer - This is the 802.11g peer-to-peer mode of operation. In 802.11g Ad Hoc, only one wireless “cell” is supported for each different SSID. All communication is done from Client to Client without the use of an Access Point. 802.11g Ad Hoc networking uses the same SSID for establishing the wireless connection.
  • Page 25 WWW.SparkLAN.com When an encrypted frame is received it will only be accepted if it decrypts correctly. This will only happen if the receiver has the WEP Key used by the transmitter. This panel allows to entry for 64/128-bit encryption according to WEP function select. To be written to the driver and registry, such as Hexadecimal format, each key must consist of hex digits, which means that only digit 0-9 and letters A-F are valid entries.
  • Page 26: About

    WWW.SparkLAN.com 4.4 About “About” tab shows the product version including the detail of Driver, Application and firmware versions. Users must use this version number when reporting their problems to technical support. User’s Guide...
  • Page 27: Troubleshooting

    WWW.SparkLAN.com 5. Troubleshooting If you encounter any problems during the installation, or to confirm that the WLAN 11Mbps device is installed properly, please read the following troubleshooting section. In Windows 98: To check that the WLAN 802.11g device is installed properly, please do the following: Go to START>SETTINGS>CONTROL PANEL>NETWORK.
