Display Panel

LED Panel

1. LED panel, it shows the time setting, charging status, and error codes by using numbers,
letters or graphs.
: Suction passage blocked,
2. " " Clean Button
A: Press this button to change from sleep mode to standby mode.
B. In standby mode, press this button and hold it for more than 3 seconds to go into sleep mode.
B: Confirm schedule setting in scheduling mode.
C: Start cleaning in standby mode.
3. "
A: Press this button to increase number in scheduling mode.
B: In other mode, press this button to start auto-homing and charging mode.
4. "
A: Press this button to decrease number in scheduling mode.
B: In other mode, press this button to start spot cleaning.
5. " " Schedule button
Press this button to enter/quit scheduling mode.
: Fully charged,
"Auto homing / number increment button
" Spot cleaning / number decrement button
: low power,
: no dust bin.
8
: charging,
