Movilent Mobile Phone
User's Guide
Model:
Please read this guide
carefully before using the
phone for the first time.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QT-57 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spice QT-57

Summary of Contents for Spice QT-57

  • Page 1 Movilent Mobile Phone User’s Guide Model: Please read this guide carefully before using the phone for the first time.

  • Page 2: Table Of Contents

    Contents   1. Safety and Maintenance --------------------------------------------------------- 3   2. Installation and charging -------------------------------------------------------- 7   2.1 I SIM C ........... 7 NSTALLING THE ARD AND ATTERY   2.2 R SIM C ..........7 EMOVING THE ATTERY AND   2.3 H ...............
  • Page 3   10. Technical Parameters --------------------------------------------------------- 26   11. RF Exposure Information ---------------------------------------------------- 27...

  • Page 4: Safety And Maintenance

    •Do not use the mobile phone while driving. •Use only the standard batteries, charger and accessories approved by Spice. Spice bears no responsibility for any consequences resulting from the use of third-party accessories. •Your mobile phone may interfere with other electronic devices around it.
  • Page 5 •Do not clean mobile housing with any dissolved matter, such as benzene, thinner or alcohol. Don’t expose your phone to corrosive chemicals, such as cleaning agents. Use only clean, soft cloth to clean your phone gently. •Never expose your mobile phone to direct sunlight or heavy smog or dust.
  • Page 6 •Squeezing of battery, mechanical vibration or shaking of battery or use of short-circuited battery is strictly prohibited, because such vehavior will damage the battery or components connected with it. Short circuit may result from direct connection of the positive pole and the negative pole of the battery by metal objects, such as a coin, pen, or paper clip, so keep the battery away from metal objects.
  • Page 7 Please follow the precautions below to use the charger. •Please read the instructions and the labels on the surface of the charger carefully before using it. •Do not try to disassemble or modify the charger. Never use the charger when power cord is damaged, otherwise, electric shock, fire and charger damage may occur.

  • Page 8: Installation And Charging

    2. Installation and charging 2.1 Installing the SIM Card and Battery Ensure that the golden contact area on the SIM card is facing downward, and the beveled corner is properly aligned with the SIM card slot. 2.2 Removing the Battery and SIM Card Note: Before removing the battery, make sure your phone is powered off and external power supply is removed.

  • Page 9: How To Insert Memory Card / T-Flash Card

    Note: Operate carefully. Do not try to pull the charger out of the charging interface by force to avoid possible damage to the phone or the charger. • The battery supplied with your mobile phone must be fully charged prior to use. •...

  • Page 10: Power On/Off

    2.5 Power On/Off Make sure the battery has been installed properly. Power on the phone and press [End] key until power-on menu appears on the screen. Some SIM cards may have PIN code protection. If there is a prompt to input PIN code, please enter your PIN code and then press [OK].

  • Page 11: Mobile Phone Parts Drawing And Key Functions

    3. Mobile Phone Parts Drawing and Key Functions 3.1 Key Description Description Confirm the operation that has been conducted and [OK key] enter the selected menu. This key usually corresponds to the function shown on [Left soft key] the lower left corner. Make or answer a call from SIM card.
  • Page 12 End a call. Press and hold this key to power on or power off the [End key] mobile phone. On the menu, press this key to return to standby state. When edting a text, click Del key can clear the character [Del key] on the front of cursor.

  • Page 13: Icons On Idle Screen

    3.2 Icons on Idle Screen <Icons on the screen > Icons Description Location Signal strength indicator Icons Area GPRS Connected Icons Area Alert Type is Ring Icons Area Alert Type is Vibration Icons Area Alert Type is Vibration and Icons Area Ring Alert Type is Vibration then Icons Area...

  • Page 14: Main Function Guide

    4. Main Function Guide 4.1 Download MP3 Songs Your phone supports MP3 music playback, and you can download MP3 music by: 1. connecting to the Internet; 2. connecting to the computer using USB; 3. receiving MP3 music via Bluetooth. 4.2 Camera You can enter the camera interface from [Camera].

