Sitecom WLX-5100 Installation Manual page 3

Step 1
Range Extender configuration
Choose an option:
Option 1
Router with OPS/WPS/ OPS/WPS/ button = button = Push button-configuration
Option 2
(page 7)
Router without OPS/WPS/ OPS/WPS/
Configure the Range Extender close to the router.
You will position it in step 2
4
button = button = Wizard-configuration
Option 1
Configure the 2.4 GHz network
A
OPS / WPS/
Push
2-5 seconds
Sitecom
(Modem)Router
No Sitecom (Modem) Router?
Please refer to your (modem) router's manual to find out Please refer to your (modem) router's manual to find out
how to activate the 2.4 GHz OPS/WPS/ how to activate the 2.4 GHz OPS/WPS/ mode mode
C C
Wait 1 minute
2.4 GHz- and WLAN-LED solid blue
B
OPS 2.4 GHz OPS 2.4 GHz
Push
5-10 seconds
Configure the 5 GHz network
5
