Dual-Port Multi-Interface
(RS-232/422/485)
Ethernet Serial Server
Model ESP902, ESP902E
Documentation Number: ESP902-2303
International Headquarters
B&B Electronics Mfg. Co. Inc.
Phone (815) 433-5100 -- General Fax (815) 433-5105
Home Page: www.bb-elec.com
Sales e-mail:
orders@bb-elec.com
European Headquarters
Westlink Commercial Park, Oranmore, Co. Galway, Ireland
Phone +353 91-792444 -- Fax +353 91-792445
Home Page: www.bb-europe.com
Sales e-mail:
Technical Support e-mail:
B&B Electronics – May 2003
-- Fax (815) 433-5109
support@bb.elec.com
B&B Electronics Ltd.
sales@bb-europe.com
support@bb-europe.com
-- Fax (815) 433-5104
Title Page