  • Page 15: Com Port

    2. When files stored on your phone become abnormal, select memory card formatting. 3. When the phone is powered on and the USB function is activated, USB related functional modules of the phone cannot not be used. 4.3.2 COM Port Your phone supports PC synchronization.

  • Page 16: Dial An Extension Of A Fixed Phone

    4.4.2 Dial an Extension of a Fixed Phone Some fixed phones can not be put through directly. You need to enter the exchange number first, followed by * key until “P” or “W” appears on the screen, and then enter the extension number. You can dial an extension of a fixed phone by entering the following in series: area code exchange number...

  • Page 17: Dial An Emergency Number

    4.5 Dial an Emergency Number Within the coverage of the network (as indicated by the signal strength bar on the upper left corner of the screen of your phone), you can make an emergency call, even if you do not have a SIM card. If your network provider does not provide roaming service in the area, the screen will display “Out of Service”.

  • Page 18: Text Input

    5. Text input Changing the Text Input Mode The indicator of the current text input mode is displayed in the upper left corner of the screen. You can press to change the text input mode. Note: Press Del key to delete the character on the left of the cursor. Press Space key to enter a space.

  • Page 19: Function List

    7. Function list 1 Phonebook 1-1 Quick seach 5 Bluetooth 1-2 Seach contact 1-3 Add new contact 6 Music 1-4 Caller groups 1-5 Extra numbers 7 Neo messages 1-6 Phonebook settings 7-1 SMS 1-7 Call picture 7-2 MMS 1-8 Caller ringtone 7-3 Broadcast message 2 Multimedia 8 Neo application...
  • Page 20 11-1-1 General 11-4 Call settings 11-1-2 Meeting 11-4-1 Blacklist 11-1-3 Outdoor 11-4-2 Call waiting 11-1-4 Indoor 11-4-3 Call divert 11-1-5 Headset 11-4-4 Call barring 11-1-6 Bluetooth 11-4-5 Low battery protection 11-2 Phone setup 11-4-6 Advance settings 11-2-1 Time and date 11-5 Shortcuts 11-2-2 Language 11-6 Network Setup...

  • Page 21: Quick Function Reference

    8. Quick Function Reference This chapter briefly describes functions of the mobile phone. Function Description Options Check Check recently dialed, Main Menu-Call logs -missed calls, recent call answered, missed and received calls, dialed calls rejected calls Delete all records, Delete Call delete dialed, Main Menu-Call logs -Delete call answered, missed and...
  • Page 22 commonly used multimedia messages Main Menu- Neo messages Message Check message -SMS-SMS settings- Memory capacity capacity status in the status; Main status SIM card and phone Menu-Messages-MMS-MMS settings- Memory status; Display Change phone’s Main Menu - Settings - Display setting display settings setup Time and...
  • Page 23 code:0000) Note: The default security password is also 0000.

  • Page 24: Troubleshooting

    Please refer to the list below if you encounter any problems when using your phone. If you tried but the problem has not been solved, contact a qualified SPICE dealer or your local maintenance provider immediately. Your display prompts Enter PIN Code: Enter the valid PIN code for your SIM card.
  • Page 25 There are three possible reasons for this. First, the charger does not function normally. In that case, you should contact the nearby maintenance center or dealer designated by SPICE. Second, the working environment or temperature is not appropriate to the charger, and you can change the charging environment.
  • Page 26 ■Some functions can’t be selected: The related service is not in use or the local network service provider doesn’t support such service. Please contact with SPICE’s designated maintenance center, dealer or your network service provider.
  • Page 27 10. Technical Parameters Standard Product: GSM dual band digital mobile phone with GPRS features Model: QT-57 System: GSM 900/DCS 1800 Operating Temperature Highest: +55 °C Lowest: -10 °C Basic Parameters Dimensions (Length x Width x Thickness): about 62.4*107.4*13.5(mm) Weight: about 120.4g (including battery) Talk time: 120—240min*...
  • Page 28 11. RF Exposure Information The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. This model (FCC ID: YCNSHARK32) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 0.639 W/kg and when properly worn on the body is 0.778 W/kg.
  • Page 29 - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help...
