safety rules regarding outdoor power equipment (cont.)
• Grass catcher components are subject to wear,
damage, and deterioration, which could expose
moving parts or allow objects to be thrown.
Frequently check components and replace with
manufacturer's
recommended
necessary.
• Check brake operation frequently. Adjust and
service as required.
• Use only factory authorized replacement parts
when making repairs.
• Always comply with factory specifications on all
settings and adjustments.
• Only authorized service locations should be
utilized for major service and repair requirements.
• Never attempt to make major repairs on this unit
unless you have been properly trained. Improper
3
unit assembly
Note: Please refer to Parts List for correct part identification and placement.
numbers are called out by sheet number followed by reference number(s) on that sheet: (1:1) indicates
Sheet 1, reference number 1; (2:32,34-38) indicates Sheet 2, reference numbers 32 through 38 excluding
33; etc.
Note: Some assembly steps may already have been completed at the factory. Simply disregard factory-
completed steps and proceed to the next assembly step.
CASTER ASSEMBLY
•
Remove Lynch pin (1:16) and all but the bottom
1/4" spacer (1:15) from Caster horn (1:13).
•
Slide Caster horn up through Caster arm (1:8),
securing with same spacers and lynch pin
removed in previous step.
assembled in this manner, cutting height will be
approximately 2-1/2".
•
With front of mower propped up, install caster
assemblies to front of Blade Deck (1:1) with
twelve 3/8" x 1" bolts, flat washers, and
serrated flange nuts (1:9-11).
installed from inside of mower deck.) Tighten
all bolts securely. Lower front of mower.
parts,
when
NOTE:
When
(Bolts are
service
procedures
operation, equipment damage and voiding of
manufacturer's warranty.
can
result
in
hazardous
Parts list reference
GVTP SM32-R0303.1
