Page 1 2020 Owner's Manual...
Page 2 WARNING – California Proposition 65 “Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 3 Please drive safely, and enjoy your Kia vehicle! 2019 KIA MOTORS AMERICA, Inc. All rights reserved. May not be reproduced or translated in whole or in part without the written consent of Kia Motors America, Inc. Printed in U.S.A.
Page 5 How to use this manual You will find various WARNINGs, CAUTIONs, and NOTICEs in this man- We want to help you get the great- ual. These were prepared to est possible driving pleasure from enhance your personal safety. You your vehicle. Your Owner's Manual should carefully read and follow ALL can assist you in many ways.
Page 7: Table Of Contents
Table of Contents Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Driving your vehicle What to do in an emergency Maintenance Specifications, Consumer information and Reporting safety defects Abbreviation Index...
Page 9: Introduction
Introduction Introduction Fuel requirements ..............1-2 Vehicle break-in process ............1-4 Risk of burns when parking or stopping vehicle....1-5 Vehicle data collection and Event Data Recorders....1-5...
Page 10: Introduction
(Consult an water, and it is thus likely to reduce authorized Kia dealer for details.) your fuel efficiency and could lower Tighten the cap until it clicks one your MPG results.
Page 11 Fuel Additives melting, clogging, abnormal corro- Kia recommends that you use good sion, life cycle reduction, etc. quality gasolines treated with...
Page 12: Vehicle Break-In Process
1,200 miles (2,000 km) of opera- mended. Additives are available tion. from your authorized Kia dealer along with information on how to use them. Do not mix other addi- tives. Operation in foreign countries...
Page 13: Risk Of Burns When Parking Or Stopping Vehicle
Introduction Risk of burns when parking or stopping vehicle Risk of burns when parking or Vehicle data collection and Event stopping vehicle Data Recorders Do not park or stop the vehicle This vehicle is equipped with an near flammable items such as Event Data Recorder (EDR).
Page 14 Introduction Vehicle data collection and Event Data Recorders der, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data rou- tinely acquired during a crash inves- tigation.
Page 15: Your Vehicle At A Glance
Your vehicle at a glance Your vehicle at a glance Exterior overview..............2-2 Interior overview............... 2-5 Instrument panel overview ............. 2-7 Engine compartment ............... 2-9...
Page 16: Your Vehicle At A Glance
Your vehicle at a glance Exterior overview YOUR VEHICLE AT A GLANCE Exterior overview Front view OON018001L * The actual shape may differ from the illustration. 1. Hood 4-40 2. Head lamp (Features of your vehicle) 4-110 Head lamp (Maintenance) 7-62 3.
Page 17 Your vehicle at a glance Exterior overview 7. Front windshield wiper blades (Features of your vehicle) 4-119 Front windshield wiper blades (Maintenance) 7-27 8. Windows 4-36 9. Parking distance warning system 4-102...
Page 18 Your vehicle at a glance Exterior overview Rear view OON018002L * The actual shape may differ from the illustration. 1. Door locks 4-15 2. Fuel filler lid 4-42 3. Rear combination lamp (Maintenance) 7-65, 7-65 4. High Mounted Stop Lamp (Maintenance) 7-66 5.
Page 19: Interior Overview
Your vehicle at a glance Interior overview Interior overview OON018005NR * The actual shape may differ from the illustration. 1. Inside door handle 4-16 2. Driver position memory button 3-12 3. Outside rearview mirror folding 4-62 4. Outside rearview mirror selection 4-61 5.
Page 20 Your vehicle at a glance Interior overview 13.Liftgate open/close button 4-27, 4-28 14.Steering wheel 4-51 15.Tilt and telescopic steering control lever 4-53 16.Brake pedal 5-26 17.Hood release lever 4-40 18.Inner fuse panel 7-47 19.Seat...
Page 21: Instrument Panel Overview
Your vehicle at a glance Instrument panel overview Instrument panel overview OON018006NR * The actual shape may differ from the illustration. 1. Driver's front air bag 3-65 2. Horn 4-54 3. Instrument cluster 4-64 4. Wiper and washer control lever 4-117 5.
Page 22 Your vehicle at a glance Instrument panel overview 14.USB charger 4-163 15.AWD mode dial 5-19 Drive mode dial 5-49, 5-53 16.AUTO HOLD button 5-33 17.EPB switch 5-28 18.Parking distance warning system On/Off button 4-102 19.Surround View Monitoring system On/Off button 4-107 20.ISG system OFF button 5-45...
Page 23: Engine Compartment
Your vehicle at a glance Engine compartment Engine compartment Gasoline Engine (Lambda II 3.8L - GDI)) OON078001L * The actual engine cover in the vehicle may differ from the illustration. 1. Engine coolant reservoir 7-18 2. Engine oil filler cap 7-17 3.
Page 25 Safety features of your vehicle Safety features of your vehicle Important safety precautions ..........3-3 Seat ..................... 3-5 Feature of Seat Leather............3-9 Front seat adjustment for manual seat ......3-9 Front seat adjustment for power seat ......3-10 Driver position memory system for power seat .... 3-12 Headrest for front seat............
Page 26 Safety features of your vehicle Air bag - advanced Supplemental Restraint System ..3-53 How does the air bag system operate? ......3-54 Do not install a child restraint on the front passenger's seat ..................3-55 Air bag warning light............3-56 Supplemental Restraint System (SRS) components and functions ................3-56 Occupant Detection System (ODS)........3-59 Driver's and passenger's front air bag......3-65...
Page 27: Safety Features Of Your Vehicle
Safety features of your vehicle Important safety precautions SAFETY FEATURES OF YOUR Air bag hazards VEHICLE While air bags can save lives, they can also cause serious or fatal inju- For the safety of the driver and ries to occupants who sit too close vehicle passengers, you should to them, or who are not properly become familiar with the vehicle's...
Page 28 Safety features of your vehicle Important safety precautions ONLY use your mobile device when allowed by laws and when conditions permit safe use. NEVER text or email while driving. Most states have laws prohibiting drivers from texting. Some states and cities also prohibit drivers from using handheld phones.
Page 29: Seat
Safety features of your vehicle Seat Seat 8 Seats OON038038NR Front seat 11.Headrest 12.Walk-in strap for emergency 1. Forward and backward 2. Seatback angle 3rd row seat 3. Seat cushion height* 13.Seatback angle strap 4. Lumbar support (Driver's seat)* 14.2nd row seat remote folding 5.
Page 30 Safety features of your vehicle Seat 7 Seats OON038039NR Front seat 3rd row seat 1. Forward and backward 13.Seatback angle strap 2. Seatback angle 14.2nd row seat remote folding 3. Seat cushion height* button 4. Lumbar support (Driver's seat)* 15.Headrest 5.
Page 31 Safety features of your vehicle Seat system's ability to restrain will be WARNING greatly reduced. Loose objects Do not place anything in the driver's WARNING footwell or under the front seats. Loose objects in the driver's foot Seat cushion area could interfere with the opera- Occupants should never sit on after- tion of the foot pedals.
Page 32 Safety features of your vehicle Seat WARNING WARNING Rear seatbacks Luggage and Cargo Always lock the rear seatback Do not stack pile or stack luggage or before driving. Failure to do so could cargo higher than the seatback in result in passengers or objects being the cargo area.
Page 33: Feature Of Seat Leather
Safety features of your vehicle Seat Feature of Seat Leather Front seat adjustment for manual seat Leather is made from the outer skin The front seat can be adjusted by of an animal, which goes through a using the control levers located on special process to be available for the outside of the seat cushion.
Page 34: Front Seat Adjustment For Power Seat
Safety features of your vehicle Seat Reclining seatback your chest. Instead, it will be in front of you. During an accident, you could be thrown into the seat belt, caus- ing neck or other injuries. The more the seatback is reclined, the greater chance the passenger's hips will slide under the lap belt or the passenger's neck will strike the...
Page 35 Safety features of your vehicle Seat Reclining seatback Before driving, adjust the seat to the proper position so you can easily control the steering wheel, pedals and switches on the instrument panel. CAUTION Power seating adjustments The power seating controls func- tion by electronic motor.
Page 36: Driver Position Memory System For Power Seat
Safety features of your vehicle Seat Adjusting cushion extension for 2. Pull the rear portion (2) of the driver's seat (if equipped) control switch up to raise or press down to lower the seat cushion. 3. Release the switch once the seat reaches the desired position.
Page 37 Safety features of your vehicle Seat By saving the desired position into pressing the SET button. The sys- tem will beep twice when mem- the system memory, different driv- ory has been successfully stored. ers can reposition the driver seat based upon their driving prefer- When recalling an adjustment mem- ence.
Page 38 Safety features of your vehicle Seat settings mode in the instrument NOTICE cluster. Upward/downward movement of 1. Press the MODE button ( ) sev- the seat may not work when pas- eral times on the steering wheel sengers get on/off the vehicle in until 'User Settings' menu appears order to prevent foot injuries in cer- on the LCD.
Page 39: Headrest For Front Seat
Safety features of your vehicle Seat 3. Initialization will be all set after the seat and seatback move to the center with alarm sound being raised. However, the initialization process will come to a stop and the alarm sound will stop as well. When pushing driving position memory system button When pushing driver's seat...
Page 40 Safety features of your vehicle Seat WARNING NOTICE Headrest removal/adjustment If you recline the seatback towards the front with the headrest and Do not operate the vehicle with seat cushion raised, the headrest the headrests removed. Head- may come in contact with the sun rests can provide critical neck and visor or other parts of the vehicle.
Page 41 Safety features of your vehicle Seat Reinstalling headrest Type B Type A OON038012NR To remove the headrest: OON038013NR 1. Recline the seatback (2) with the Type B recline lever or switch (1). 2. Raise headrest as far as it can go. 3.
Page 42: Seatback Pocket (If Equipped)
Safety features of your vehicle Seat Seatback hook WARNING 1st row Headrest Reinstallation To reduce the risk of injury to the head or neck, always make sure the headrest is locked into position and adjusted properly after reinstalling. Seatback pocket (if equipped) The seatback pocket is provided on the back of the front passenger's and driver's seatbacks.
Page 43: Headrest For Rear Seat
Safety features of your vehicle Seat Adjusting the height up and down Headrest for rear seat (2nd row seat and 3rd row center The rear seat is equipped with seat) headrests in all the seating positions 2nd row for the occupant's safety and com- fort.
Page 44 Safety features of your vehicle Seat Removing/reinstalling headrest Folding 3rd row headrest (except (2nd row seat and 3rd row center for center) seat) 2nd row OON038105NR OON038020NR 3rd row center OON038106NR The headrest will fold down auto- matically when folding the seatback. To fold the headrest manually: OON038020NR To remove the headrest, raise it...
