Special Tools

OMS/OMSW Orbital Motor
Repair Instruction
Special Tools
A
C
E
G
Service tool drawing can be ordered from Sauer-Danfoss
L1012850 • Rev AB • Sep 2010
B
D
F
A. Main holding tool SJ 151-9000-1
B: Holding tool for OMSS SJ 151F9000-1
C : Holding tool for OMSW SJ 151B9000-1
D: Mandrel for fitting shaft seal SJ 151F9000-7
E.: Mandrel for fitting PTO shaft seal SJ 151F9000-8
F : Holding tool for OMSW with brake nose SJ
151F9000-10
G: Holding tool for OMS SAE B - flange SJ
151F9000-11
