NO
ROTATION
P903
OK ?
Yes
Q902 (c)
15 V ?
Yes
Q903 (E)
7 V ?
Yes
Q904 (B)
2.5V ?
Yes
CHECK
Q904
A70PF(RX-777NS)
No
CHECK
Rotation Coil
No
CHECK
15V LINE
No
CHECK
7V LINE
No
CHECK
IC901
18 / 33