Page 45: Armrest
Safety features of your vehicle Seat WARNING If the liftgate is pushed down to close it when a passenger's head is not against a properly adjusted headrest or a tall person is seated, the liftgate may hit the occupant's head, which could cause injury. OON038021NR For 8 seats To use the armrest, pull it forward...
Page 46 Safety features of your vehicle Seat Folding down the rear seatback WARNING 1. Set the front seatback to the Folded Seatback upright position and if necessary, The purpose of the fold-down rear slide the front seat forward. 2. Lower the rear headrests to the seatbacks is to allow you to carry lowest position.
Page 47 Safety features of your vehicle Seat 4. Pull on the seatback folding lever 6. Return the rear seat belt to the (for 2nd row) or strap (for 3rd proper position. row), then fold the seat toward the front of the vehicle. When you Unfolding the rear seat return the seatback to its upright 2nd row seat...
Page 48 Safety features of your vehicle Seat means the seatback is locked WARNING completely. Rear seat folding 2. Return the rear seat belt to the proper position. Do not fold the rear seats (2nd & 3. When the seatback is completely 3rd row seats), if passengers, pets installed, check the seatback fold- or luggage are in the rear seats.
Page 49 Safety features of your vehicle Seat 7 seat WARNING Do not pull the strap (3) when the 2nd-row seat(s) is/are occupied. Sudden movement of the seat(s) may result in injury. Use the strap only when the folding switch in the 2nd row (in the upper part of the second-row seatback or the outer part of the seat) does not work.
Page 50 Safety features of your vehicle Seat Do not allow the seat belt web- CAUTION bing or buckle to become pinched Be careful when loading cargo or caught in the rear seat. through the rear passenger seats to Ensure the seatback is completely prevent damage to the vehicle inte- locked into its upright position by rior.
Page 51: Seat Belts
Safety features of your vehicle Seat belts Seat belts Always wear both the shoulder portion and lap portion of the lap/ Seat belts are designed to bear upon shoulder belt. the bony structure of the body, and should be worn low across the front of the pelvis, chest and shoulders.
Page 52: Driver's Seat Belt Warning
Safety features of your vehicle Seat belts No modifications or additions Driver's seat belt warning should be made by the user which As a reminder to the driver, the would either prevent the seat belt driver's seat belt warning lights will adjusting devices from operating illuminate for approximately 6 sec- to remove slack, or prevent the...
Page 53: Front Passenger's Seat Belt Warning
Safety features of your vehicle Seat belts the speed is under 12 mph (20 km/ unfasten the seat belt when you h). When the speed is 12 mph (20 drive 12 mph (20 km/h) and faster, km/h) and faster, the warning light the warning light will blink and will blink and warning chime will warning chime will sound for...
Page 54: Seat Belt - Driver's 3-Point System With Emergency Locking Retractor
Safety features of your vehicle Seat belts Seat belt - Driver's 3-point system WARNING with emergency locking retractor You should place the lap belt portion The following explains how to fas- as low as possible and snugly across ten and adjust the driver's seat belt. your hips.
Page 55: Seat Belts - Front Passenger And Rear Seat 3-Point System With Combination Locking Retractor
Safety features of your vehicle Seat belts Adjusting the height of shoulder Improperly positioned seat belts can belt cause serious injuries in an accident. You can adjust the height of the WARNING shoulder belt anchor to one of the 4 positions for maximum comfort and Shoulder belt positioning safety.
Page 56 Safety features of your vehicle Seat belts retractor is also installed in the NOTICE front passenger seat position, it is Although the combination retractor strongly recommended that children provides the same level of protec- always be seated in the rear seat. tion for seated passengers in either NEVER place any infant restraint emergency or automatic locking...
Page 57 Safety features of your vehicle Seat belts 2nd row seat WARNING Prior to fastening the rear seat belts, ensure the latch matches the seat belt buckle. Forcefully fasten- ing the left or right seat belt to the center buckle can result in an improper fastening scenario that will not protect you in an accident.
Page 58 Safety features of your vehicle Seat belts Stowing the rear seat belt 2nd row seat The rear seat belt buckles can be stowed in the pocket between the rear seatback and cushion when not in use. 2nd row seat OON039116NR 3rd row seat OON039115NR 3rd row seat...
Page 59: Rear Center Seat Belt (3Rd Row)
Safety features of your vehicle Seat belts When it is released, the belt WARNING should automatically draw back 3rd center seat belt into the retractor. If this does not happen, check the belt to make sure it is not twisted, then try again.
Page 60 Safety features of your vehicle Seat belts 3. Pull out the tongue plate (B) from the pocket. Pull the tongue plate (B) and insert it into the buckle (B') until an audible "click" is heard, indicating the latch is locked. Make sure the belt is not twisted.
Page 61: Pre-Tensioner Seat Belt
Safety features of your vehicle Seat belts Pre-tensioner seat belt the pressure on the affected seat belt. (if equipped) WARNING For your safety, be sure that the belt webbing is not loose or twisted and always sit properly on your seat.
Page 62 NOTICE have the system inspected by an When the pre-tensioner seat authorized Kia dealer. belts are activated, a loud noise may be heard and fine dust, which WARNING may appear to be smoke, may be...
Page 63: Seat Belt Precautions
Federal Motor Vehicle Safety Stan- Therefore, have the system ser- dard 213. The restraint must be viced by an authorized Kia dealer. appropriate for your child's height and weight. Check the label on the child restraint for this information.
Page 64 Safety features of your vehicle Seat belts Larger children WARNING Children who are too large for Child Small children Restraint System should always Do not allow small children to ride in occupy the rear seat and use the the vehicle without an appropriate available lap/shoulder belts.
Page 65: Care Of Seat Belts
Safety features of your vehicle Seat belts Injured person WARNING A seat belt should be used when an Pinched seat belt injured person is being transported. Make sure that the webbing and/or When this is necessary, you should buckle does not get caught or consult a physician for recommen- pinched in the rear seat when dations.
Page 66: Child Restraint System (Crs)
Kia dealer. Children always in the rear Children under age 13 must always ride in the rear seats and must...
Page 67 Safety features of your vehicle Child Restraint System (CRS) restrained in the rear seats than in installation and use provided by the the front seat. Even with air bags, manufacturer of the CRS. children can be seriously injured or WARNING killed.
Page 68: Selecting A Crs
Always use a Child Restraint System which is appropriate for your child's height and weight. NOTICE After an accident, have a Kia dealer check the Child Restraint System, WARNING seat belts, tether anchors and lower Unattended Children anchors.
Page 69 Safety features of your vehicle Child Restraint System (CRS) CRS types allowed by the child seat manufac- turer. It's the best way to keep There are three main types of the them safe. Once your child has out- CRS: rear-facing seats, forward- grown the rear-facing child facing seats, and booster seats.
Page 70: Installing A Crs
Safety features of your vehicle Child Restraint System (CRS) the seat without a booster and still Secure the child in the child have the seat belt fit properly. For a restraint. Make sure the child is seat belt to fit properly, the lap belt properly strapped in the child must lie snugly across the upper restraint according to the manu-...
Page 71 Safety features of your vehicle Child Restraint System (CRS) The lower anchor position indicator symbols are located on the left and right 2nd row rear seatbacks to identify the position of the lower anchors in your vehicle (see arrows in illustration). 7 seats 2nd row OON039114NR LATCH anchors have been provided...
Page 72 Safety features of your vehicle Child Restraint System (CRS) 3rd row seat the child restraint and the lower anchors. 3. Place the child restraint on the vehicle seat, then attach the seat to the lower anchors according to the instructions provided by the child restraint manufacturer.
Page 73 Safety features of your vehicle Child Restraint System (CRS) Always have the LATCH system 8 seats inspected by your authorized Kia dealer after an accident. An acci- dent can damage the LATCH sys- tem and may not properly secure the child restraint.
Page 74 Safety features of your vehicle Child Restraint System (CRS) 1. Route the child restraint tether WARNING strap over the child restraint Take the following precautions seatback. Route the tether strap when installing the tether strap: under the head restraint and between the head restraint posts, Read and follow all installation or route the tether strap over the...
Page 75 Safety features of your vehicle Child Restraint System (CRS) All passenger seat belts move freely 3. Pull the shoulder portion of the under normal conditions and only seat belt all the way out. When lock under extreme or emergency the shoulder portion of the seat conditions (emergency locking belt is fully extended, it will shift mode).
Page 76 Safety features of your vehicle Child Restraint System (CRS) shoulder belt back into the WARNING retractor. Auto lock mode 6. Push and pull on the CRS to con- firm that the seat belt is holding it Set the retractor to Automatic Lock firmly in place.
Page 77: Air Bag - Advanced Supplemental Restraint System
Safety features of your vehicle Air bag - advanced Supplemental Restraint System Air bag - advanced Supplemental Restraint System OON038084NR * The actual air bags in the vehicle may differ from the illustration. 1. Driver's front air bag 2. Passenger's front air bag 3.
Page 78: How Does The Air Bag System Operate
Safety features of your vehicle Air bag - advanced Supplemental Restraint System How does the air bag system oper- their storage compartments after ate? the collision. Air bags are activated (able to In addition to inflating in serious inflate if necessary) only when side collisions, side and/or curtain the ENGINE START/STOP button air bags will inflate if the sensing...
Page 79: Do Not Install A Child Restraint On The Front Passenger's Seat
Safety features of your vehicle Air bag - advanced Supplemental Restraint System WARNING WARNING Airbag inflation Hot components Sit as far back as possible from the Do not touch the air bag storage steering wheel while still maintain- area's internal components immedi- ing comfortable control of the vehi- ately after airbag inflation.
Page 80: Air Bag Warning Light
Have an autho- rized Kia dealer inspect the air bag WARNING system as soon as possible. The light does not turn on briefly...
Page 81 Safety features of your vehicle Air bag - advanced Supplemental Restraint System The SRS consists of the following the vehicle, it will automatically components: deploy the front air bags. 1. Driver's front air bag module Driver's front air bag (2) 2.
Page 82 If this occurs, have your vehicle Flying objects immediately inspected by an Do not place any objects (an authorized Kia dealer. umbrella, bag, etc.) between the front door and the front seat. Such objects may become dangerous projectiles if the side airbag inflates.
Page 83: Occupant Detection System (Ods)
Safety features of your vehicle Air bag - advanced Supplemental Restraint System Main components of the ODS NOTICE A detection device is located Before you replace a fuse or discon- within the front passenger seat nect a battery terminal, change the cushion.
Page 84 Safety features of your vehicle Air bag - advanced Supplemental Restraint System the front passenger air bag based can defeat the detection system. on these conditions. These include: 1. Failing to sit in an upright position. Always be sure that you and all 2.
Page 85 Any service related to the pas- Detection System and may result in senger seat and the ODS must be the deactivation of the front pas- done at an authorized Kia dealer- senger airbag. It is important for the ship. driver to instruct the passenger as...
Page 86 Safety features of your vehicle Air bag - advanced Supplemental Restraint System ODEEV058055NR ODEEV058002NR Do not place feet on the front Never place feet on the dash- passenger seatback. board. ODEEV058056NR ODEEV058059NR Never sit with hips shifted Never lean on the door or center towards the front of the seat.
Page 87 Safety features of your vehicle Air bag - advanced Supplemental Restraint System Do not use car seat accessories Wet passenger seat such as thick blankets and cush- Do not spill liquid in the passenger seat. Spilled liquid on the passen- ions which cover up the car seat ger seat may cause the air bag surface.
Page 88 Safety features of your vehicle Air bag - advanced Supplemental Restraint System senger to sit properly (sitting NOTICE upright with the seatback in an upright position, centered on the The PASSENGER AIR BAG " " indi- seat cushion with their seat belt on, cator illuminates for about 4 sec- legs comfortably extended and their onds after the ENGINE START/STOP...
Page 89: Driver's And Passenger's Front Air Bag
Safety features of your vehicle Air bag - advanced Supplemental Restraint System the passenger's front airbag will Passenger's front air bag inflate in frontal impact crashes even if there is no occupant in the front passenger seat. Driver's and passenger's front air Your vehicle is equipped with an advanced supplemental restraint (air bag) system and lap/shoulder...
Page 90 The advanced SRS offers the ability system. That contact is Kia's toll- to control the air bag inflation with free Customer Assistance center at two levels. A first stage level is pro- 1-800-333-4Kia.
Page 91: Side Air Bag
Air bags can only be used once air bags to deploy. have an authorized Kia dealer Do not place any objects over the air replace the air bag immediately bag or between the air bag and after deployment.
Page 92 If seat or seat cover is damaged, have the vehicle checked and WARNING repaired by an authorized Kia dealer. Inform the dealer that Unexpected deployment your vehicle is equipped with side Avoid impact to the side impact air-...
Page 93: Curtain Air Bag
Safety features of your vehicle Air bag - advanced Supplemental Restraint System Curtain air bag WARNING Curtain air bags are located along Flying objects both sides of the roof rails above Do not place any objects (an the front and rear doors. umbrella, bag, etc.) between the front door and the front seat.
Page 94 NOTICE Never try to open or repair any components of the side and curtain air bag system. This should only be done by an authorized Kia dealer.
Page 95: Air Bag Collision Sensors
Safety features of your vehicle Air bag - advanced Supplemental Restraint System Air bag collision sensors The air bag collision sensors are located in the following positions OON038070L OON038071NR OON038072NR OON038073NR OON038087NR OON038074NR * The actual shape and position of sensors may differ from the illustration. 1.
Page 96: Why Didn't My Air Bag Go Off In A Collision
Have the vehicle checked and repaired by an authorized Kia dealer. Air bag inflation conditions Do not arbitrarily touch the front Front air bags impact sensor. When the angle of the sensor is changed, the air bag system may malfunction.
Page 97 Safety features of your vehicle Air bag - advanced Supplemental Restraint System Front air bags are designed to Also, the side and curtain air bags inflate in a frontal collision depend- are designed to inflate when a roll- ing on several factors, including the over is detected by a rollover sensor.
Page 98 Safety features of your vehicle Air bag - advanced Supplemental Restraint System Air bag non-inflation conditions Front airbags may not inflate in side impact collisions, because In certain low-speed collisions the passengers move in the direction air bags may not deploy. The air of the collision.
Page 99: Supplemental Restraint System (Srs) Care
Kia dealer. Any work on the SRS, such as removing, installing, repairing, or any work on the steering wheel, the front passenger's panel, front seats and roof rails must be performed by an authorized Kia dealer. Improper OON039124NR...
Page 100: Adding Equipment To Or Modifying Your Air Bag-Equipped Vehicle
An Air bag warning label authorized Kia dealer knows these Air bag warning labels, some precautions and can give you the required by the U.S. National High- necessary information. Failure to...
Page 101 Features of your vehicle Features of your vehicle Smart key................... 4-7 Replacing smart key battery ..........4-11 Smart key immobilizer system.......... 4-12 This device complies with Part 15 of the FCC rules..4-13 Theft-alarm system .............. 4-13 Armed stage................4-13 Theft-alarm stage ...............
Page 102 Features of your vehicle Smart Power Liftgate ............4-32 Using the smart power liftgate .........4-32 Deactivating the smart power liftgate with the smart key...................4-34 Detecting area...............4-35 Windows ...................4-36 Window opening and closing..........4-38 Power window lock switch..........4-39 Hood ..................4-40 Opening the hood ..............4-40 Closing the hood ..............4-41 Fuel filler lid................4-42 Opening the fuel filler lid .............4-42...
Page 103 Features of your vehicle Instrument cluster control..........4-65 Gauges..................4-65 Transmission shift indicator ..........4-68 LCD display................4-68 LCD Display Control .............. 4-68 LCD Display Modes ............... 4-69 LCD displays................4-78 Trip information (trip computer) ........4-78 Drive mode ................4-80 Service Mode .................
Page 104 Features of your vehicle Operating high beam ............4-112 Operating turn signals and lane change signals... 4-113 Operating front fog light..........4-114 High Beam Assist (HBA) system........4-114 Wipers and washers ............4-117 Operating windshield washer .......... 4-119 Operating rear window wiper and washer switch ..4-120 Interior lights ................
Page 105 Features of your vehicle Heating and air conditioning manually ......4-142 Controlling rear climate .............4-147 Windshield defrosting and defogging .......4-151 Defogging inside windshield with manual climate control system ..............4-151 Defrosting outside windshield with manual climate control system ..............4-152 Defogging inside windshield with the automatic climate control ..................4-152 Defrosting outside windshield with automatic climate control ..................4-153...
Page 106 Features of your vehicle AC inverter ................4-164 Wireless smart phone charging system ......4-166 Coat hook ................4-169 Side curtain................. 4-170 Floor mat anchor(s) ............4-170 Luggage net holder ............4-171 Exterior features ..............4-172 Roof rack................4-172 Audio system................ 4-173 Shark fin antenna ..............
Page 107: Features Of Your Vehicle
With a smart key, you can lock or lose your keys, this number will unlock a door (and liftgate). enable an authorized Kia dealer to duplicate the keys easily. Remove Refer to the following for more the bar code tag and store it in a details.
Page 108 Features of your vehicle Smart key Locking Unlocking Pressing the button of the front outside door handles, with all doors (and liftgate) closed and locked, unlocks all the doors (and liftgate). The hazard warning lights will blink twice to indicate that all doors (and liftgate) are unlocked.
Page 109 Features of your vehicle Smart key Liftgate unlocking doors are closed after the lock but- ton is pressed, the hazard warning If you are within 28~40 in (0.7~1 m) lights will blink once. from the outside liftgate handle, with your smart key in possession, Unlock (2) the liftgate will unlock and open when you press the liftgate handle...
Page 110 You should immediately and maintain adequate distance take the vehicle and remaining key between the two devices. to your authorized Kia dealer (tow...
Page 111: Replacing Smart Key Battery
If you are unsure how to use your with a parking attendant, remove smart key or replace the battery, the mechanical key for your own contact an authorized Kia dealer. use and provide the attendant with 1. Remove the mechanical key. the electronic key only.
Page 112: Smart Key Immobilizer System
Kia dealer. An inappropriately dis- posed battery can be Do not attempt to alter this system harmful to the environ- or add other devices to it.
Page 113: Theft-Alarm System
Features of your vehicle Theft-alarm system This device complies with Part 15 Theft-alarm system of the FCC rules. The theft-alarm system is designed Operation is subject to the following to provide protection from unau- two conditions: thorized entry into the vehicle. 1.
Page 114: Theft-Alarm Stage
Features of your vehicle Theft-alarm system will operate once to indicate that Theft-alarm stage the system is armed. The alarm will be activated if any of If any door (or liftgate) or hood the following occurs while the sys- remains open, the hazard warning tem is armed.
Page 115: Door Locks
START/STOP button to the ON position and wait for 30 seconds. Then the system will be disarmed. If you lose your keys, consult your authorized Kia dealer. OON048047NR 1. Pull out the door handle. 2. Press the lever (1) located inside the bottom part of the cover with a key or flat-head screwdriver.
Page 116: Operating Door Locks From Inside The Vehicle
Features of your vehicle Door locks Once the doors are unlocked, they WARNING may be opened by pulling the If adult passengers must remain in door handle. the vehicle while it is very hot or cold When closing the door, push the outside, there is risk of injuries or door by hand.
Page 117 Features of your vehicle Door locks With the door lock button Door lock malfunction If a power door lock ever fails to function while you are in the vehicle, try one or more of the following techniques to exit: Operate the door unlock feature repeatedly (both electronic and manual) while simultaneously pulling on the door handle.
Page 118: Door Lock/Unlock Features
Features of your vehicle Door locks Passenger side Be careful when opening doors and watch for vehicles, motorcy- cles, bicycles or pedestrians approaching the vehicle in the path of the door. Opening a door when something is approaching can cause damage or injury. WARNING Unattended children/animals OON048410NR...
Page 119: Electronic Child Safety Lock System
If this occurs, have the system child safety lock system. checked by a professional workshop. The electronic child safety lock sys- Kia recommends to visit an autho- tem is always on when the ENGINE rized Kia dealer. START/STOP button is in the ON or...
Page 120: Safe Exit Assist (Sea) System
Features of your vehicle Door locks Safe Exit Assist (SEA) system door is opened, the "Watch for traf- fic" warning message appears on The Safe Exit Assist (SEA) system is the cluster and a warning sounds. provided to help prevent passengers The above 2 and 3 functions are from opening their door by warning activated when you select 'Driver...
Page 121: Rear Occupant Alert (Roa) System
Features of your vehicle Door locks nates) it automatically switches WARNING OFF and the rear door is unlocked. The system does not detect every obstacle approaching the vehicle CAUTION exit. The Safe Exit Assist (SEA) system The driver and passenger are may not operate normally if there responsible for any obstacles is any vehicle or obstacle at the...
Page 122 Features of your vehicle Door locks - Unlock the door with the Steering wheel remote key or smart key to stop the alert. - The system detects movement in the vehicle for 24 hours after the door is locked. The 2nd alert is activated only after the prior activation of the 1st alert.
Page 123: Manual Liftgate
Features of your vehicle Manual liftgate Manual liftgate WARNING When you open the liftgate, you will Even if your vehicle is equipped see a space where you can load the with the Rear Occupant Alert cargo. (ROA) system, always make sure you check the rear seat before Opening the manual liftgate you get off the vehicle.
Page 124: Closing The Manual Liftgate
Features of your vehicle Manual liftgate If unlocked, the liftgate can be Make sure your hands, feet and opened by pressing the handle other parts of your body are safely and pulling it up. out of the way before closing the Once the liftgate is opened and liftgate.
Page 125 Features of your vehicle Manual liftgate 1. Input the mechanical key into the WARNING hole. Do not grasp the part supporting 2. Push the mechanical key to the the liftgate (gas lifter), as this may right (1). 3. Push the liftgate upwards. cause serious injury.
Page 126: Power Liftgate
Features of your vehicle Power liftgate Power liftgate (if equipped) When you open the liftgate, you will see a space where you can load the cargo. OON049403NR 1. Power liftgate open/close button 2. Power liftgate handle switch 3. Power liftgate close button 4.
Page 127: Opening The Power Liftgate
Features of your vehicle Power liftgate that there is sufficient clearance NOTICE above the liftgate. In cold and wet climates, power lift- gate may not work properly due to CAUTION freezing conditions. It is recommended to open and close the liftgate automatically. Do not NOTICE apply excessive force when opening or closing the lift gate manually.
Page 128: Closing The Power Liftgate
Features of your vehicle Power liftgate OON048059NR OON048059NR Press the liftgate handle switch For emergency stop while power with the smart key in your pos- liftgate operating, press the session. power liftgate open/close button shortly. Press the power liftgate close button when the liftgate is opened.
Page 129: Power Liftgate Non-Opening Conditions
This must be done by an autho- The chime will sound continuously if rized Kia dealer. you drive over 2 mph (3 km/h) with When jacking up the vehicle to the liftgate opened. Stop your vehi-...
Page 130: Automatic Reversal
Features of your vehicle Power liftgate In cold and wet climates, the and move in the opposite direc- tion. power liftgate may not work If the resistance is detected while properly due to freezing condi- closing the liftgate, it will stop and tions.
Page 131: Resetting The Power Liftgate
4-71. properly after the above procedure, have the system checked by an NOTICE authorized Kia dealer. If the power liftgate does not oper- NOTICE ate normally, check again if the gear position is in P (Park) position.
Page 132: Features Of Your Vehicle
Features of your vehicle Smart Power Liftgate 1. Position the liftgate manually to Smart Power Liftgate (if the preferred height. equipped) 2. Press the liftgate close button for more than 3 seconds. 3. Close the liftgate manually after hearing the buzzer sound. The liftgate will open to the height the driver has set up.
Page 133 Features of your vehicle Smart Power Liftgate - The smart key is detected the chime will sound for about 3 seconds. This alerts you that the within 15 seconds after the smart key has been detected and doors are closed and locked, the liftgate will open.
Page 134: Deactivating The Smart Power Liftgate With The Smart Key
Features of your vehicle Smart Power Liftgate injury. Make sure to deactivate the If you press any button of the Smart Power Liftgate when wash- smart key during the Detect and ing your vehicle. Otherwise, the lift- Alert stage, the Smart Power gate may open inadvertently.
Page 135: Detecting Area
Features of your vehicle Smart Power Liftgate Detecting area NOTICE The Smart Power Liftgate func- tion will not work if any of the fol- lowing occurs: - The smart key is close to a radio transmitter such as a radio station or an airport which can interfere with normal operation of the transmitter.
Page 136: Windows
Features of your vehicle Windows Windows The doors of this vehicle are equipped with power windows that can be operated by a switch. OON049438NR 1. Driver's door power window switch 2. Front passenger's door power window switch 3. Rear door (left) power window switch 4.
Page 137 Features of your vehicle Windows NOTICE NOTICE In cold and wet climates, power win- While driving with the rear windows dows may not work properly due to down or with the sunroof (if freezing conditions. equipped) in an open (or partially open position), your vehicle may demonstrate a wind buffeting or The ENGINE START/STOP button...
Page 138 Features of your vehicle Windows Automatic reversal Window opening and closing You can open and close windows If the upward movement of the using the power window switch. window is blocked by an object or part of the body, the window will detect the resistance and will stop Auto up/down window upward movement.
Page 139 Features of your vehicle Windows pulling up the switch. The automatic Power window lock switch reverse feature will not operate if The driver can disable the power the window is raised using the half- window switches on the rear pas- way position on the power window sengers' doors by pressing the switch.
Page 140: Power Window Lock Switch
Features of your vehicle Hood Hood WARNING The hood serves as a cover for the Power windows engine compartment. Open the Do not allow children to play with hood if maintenance works needs to the power windows. Keep the be performed in the engine com- power window lock switch (on the partment or if you need to look at driver's door) in the LOCK...
Page 141: Closing The Hood
Features of your vehicle Hood Closing the hood 1. Before closing the hood, check the following: All filler caps in the engine com- partment must be correctly installed. Gloves, rags or any other com- bustible material must be removed from the engine com- partment.
Page 142: Fuel Filler Lid
Features of your vehicle Fuel filler lid Fuel filler lid WARNING The vehicle's fuel filler lid must be Unsecured hood opened and closed by hand from Always double check to be sure that outside the vehicle. the hood is firmly latched before driving away.
Page 143: Closing The Fuel Filler Lid
Features of your vehicle Fuel filler lid 3. Pull the fuel filler lid (1) out to NOTICE fully open. When refueling on unlevel ground, the fuel gauge may not point to the F position. It is not a malfunction. If you move your vehicle to a level ground, the fuel gauge will move to the full position.
Page 144 Make sure to refuel your vehicle according to "Fuel requirements" on page 1-2. If the fuel filler cap requires replace- ment, use only a genuine Kia cap or...
Page 145 Features of your vehicle Fuel filler lid the equivalent specified for your Immediately rinse fuel off your vehicle. An incorrect fuel filler cap skin with soap and water. If fuel comes into contact with can result in a serious malfunction your eyes, immediately rinse of the fuel system or emission con- them thoroughly with clean...
Page 146: Dual Sunroof
Have be opened or closed with the switch the system serviced by an autho- (2). rized Kia dealer. NOTICE Do not overfill the fuel tank Do not overfill the fuel tank; other- wise fuel may slide, causing harm to the environment and damaging the vehicle.
Page 147 Features of your vehicle Dual sunroof NOTICE WARNING In cold and wet climates, the sun- Never adjust the sunroof or sun- roof may not work properly due to shade while driving. This could result freezing conditions. in loss of control and an accident that may cause death, serious After the vehicle is washed or in a injury, or property damage.
Page 148: Sliding The Sunroof For Front Seat
Features of your vehicle Dual sunroof Sliding the sunroof for front seat dren could operate the sunroof, which could result in serious injury. Automatic reversal If an object or part of the body is detected while the sunroof is closing automatically, it will reverse direc- tion, and then stop.
Page 149: Sunshade
Features of your vehicle Dual sunroof The sunroof will open only while Sunshade pressing the control switch upward. for Front Seat Move the control switch forward to close the sunroof. It will close only while pressing the control switch. You cannot tilt the sunroof while sliding it or tilt the sunroof when it is completely closed.
Page 150: Resetting The Sunroof
Close the sunroof when driving been reset.) through dusty roads. Dust may * For more detailed information, cause a malfunction of the vehicle contact an authorized Kia dealer. system. NOTICE Resetting the sunroof If the sunroof is not reset when the...
Page 151: Sunroof Open Warning
Should you notice any change in the effort required to steer during nor- mal vehicle operation, have the power steering checked by an authorized Kia dealer.
Page 152 If the EPS does not operate nor- Take your vehicle to an authorized mally, the warning light will illumi- Kia dealer and have the vehicle nate on the instrument cluster. The checked as soon as possible. steering wheel may become difficult When the charging system warn- to control or operate abnormally.
Page 153: Tilt & Telescopic Steering Wheel
Features of your vehicle Steering wheel Adjusting steering wheel angle and steering effort may be high and height abnormal noise could occur. If tem- perature rises, the noise will disap- pear. This is a normal condition. When the vehicle is stationary, and the steering wheel is turned all the way to the left or right continu- ously, the steering wheel becomes...
Page 154: Heated Steering Wheel
Features of your vehicle Steering wheel Heated steering wheel (if equipped) Doing so may damage the surface of the steering wheel. With the ENGINE START/STOP but- If the surface of the steering ton in the ON position, pressing the wheel is damaged by a sharp heated steering wheel button object, damage to the heated warms the steering wheel.
Page 155: Mirrors
Features of your vehicle Mirrors Mirrors CAUTION This vehicle is equipped with inside Cleaning mirror and outside rearview mirrors to When cleaning the mirror, use a provide views of objects behind the paper towel or similar material vehicle. dampened with glass cleaner. Do not spray glass cleaner directly on the Inside rearview mirror mirror.
Page 156 Features of your vehicle Mirrors Electric Chromic Mirror (ECM) (if equipped) The electric rearview mirror auto- matically controls the glare from the headlights of the vehicles behind you at night or in low-light driving conditions. The sensor (3) mounted in the mir- ror senses the light level around the vehicle, and automatically controls OON048086NR...
Page 157 Features of your vehicle Mirrors The mirror indicator light will illu- poses (follow step 1 in "Program- minate. ming HomeLink" on page 4-57). Press the O button (2) to turn the automatic- dimming function off. Programming HomeLink The mirror indicator light will turn Your vehicle may require the off.
Page 158 Features of your vehicle Mirrors OON048401NR OON048402NR 1)Flashing 1)Flashing 2)Transmitter NOTICE 3. The HomeLink indicator light will flash, first slowly and then rap- For non-rolling code garage door idly. When the indicator light openers, follow steps 2-3. flashes rapidly, both buttons may For rolling code garage door open- be released.
Page 159 Features of your vehicle Mirrors may make the following training mitter of the device may also be procedures quicker & easier.) used at any time. The HomeLink 4. Locate the "learn" or "smart" but- Wireless Controls system (once pro- ton on the device's motor head grammed) or the original hand-held unit.
Page 160 Features of your vehicle Mirrors Reprogramming a single HomeLink HomeLink" on page 4-57) while you button press and re-press ("cycle") your handheld transmitter every two To program a device to HomeLink seconds until the frequency signal using a HomeLink button that has has been learned.
Page 161: Outside Rearview Mirror
Features of your vehicle Mirrors Outside rearview mirror moving. This could result in loss of control. Your vehicle is equipped with both left-hand and right-hand outside rearview mirrors. Adjusting the outside rearview mir Be sure to adjust the mirror angles rors before driving.
Page 162 Features of your vehicle Mirrors Folding the outside rearview mirror 1. To fold the outside rearview mir- ror depress the button (1). Manual type 2. To unfold it, depress the button To fold the outside rearview mir- (1) again. The mirror will fold or unfold ror, grasp the housing of the mir- ror and then fold it toward the when the door is locked or...
Page 163 Features of your vehicle Mirrors Reverse parking aid function (if The outside rearview mirrors will equipped) automatically revert to their original positions under the following condi- tions: 1. The ENGINE START/STOP button is in the OFF position. 2. Shift lever is moved to any posi- tion except R (Reverse).
Page 164: Instrument Cluster
Features of your vehicle Instrument cluster Instrument cluster Type A OON048100NR Type B OON048101NR * The actual cluster and contents of the LCD display in the vehicle may differ from the illustration. 1. Tachometer 2. Speedometer 3. Engine coolant temperature gauge 4.
Page 165: Instrument Cluster Control
Features of your vehicle Instrument cluster Instrument cluster control Gauges The brightness of the instrument The gauges display various informa- panel illumination is changed by tion such as the speed of the vehi- pressing the illumination control cle, the amount of charge of the button ("+"...
Page 166 Features of your vehicle Instrument cluster Use the tachometer to select the CAUTION correct shift points and to prevent If the gauge pointer moves beyond lugging and/or over-revving the the normal range area toward the engine. "H" position, it indicates overheating that may damage the engine.
Page 167 Features of your vehicle Instrument cluster Odometer NOTICE The fuel tank capacity is given in "Recommended lubricants and capacities" on page 8-6. The fuel gauge is supplemented by a low fuel warning light, which will illuminate when the fuel tank is nearly empty.
Page 168: Transmission Shift Indicator
Features of your vehicle LCD display ately, like a normal thermometer LCD display would, so as to prevent the driver The LCD display shows trip com- from being distracted. puter and other information. To change the temperature unit (from F to C or from C to F) LCD Display Control The temperature unit can be The LCD display modes can be...
Page 169: Lcd Display Modes
Features of your vehicle LCD display LCD Display Modes The LCD display provides 5 modes. You can switch modes by pressing the Mode button. Mode Trip Computer Assist Master warning Turn By Turn User Settings (TBT) Fuel Economy Route Guidance Lane Safety Head-Up Display The Master Warning mode...
Page 170 Features of your vehicle LCD display Trip Computer mode Assist mode OON048111NR OON048112NR The trip computer mode displays This mode displays the state of: information related to vehicle driv- Lane Safety system ing parameters including fuel econ- Driver Attention Warning (DAW) omy, tripmeter information and TPMS vehicle speed.
Page 171 Features of your vehicle LCD display This warning light informs the driver 6. Convenience the following situations. 7. Service Interval 8. Other features LED headlamp malfunction (if 9. Language equipped) 10.Reset Lamp malfunction High Beam Assist malfunction (if The information provided may dif- equipped) fer depending on which functions At this time, a Master Warning icon...
Page 172 Features of your vehicle LCD display 1. Head-Up Display (if equipped) Explanation Enable Head-Up Display If this item checked, the Head-Up Display will be activated. Adjust the height (1~20) of the HUD image on the HUD Display Height screen. Rotation Adjust the degree (-5~+5) of the HUD rotation.
Page 173 Features of your vehicle LCD display Explanation Active assist, Warning only, Off Forward Safety To select the functions. Blind-Spot view Safe Exit Assist (SEA) Active Assist Blind-spot safety Warning Only To select the functions. Rear Cross-Traffic Safety: You can turn on/off the Rear Cross-Traffic Collision Warning (RCCW) and Rear Cross- Traffic Collision-Avoidance Assist (RCCA).
Page 174 Features of your vehicle LCD display Explanation If this item is checked, the power liftgate function will be Power Liftgate (if activated. equipped) * For more details, refer to "Power liftgate (if equipped)" on page 4-26. Power Liftgate Speed Normal/ Fast (if equipped) You can select the operating speed of the power liftgate.
Page 175 Features of your vehicle LCD display 6. Convenience (if equipped) Explanation Off: The seat easy access function will be deactivated. Normal/Extended: When you turn off the engine, the driver's seat will automatically move rear 3 in (7.6 cm) (Enhanced) for you to enter or exit the vehicle more com- Seat (forward/back- fortably.
Page 176 Features of your vehicle LCD display 7. Service Interval Explanation If this item is checked, the Service Interval function will be Enable Service Interval activated. If the service interval menu is activated, you may adjust the Adjust Interval time and distance. Reset To reset the service interval function.
Page 177 Features of your vehicle LCD display 9. Language (if equipped) Explanation Language To select language. 10. Reset Explanation You can reset the menus in the User Settings mode. All Reset menus in the User Settings mode are reset to factory set- tings, except language and service interval.
Page 178: Lcd Displays
Features of your vehicle LCD displays Trip modes LCD displays To change the trip mode, scroll the LCD displays show the following toggle the switch ( ) on the information to drivers. steering wheel. Trip information LCD modes Warning messages Trip information (trip computer) The trip computer is a microcom- puter-controlled driver information...
Page 179 Features of your vehicle LCD displays Average Fuel Economy (1) Instant Fuel Economy (2) The average fuel economy is cal- This mode displays the instant culated by the total driving dis- fuel economy. tance and fuel consumption since the last average fuel economy Accumulated Info display reset.
Page 180: Drive Mode
Features of your vehicle LCD displays NOTICE NOTICE The vehicle must be driven for a The vehicle must be driven for a minimum of 0.19 miles (300 minimum of 0.19 miles (300 meters) since the last ignition cycle meters) since the last ignition cycle before the average accumulated before the average accumulated driving information is recalculated.
Page 181: Service Mode
Features of your vehicle LCD displays Service Mode Driving info display This mode reminds you of scheduled At the end of each driving cycle, the maintenance information. Driving Info message is displayed. Service in It calculates and displays when you need a scheduled maintenance ser- vice (mileage or days).
Page 182: Lcd Display Messages
If the steering wheel lock system has a problem. In this case, have Engine has overheated your vehicle inspected by an autho- rized Kia dealer. This warning message illuminates when the engine coolant tempera- Check Steering Wheel Lock system ture is above 248 F (120 C). This...
Page 183 Features of your vehicle LCD displays Door, Hood, Liftgate open warning Sunroof open warning display (if display equipped) OON048119NR OON048120NR This warning is displayed if any door This warning is displayed if you turn or the hood or the liftgate is left off the vehicle when the sunroof is open.
Page 184 Features of your vehicle LCD displays * For more details, refer to "Tire This indicator displays which wiper Pressure Monitoring System speed is selected using the wiper (TPMS)" on page 6-9. control. You can activate or deactivate Lights mode Wiper/Lights Display function from the User Settings mode in the clus- ter LCD display.
Page 185 Attention Warning system. In this external electrical devices are case, have the vehicle inspected by removed, have your vehicle an authorized Kia dealer. inspected by an authorized Kia dealer. * For more information, refer to "Driver Attention Warning (DAW) Press START button again for system"...
Page 186 Electronic Control Suspension (ECS) ing chime sounds once. system. In this case, have your vehi- The temperature on the outside cle inspected by an authorized Kia temperature gauge is below dealer. approximately 40 F (4 C). NOTICE...
Page 187: Warning And Indicator Lights
2. With the vehicle stopped, check tem (SRS). the brake fluid level immediately In this case, have the vehicle inspected by an authorized Kia and add fluid as required (For dealer. more details, refer to "Brake fluid" on page 7-21). Then check all brake components for fluid leaks.
Page 188 In this case, have your vehicle This warning light illuminates: towed to an authorized Kia dealer Once you set the ENGINE START/ and inspected. STOP button to the ON position. - It illuminates for approximately Dual-diagonal braking system 3 seconds and then goes off.
Page 189 Have your vehicle inspected by an 2. Turn the engine off and check the authorized Kia dealer as soon as alternator drive belt for looseness possible. or breakage. In this case, have the vehicle...
Page 190 Otherwise, the could result in loss of engine power. engine may be damaged. In this case, have the vehicle inspected by an authorized Kia CAUTION dealer. Engine damage If the engine is not stopped immedi-...
Page 191 Tire Pressure Monitoring Sys- position off the road. tem (TPMS). In this case, have your vehicle inspected by an authorized Kia Master warning light dealer. * For more details, refer to "Tire This warning light informs the...
Page 192 LED headlamp. Electronic Parking Brake (EPB) In this case, have your vehicle warning light (if equipped) inspected by an authorized Kia dealer. This warning light illuminates: CAUTION Once you set the ENGINE START/ STOP button to the ON position.
Page 193: Indicator Lights
AWD. STOP button to the ON position. In this case, have your vehicle - It illuminates for approximately inspected by an authorized Kia 3 seconds and then goes off. dealer. When you deactivate the ESC system by pressing the ESC OFF button.
Page 194 ENGINE START/ battery voltage. It does not mean STOP button is ON. the system is malfunctioning. In this case, have your vehicle inspected by an authorized Kia dealer. Turn signal indicator light This indicator light blinks: This indicator light blinks:...
Page 195 Features of your vehicle Warning and indicator lights Lane Keeping Assist (LKA) indica High beam indicator light (if equipped) This indicator light illuminates: The LKA indicator will illuminate When the headlights are on and in when you turn the LKA on by press- the high beam position.
Page 196 Yellow When there is a malfunc- SMART mode indicator tion with the auto hold system. equipped) In this case, have your vehicle inspected by an authorized Kia This indicator light illuminates: dealer. When you select "SMART" mode * For more details, refer to "AUTO as drive mode.
Page 197: Head-Up Display (Hud) (If
When the HUD needs inspection or repair, have your vehicle equipped) inspected or repaired by an The Head-Up Display (HUD) is a authorized Kia dealer. transparent display that projects an image of certain information from HUD ON/OFF the instrument cluster and naviga- tion system on the windshield glass.
Page 198 Features of your vehicle Head-Up Display (HUD) HUD Information HUD Setting On the LCD display, you can change the HUD settings as follows. 1. Display height 2. Rotation 3. Brightness 4. Content selection 5. Speedometer size 6. Speedometer color * For more details, refer to "LCD Dis- play Modes"...
Page 199: Parking Distance Warning-Reverse System
Features of your vehicle Parking distance warning-reverse system Parking distance warning- obstructions before moving the vehicle in any direction. Stop imme- reverse system (if equipped) diately if you are aware of a child The parking distance warning- anywhere near your vehicle. Some reverse assists the driver when the objects may not be detected by the vehicle is moving in reverse by chim-...
Page 200 Features of your vehicle Parking distance warning-reverse system When more than two objects are cycle engines, or truck air brakes) sensed at the same time, the are within range of the sensor. closest one will be recognized There is rain or water spraying first.
Page 201 If an incorrect distance. Use caution. this occurs, have your vehicle When the sensor is frozen or cov- checked by an authorized Kia dealer ered with snow, dirt, or water, the as soon as possible. sensor may be inoperative until...
Page 202: Parking Distance Warning System
Features of your vehicle Parking distance warning system Parking distance warning sys- front and behind you as you would in a vehicle without parking distance tem (if equipped) warning. The parking distance warning assists the driver during movement WARNING of the vehicle by chiming if any The parking distance warning is a object is sensed within the distance supplemental system only.
Page 203 Features of your vehicle Parking distance warning system parking distance warning when The side sensors are activated you shift the gear to the R when you shift the gear to the R (Reverse) position. (Reverse) position. The sensing distance while back- If the vehicle speed is above 12.4 ing up is approximately 47 in (120 mph (20 km/h), the system auto-...
Page 204 Features of your vehicle Parking distance warning system Sensor is covered with foreign NOTICE matter, such as snow or water, or The actual warning sound and the sensor cover is blocked. (It will indicator may differ from the operate normally when the mate- illustration depending on the rial is removed or the sensor is no objects or sensor status.
Page 205 Features of your vehicle Parking distance warning system The following objects may not be NOTICE recognized by the sensor: This system can only sense objects Sharp or slim objects such as within the range and location of the ropes, chains or small poles. sensors;...
Page 206: Rear View Monitor System
For detailed information, refer to a intermittently. separately supplied manual. (blinks) is displayed. If this occurs, have your vehicle checked by an authorized Kia dealer as soon as possible. NOTICE Your new vehicle warranty does not cover any accidents or damage to...
Page 207: Rear View Monitor Top View
Features of your vehicle Surround View Monitoring (SVM) system the shift lever is moved from R Surround View Monitoring (Reverse) to D (Drive) with vehicle (SVM) system (if equipped) speed below 9 mph (15 km/h). Surround View Monitoring (SVM) is the parking support system that Rear view monitor Top view...
Page 208 - The liftgate is opened. - The driver's door is opened. - The passenger's door is opened. - The outside rearview mirror is folded. If the system is not operating normally, the system should be checked by an authorized Kia dealer.
Page 209: Blind-Spot View Monitor (Bvm) System
Features of your vehicle Blind-spot View Monitor (BVM) system Blind-spot View Monitor (BVM) WARNING system (if equipped) ALWAYS look around your vehicle The Blind-spot View Monitor (BVM) to make sure there are no objects system displays the passenger-side or obstacles before moving the rear areas in the cluster when the vehicle in any direction to prevent system is activated.
Page 210: Lighting
Features of your vehicle Lighting Lighting Daytime Running Light (DRL) The Daytime Running Light (DRL) This vehicle is equipped with a vari- can make it easier for others to see ety of lights to illuminate the inte- the front of your vehicle during the rior and exterior of the vehicle.
Page 211 Features of your vehicle Lighting 4. Headlight position NOTICE The ENGINE START/STOP button Position & Tail lamp must be in the ON position to turn on the headlights. Auto light OON048417NR When the light switch is in the posi- tion lamp position, the tail, license and instrument panel lights will turn OON048414NR When the light switch is in the AUTO...
Page 212: Operating High Beam
Features of your vehicle Lighting CAUTION WARNING Never place anything over the High beams sensor (1) located on the instru- Do not use high beam when there ment panel as this will ensure are other vehicles in front of or better auto-light system control.
Page 213: Operating Turn Signals And Lane Change Signals
Features of your vehicle Lighting Operating turn signals and lane NOTICE change signals If an indicator flash is abnormally quick or slow, a bulb may be burned out or have a poor electrical connec- tion in the circuit. One-touch lane change function To activate a one-touch lane change function, move the turn signal lever slightly and then release it.
Page 214: Operating Front Fog Light
Features of your vehicle Lighting Operating front fog light (if equipped) Fog lights are designed to provide improved visibility when visibility is poor due to fog, rain or snow, etc. OON048420NR Operating the HBA The HBA can be operated using the light switch.
Page 215 If the light switch is pulled minate. Take your vehicle to an towards you when the high beam authorized Kia dealer and have the is turned on using the HBA, the system checked. low beam will turn on and the HBA turn off.
Page 216 - When the road conditions are assemble it again, take your vehi- poor such as being wet, iced or cle to an authorized Kia dealer covered with snow. and have the system checked. - When a vehicle suddenly When you replace or reinstall the appears from a curve.
Page 217: Wipers And Washers
Features of your vehicle Wipers and washers Wipers and washers B: Intermittent control wipe time adjustment The wipers and washers remove C: Wash with brief wipes (front) foreign substances from the wind- shield and rear window, helping to D: Rear wiper/washer control maintain visibility.
Page 218 Features of your vehicle Wipers and washers controls the wiping cycle for the NOTICE proper interval. The more it rains, If there is heavy accumulation of the faster the wiper operates. When snow or ice on the windshield, the rain stops, the wiper stops. defrost the windshield for about 10 To vary the speed setting, turn the minutes, or until the snow and/or...
Page 219: Operating Windshield Washer
Features of your vehicle Wipers and washers Operating windshield washer CAUTION Use this function when the wind- When washing the vehicle, set the shield is dirty. wiper switch in the OFF position to stop the auto wiper operation. The wiper may operate and be damaged if the switch is set in AUTO mode while washing the vehicle.
Page 220: Operating Rear Window Wiper And Washer Switch
Features of your vehicle Wipers and washers CAUTION Washer pump To prevent possible damage to the washer pump, do not operate the washer when the fluid reservoir is empty. CAUTION ODEEV068146NR Wipers & windshields HI: Continuous wipe To prevent possible damage to LO: Intermittent wipe the wipers or windshield, do not OFF: OFF...
Page 221: Interior Lights
Features of your vehicle Interior lights Interior lights Map lamp This vehicle is equipped with lights throughout the vehicle to illuminate the interior. WARNING Interior Lights Do not use the interior lights when driving in the dark. Accidents could happen because the view may be OON048011NR obscured by interior lights.
Page 222: Room Lamp
Features of your vehicle Interior lights - The map lamp and room lamp Type B will go out immediately if the ENGINE START/STOP button is changed to the ON position or all doors are locked. - To turn off the DOOR mode, press the DOOR button (2) once again (not pressed).
Page 223: Vanity Mirror Lamp
Features of your vehicle Interior lights Vanity mirror lamp Glove box lamp (if equipped) The glove box lamp comes on when the glove box is opened. OON048422NR Opening the lid of the vanity mirror will automatically turn on the mirror OON048015NR light.
Page 224: Welcome System
Features of your vehicle Welcome system Welcome system (if equipped) Pocket lamp (if equipped) When all doors are locked and The welcome system is a function closed, the pocket lamp will come on that illuminates the surroundings or for 15 seconds if any of the follow- the interior when the driver ing occurs: approaches or exits the vehicle.
Page 225: Defroster
Features of your vehicle Defroster Defroster Type A The vehicle is equipped with a defroster for removing frost or fog from the rear window. CAUTION Conductors To prevent damage to the conduc- tors bonded to the inside surface of the rear window, never use sharp OON048302NR instruments or window cleaners Type B...
Page 226: Operating Outside Mirror Defroster
Features of your vehicle Climate control system To turn off the defroster: Climate control system Press the rear window defroster The climate control system uses button again. cooling and heating to help maintain a pleasant environment inside the Operating outside mirror defroster vehicle.
Page 227 CAUTION The air conditioning system should Air conditioning (A/C) only be used with the windows and All Kia air conditioning systems are sunroof closed to prevent conden- filled with R-1234yf refrigerant. sation inside the vehicle that may 1. Start the vehicle. Press the A/C cause damage to electrical compo- button.
Page 228: Climate Control Air Filter
This is a normal side (fresh) air position is selected. If characteristic of system opera- this happens, have the climate con- tion. trol air filter replaced by an autho- rized Kia dealer.
Page 229: Checking The Amount Of Air Conditioner Refrigerant And Compressor Lubricant
Overfilling also by trained and certified Kia techni- has a negative impact on the air cians. conditioning system.
Page 230: Air Conditioning Refrigerant Label
Features of your vehicle Climate control system Air conditioning refrigerant label Example OSK3068035NR * The actual air conditioning refrig- erant label in the vehicle may dif- fer from the illustration. Each symbol and specification on the air conditioning refrigerant label is represented below: 1.
Page 231: Manual Climate Control System
Features of your vehicle Manual climate control system Manual climate control system (if equipped) The manual climate control system uses cooling and heating to help main- tain a pleasant environment inside the vehicle. OON048300NR 1. Fan speed control knob 2. Rear window defroster button 3.
Page 232: Heating And Air Conditioning
Features of your vehicle Manual climate control system Heating and air conditioning OON048303NR 1. Start the engine. 2. Set the mode to the desired position. For improving the effectiveness of heating and cooling; Heating: Cooling: 3. Set the temperature control to the desired position. 4.
Page 233 Features of your vehicle Manual climate control system Mode selection Floor/Defrost-Level (A, C, D, E) The mode selection knob controls Most of the air flow is directed to the direction of the air flow through the floor and the windshield with a the ventilation system.
Page 234 Features of your vehicle Manual climate control system MAX A/C selection Recirculated air position With the recirculated air To operate the MAX A/C, turn the position selected, air from temperature knob all the way to the the passenger compart- left. Air flow is directed toward the ment will be drawn through the upper body and face.
Page 235 Features of your vehicle Manual climate control system Do not sleep in a vehicle with the Setting the fan speed control knob to the "0" position turns off air conditioning or heating system the fan. on. It may cause serious harm or death due to a drop in the oxygen Turning off the blowers level and/or body temperature.
Page 236: Controlling Rear Climate
Features of your vehicle Manual climate control system Controlling rear fan speed Controlling rear climate Front climate control panel Rear OON048016NR OON048310NR 1. Rear temperature control button 1. Press the REAR button located on 2. Rear air conditioning OFF button the front climate control panel 3.
Page 237 Features of your vehicle Manual climate control system 1. To change the rear fan speed, 1. To change the rear air tempera- ture, press the button ( ) for press the button ( ) for higher warmer air or press the button speed, or press the button ( ) for ) for cooler air.
Page 238 Features of your vehicle Manual climate control system To turn off the rear climate con- trol system, press the rear blower OFF button Selecting rear mode OON048315NR : Air discharged from [A] spreads over a wider area. : Air discharged from [B] has a OON048313NR centered and direct flow.
Page 239 Features of your vehicle Manual climate control system Opening/closing the vent and adjusting the direction You can set the direction of air by adjusting the knob of air vents located above the 2nd-row and 3rd-row seats. Adjust the outer and central parts of the air vent to the desired positions.
Page 240: Automatic Climate Control System
Features of your vehicle Automatic climate control system Automatic climate control system (if equipped) The automatic climate control system uses cooling and heating to help maintain a pleasant environment inside the vehicle. OON048301NR 1. Driver's temperature control knob 2. AUTO (automatic control) button 3.
Page 241: Heating And Air Conditioning Automatically
Features of your vehicle Automatic climate control system Heating and air conditioning auto- - Front windshield defroster but- matically ton (Press the button one more 1. Press the AUTO button. time to deselect the front The modes, fan speeds, air intake windshield defroster function.
Page 242: Heating And Air Conditioning Manually
Features of your vehicle Automatic climate control system Heating and air conditioning manually The heating and cooling system can be controlled manually by pressing but- tons or turning knob(s) other than the AUTO button. OON048303NR In this case, the system works sequentially according to the order of but- tons or knob(s) selected.
Page 243 Features of your vehicle Automatic climate control system Press the AUTO button in order to Floor-Level (A, C, D, E) convert to fully automatic control of Most of the air flow is directed to the system. the floor, with a small amount of the air being directed to the wind- Mode selection shield and side window defrosters.
Page 244 Features of your vehicle Automatic climate control system Temperature control Adjusting the driver and passenger side temperature, fan speed and Driver's side Passenger's side air flow direction equally OON048317NR OON048320NR The temperature will increase to the 1. Press the "SYNC" button to adjust maximum (HI) by turning the knob the driver and front/rear passen- all the way to the right.
Page 245 Features of your vehicle Automatic climate control system Adjusting the driver and passenger To change the air intake control side temperature, fan speed and position: air flow direction individually Push the desired control button. Press the "SYNC" button again to adjust the driver and front/rear Outside (fresh) air position passenger side temperature, fan...
Page 246 Features of your vehicle Automatic climate control system increase inside the vehicle which may fog the glass and obscure visi- bility. WARNING Recirculated Air Continued use of the climate control system in the recirculated air posi- tion can cause drowsiness or sleepi- OON048322NR ness, and loss of vehicle control.
Page 247: Controlling Rear Climate
Features of your vehicle Automatic climate control system Press the OFF button to turn off regardless of the front climate the front and rear air climate con- control system operation. trol system. However, you can still operate the Controlling rear fan speed mode and air intake buttons as Front climate control panel long as the ENGINE START/STOP...
Page 248 Features of your vehicle Automatic climate control system Rear climate control panel 2. Press the button (+) for warmer air or press the button (-) for cooler air. Rear climate control panel 1. Adjust the temperature by press- ing the rear temperature control button.
Page 249 Features of your vehicle Automatic climate control system To turn off the rear climate con- trol system, press the REAR but- ton located on the front climate control panel and OFF button on the audio or multimedia screen. Rear climate control panel OON048314NR The rear mode is selected by press- ing the rear mode selection button...
Page 250 Features of your vehicle Automatic climate control system Opening/closing the vent and adjusting the direction You can set the direction of air by adjusting the knob of air vents located above the 2nd-row and 3rd-row seats. Adjust the outer and central parts of the air vent to the desired positions.
Page 251: Windshield Defrosting And Defogging
Features of your vehicle Windshield defrosting and defogging Windshield defrosting and to improve heater and defroster efficiency and to reduce the prob- defogging ability of fogging up the inside of When the windshield is covered with the windshield. frost or moisture, the front view is blurred, so you should remove the CAUTION frost and moisture.
Page 252: Defrosting Outside Windshield With Manual Climate Control System
Features of your vehicle Windshield defrosting and defogging 1. Select any fan speed except "0" Defogging inside windshield with position. the automatic climate control 2. Select desired temperature. 3. Select the position. The outside (fresh) air and air conditioning will be selected auto- matically.
Page 253: Defrosting Outside Windshield With Automatic Climate Control
Features of your vehicle Windshield defrosting and defogging Canceling/returning automatic Defrosting outside windshield with defogging logic on manual climate automatic climate control control system OON048332NR 1. Set the fan speed to the highest OON048333NR position. 1. Turn the Engine Start/Stop to the ON position.
Page 254: Auto Defogging System (Ads) (Only
Features of your vehicle Windshield defrosting and defogging Canceling/returning automatic Auto Defogging System (ADS) (only defogging logic on automatic cli for automatic climate control sys- mate control system tem) (if equipped) The Auto Defogging System (ADS) reduces the probability of fogging up the inside of the windshield by automatically sensing the moisture inside the windshield.
Page 255: Additional Features Of Climate Control
Features of your vehicle Additional features of climate control Turning the ADS on or off Additional features of climate control Press the front windshield defroster button for 3 seconds when the ENGINE START/STOP Sunroof inside air recirculation (if button is in the ON position. equipped) When the ADS system is canceled, For air ventilation, when you open...
Page 256: Storage Compartment
Features of your vehicle Storage compartment Storage compartment To open the center console storage: Pull up the lever. These compartments can be used to store small items required by the Glove box driver or passengers. To avoid possible theft, do not leave valuables in the storage compartment.
Page 257: Sunglass Holder
Features of your vehicle Storage compartment Sunglass holder Luggage box OON048021NR OON048022NR To open the sunglass holder: You can place a first aid kit, a reflec- Press the cover and the holder will tor triangle, tools, etc. in the box for slowly open.
Page 258: Interior Features
Features of your vehicle Interior features Interior features Front There are various features inside the vehicle for the convenience of the occupants. Cup holder The front and rear seats of the vehicle have cup holders to accom- modate cups. OON048025NR WARNING 2nd row Hot liquids...
Page 259: Seat Warmer
Features of your vehicle Interior features 3rd row Rear seat OON048027NR OON048029NR Cups or small beverage cans may be With the ENGINE START/STOP but- placed in the cup holders. ton in the ON position: Push either of the toggle switch 2nd row center (if equipped) up (front seat) or push either of the switches (rear seat) to warm...
Page 260: Air Ventilation Seat
Features of your vehicle Interior features Automatic temperature control WARNING The seat warmer starts to auto- Seat warmer burns matically control the seat tempera- The seat warmer may cause burns, ture in order to prevent low- even at low temperature, if used temperature burns after being manually turned on.
Page 261: Sun Visor
Features of your vehicle Interior features Do not place heavy or sharp Rear seat objects on the seat. Those things may damage the air ventilation seat. Be careful not to spill liquid such as water or beverages on the seat. If you spill some liquid, wipe the seat with a dry towel.
Page 262: Power Outlet
Features of your vehicle Interior features Adjust the sun visor forward or 2nd row backward (4) as needed. The ticket holder (5) is provided for holding a tollgate ticket. CAUTION Vanity mirror lamp To prevent unnecessary charging system drain, close the vanity mir- ror cover securely after using the mirror.
Page 263: Usb Charger
Features of your vehicle Interior features Close the cover when not in use. Front Some electronic devices can cause electronic interference when plugged into a vehicle's power outlet. These devices may cause excessive audio static and mal- functions in other electronic sys- tems or devices used in your vehicle.
Page 264: Features Of Your Vehicle
Features of your vehicle Interior features 3rd row Use the official USB cable of the manufacturer of the digital device to be charged. Make sure that any foreign object, drinks, and water do not come into contact with the USB car charger.
Page 265 Features of your vehicle Interior features The AC inverter supplies 115 V / 150 When the AC inverter input volt- W electric power to operate electric age is less than 11.3 V, automati- cally turn off the power. accessories or equipment. AC inverter will operate as normal If you wish to use the AC inverter, when the voltage is increased.
Page 266: Wireless Smart Phone Charging System
Features of your vehicle Interior features Wireless smart phone charging smart phone, the wireless system (if equipped) charging function may not oper- ate properly. A wireless smart phone charging 2. Place the smart phone on the system is located in front of the center of the wireless charging center console.
Page 267 Features of your vehicle Interior features through warning messages and CAUTION sound (applicable for vehicles with Liquid in Wireless Smart Phone the voice guidance function) after Charger the 'Goodbye' function on the To prevent liquid from damaging the instrument cluster ends. wireless smart phone charging sys- For some manufacturers' smart tem in your vehicle, be sure not to...
Page 268 Features of your vehicle Interior features The wireless charging may not equipped in order to use the vehi- function properly when there is a cle's wireless charging system. heavy accessory cover on the Certain smart phones may display smart phone. messages on a weak current.
Page 269: Coat Hook
Features of your vehicle Interior features phone may experience higher CAUTION heat conduction. Hanging clothing When charging some cellular Do not hang heavy clothes, since phones with a self-protection they may damage the hook. feature, the wireless charging speed may decrease and the wireless charging may stop.
Page 270: Side Curtain
Features of your vehicle Interior features Side curtain (if equipped) Floor mat anchor(s) (if equipped) Type A / Type B OON048409NR To use the side curtain: ODEEV068210NR 1. Lift the curtain by the handle (1). When using a floor mat on the front 2.
Page 271: Luggage Net Holder
Do not stack floor mats on top of attach the luggage net. one another (e.g., all-weather If necessary, Kia recommends con- rubber mat on top of a carpeted tacting an authorized Kia dealer. floor mat). Only a single floor mat...
Page 272: Exterior Features
Distribute the your vehicle may be obtained from load as evenly as possible across the an authorized Kia dealer. crossbars (if equipped) and roof rack and secure the load firmly. NOTICE ROOF 220 lbs.
Page 273: Audio System
Features of your vehicle Audio system Audio system WARNING The vehicle center of gravity will NOTICE be higher when items are loaded If you install an aftermarket HID onto the roof rack. Avoid sudden head lamp, your vehicle's audio and starts, braking, sharp turns, electronic device may malfunction.
Page 274: Usb Port
Features of your vehicle Audio system USB port AM and FM radio signals are broad- cast from transmitter towers You can use an USB port to plug in located around your city. They are an USB. intercepted by the radio antenna on your vehicle.
Page 275 Features of your vehicle Audio system they curve around obstructions resulting in better signal coverage. FM radio station OSK3048403NR Flutter/Static - Weak FM signals or large obstructions between the transmitter and your radio can disturb the signal causing static or ODEEV068219NR fluttering noises to occur.
Page 276 Features of your vehicle Audio system Multi-Path Cancellation - Radio WARNING signals being received from sev- Cell phone use eral directions can cause distor- Do not use a cellular phone while tion or fluttering. This can be driving. Stop at a safe location to caused by a direct and reflected use a cellular phone.
Page 277: Declaration Of Conformity
Features of your vehicle Declaration of Conformity Declaration of Conformity Consult the dealer or an experi- enced radio/TV technician for help. This equipment has been tested and CAUTION found to comply with the limits for a Any changes or modifications to this Class B digital device, pursuant to device not explicitly approved by part 15 of the FCC Rules.
Page 279 Driving your vehicle Driving your vehicle Be sure the exhaust system does not leak......5-6 Before driving ................5-7 ENGINE START/STOP button ..........5-9 Illuminated ENGINE START/STOP button ......5-9 ENGINE START/STOP button position......... 5-9 Starting the engine .............. 5-11 Automatic transmission ............
Page 280 Driving your vehicle Deactivating the ISG.............5-47 ISG malfunction..............5-47 Battery Sensor Deactivation ..........5-48 Drive mode integrated control system (FWD)....5-49 Drive mode integrated control system (AWD)....5-53 Forward Collision-Avoidance Assist (FCA) Sensor fusion type (front Camera + front radar type) system ....5-57 Setting and activating the FCA ..........5-58 Setting the initial warning activation time.......5-58 Prerequisite for the FCA activation........5-59 FCA warning message and brake control......5-59...
Page 281 Driving your vehicle Setting vehicle-to-vehicle distance........5-79 When the lane ahead is clear: ..........5-80 When there is a vehicle ahead of you in your lane:..5-80 Radar to detect distance to the vehicle ahead ....5-82 SCC malfunction message ..........5-83 Limitations of the SCC ............
Page 282 Driving your vehicle Driver's Attention .............. 5-106 LKA function change ............5-107 Driver Attention Warning (DAW) system......5-108 Setting and activating the DAW ........5-108 Displaying the driver's attention level ......5-108 Taking a break..............5-109 Resetting the DAW ............5-109 DAW standby ..............
Page 283 Driving your vehicle RCCA alert................5-127 Detecting Sensor ..............5-129 Warning message...............5-129 Limitations of the RCCW/RCCA ........5-130 This device complies with Part 15 of the FCC rules..5-134 Special driving conditions ............5-135 Winter driving................5-139 Trailer towing ................5-143 Hitches .................5-144 Safety chains ..............5-144 Trailer brakes ..............5-144 Driving with a trailer ............5-145 Maintenance when trailer towing ........5-147...
Page 284: Driving Your Vehicle
"Floor" or "Face" and the fan at neath side of the vehicle, have the the highest speed. exhaust system checked as soon as possible by an authorized Kia dealer. WARNING Engine exhaust Do not inhale exhaust fumes or leave your engine running in a enclosed area for a prolonged time.
Page 285: Before Driving
Driving your vehicle Before driving Before driving WARNING Before getting into the vehicle, you Distracted driving should examine the car and its sur- Focus on the road while driving. The roundings. After getting into the driver's primary responsibility is in vehicle, you should check a number the safe and legal operation of the of things before driving.
Page 286 Driving your vehicle Before driving WARNING WARNING Fire risk Driving while intoxicated When you intend to park or stop the Do not drive while intoxicated. vehicle with the engine on, be care- Drinking and driving is dangerous. ful not to depress the accelerator Even a small amount of alcohol will pedal for a long period of time.
Page 287: Engine Start/Stop Button
Driving your vehicle ENGINE START/STOP button ENGINE START/STOP button NOTICE You are able to turn off the engine Illuminated ENGINE START/STOP (START/RUN) or vehicle power (ON), button only when the vehicle is not in motion. CAUTION In an emergency situation while the vehicle is in motion, you are able to turn the engine off and to the ACC position by pressing the ENGINE...
Page 288 Driving your vehicle ENGINE START/STOP button Some electrical accessories are WARNING operational. Never press the ENGINE START/ If the ENGINE START/STOP button is STOP button while the vehicle is in in the ACC position for more than 1 motion. This would result in loss hour, the button is turned off auto- of directional control and braking matically to prevent battery dis-...
Page 289: Starting The Engine
Driving your vehicle ENGINE START/STOP button Starting the engine with smart key Starting the engine At the time that the vehicle doors WARNING are opened or when the ENGINE START/STOP button is pressed the Do not start the vehicle with the vehicle will check for the smart key.
Page 290 Driving your vehicle ENGINE START/STOP button When the stop lamp fuse is blown, CAUTION you cannot start the engine nor- If the engine stalls while the vehicle mally. is in motion, do not attempt to Replace the fuse with a new one. move the shift lever to the P (Park) If it is not possible, you can start position.
Page 291: Automatic Transmission
Driving your vehicle Automatic transmission Automatic transmission For smooth operation, press the brake pedal when shifting from N The automatic transmission has 8 (Neutral) to a forward or reverse forward speeds and one reverse gear. speed. WARNING Automatic transmission Always check the surrounding areas near your vehicle for peo- ple, especially children, before shifting a vehicle into D (Drive) or...
Page 292: Transmission Ranges
Driving your vehicle Automatic transmission Do not shift from N (Neutral) or P CAUTION (Park) into D (Drive), or R The transmission may be damaged (Reverse) when the engine is if you shift into P (Park) while the above idle speed. vehicle is in motion.
Page 293 Driving your vehicle Automatic transmission Manual mode manages the driving CAUTION dynamics by automatically adjusting Always park the vehicle in "P" (Park) the steering effort, and the engine for safety and engage the parking and transmission control logic for brake. enhanced driver performance.
Page 294: Shift Lock System
Driving your vehicle Automatic transmission Shifting the transmission from P To maintain the required levels of (Park) into R (Reverse) vehicle performance and safety, the system may not execute cer- To shift the transmission from P tain gearshifts when the shift (Park) into R (Reverse): lever is operated.
Page 295: Engine Start/Stop Button Interlock System
Otherwise, the lower install the cap. gear may not be engaged. 7. Have your vehicle inspected by an authorized Kia dealer immedi- Always use the parking brake. Do ately. not depend on placing the trans- mission in P (Park) to keep the ENGINE START/STOP button inter- vehicle from moving.
Page 296 Driving your vehicle Automatic transmission unstuck, causing injury or damage WARNING to nearby people or objects. Always buckle-up! In a collision, an unbelted occupant is significantly more likely to be seriously injured Moving up a steep grade from a standing start or killed than a properly belted occupant.
Page 297: All Wheel Drive (Awd) System (If
AWD system. When the AWD warning light ( ) illuminates, have your vehicle checked by an autho- rized Kia dealer as soon as possible. WARNING To reduce the risk of SERIOUS INJURY or DEATH:...
Page 298 Driving your vehicle All Wheel Drive (AWD) system AWD transfer mode selection Transfer Selection mode Description mode AWD AUTO is used when driving on roads in normal conditions, roads in urban areas, and on highways. All wheels are in operation when a vehicle travels at a constant speed.
Page 299: For Safe All Wheel Drive (Awd) Operation
Driving your vehicle All Wheel Drive (AWD) system Do not try to drive in deep stand- NOTICE ing water or mud since such con- Normal road conditions ditions can stall your engine and Maintain AWD Auto mode when clog your exhaust pipes. Do not driving on roads in normal condi- drive down steep hills since it tions.
Page 300 Driving your vehicle All Wheel Drive (AWD) system WARNING Hills Driving across the contour of steep hills can be extremely dangerous. This danger can come from slight changes in the wheel angle which can destabilize the vehicle or, even if the vehicle is maintaining stability under power, it can lose that stabil- ity if the vehicle stops its forward...
Page 301 Driving your vehicle All Wheel Drive (AWD) system If you need to drive in the water, Since the driving torque is always stop your vehicle, set your trans- applied to the 4 wheels the per- fer to the AWD LOCK mode and formance of the AWD vehicle is drive at less than 5 mph (8 km/h).
Page 302 Driving your vehicle All Wheel Drive (AWD) system CAUTION NOTICE Mud or snow Moving the car forcibly to get out of mud or sand can cause damage/ If one of the front or rear wheels overheat of the engine or damage/ begins to spin in mud, snow, etc.
Page 303 Driving your vehicle All Wheel Drive (AWD) system 2. Place the front wheels on the roll WARNING tester (1) for a speedometer test Jacked vehicle as shown in the illustration. While the full-time AWD vehicle is 3. Release the parking brake. being raised on a jack, never start 4.
Page 304: Brake System
Driving your vehicle Brake system Brake system WARNING Your vehicle has power-assisted Steep hill braking brakes, parking brake, and various Avoid continuous application of the braking systems for safe driving. brakes when descending a long or steep hill by shifting to a lower gear. Power brakes Continuous brake application will cause the brakes to overheat and...
Page 305 Do not ignore high pitched wear sounds from your brakes. If you persists, have your vehicle towed to ignore this audible warning, you will an authorized Kia dealer and eventually lose braking perfor- inspected. mance, which could lead to a serious...
Page 306: Electronic Parking Brake (Epb)
Driving your vehicle Brake system Electronic Parking Brake (EPB) NOTICE After parking the vehicle, apply the Brake dust may accumulate on the Electronic Parking Brake (EPB) to wheels, even under normal driving prevent the vehicle from being conditions. Some dust is inevitable moved by the external force.
Page 307 Driving your vehicle Brake system Releasing the EPB with EPB switch Releasing the parking brake. Shifting the transmission out of P (Park) position. Starting the engine. In addition, they may operate vehicle equip- ment. Never leave children and animals unattended in the vehicle. When leaving the vehicle, always take the smart key with you and lock the vehicle.
Page 308 EPB has If you try to drive off while been released, have the system engaging the accelerator pedal checked by an authorized Kia dealer. with the EPB applied, but the EPB doesn't release automatically, a warning will sound and a message will appear.
Page 309 Driving your vehicle Brake system driver's door or liftgate is opened, A click or electric brake motor a warning will sound and a mes- whine sound may be heard while sage will appear. operating or releasing the EPB. These conditions are normal and indicate that the EPB is function- ing properly.
Page 310 If this occurs, have your vehicle will appear. checked by an authorized Kia dealer as soon as possible. The EPB malfunction indicator may illuminate when the ESC indicator comes on to indicate that the ESC is...
Page 311: Auto Hold
If there is a problem with the brake mally, take your vehicle to an pedal while driving, emergency authorized Kia dealer by loading the braking is possible by pulling up and vehicle on a flatbed tow truck and holding the EPB switch.
Page 312 Driving your vehicle Brake system Canceling Auto Hold function When coming to a complete stop by pressing the brake pedal, the AUTO HOLD indicator changes from white to green indicating the AUTO HOLD is engaged. The vehicle will remain at a standstill even if you release the brake pedal.
Page 313 Auto Hold may not work properly. - The vehicle is in a standstill for Take your vehicle to an authorized more than 10 minutes. Kia dealer and have the system - The vehicle is standing on a checked. steep slope.
Page 314: Anti-Lock Brake System (Abs)
Driving your vehicle Brake system sound and a message will appear on the LCD display. OON058075NR NOTICE OON058128NR At this moment, press the [AUTO When this message is displayed, the HOLD] button after closing the Auto Hold and EPB may not operate. driver's door, engine hood and lift- For your safety, press the brake gate.
Page 315 NOTICE problem with your ABS. Contact an A click sound may be heard in the authorized Kia dealer as soon as vehicle compartment when the possible. vehicle begins to move after the...
Page 316: Electronic Stability Control (Esc) System
ABS is normal. Otherwise, you may ESC applies the brakes on individual have a problem with the ABS. Con- wheels and intervenes with the tact an authorized Kia dealer as vehicle management system to sta- soon as possible. bilize the vehicle.
Page 317 Driving your vehicle Brake system The ESC system is an electronic approximately 3 seconds, then system designed to help the driver ESC is turned on. Press the ESC OFF button for at maintain vehicle control under least half a second after turning adverse conditions.
Page 318 Driving your vehicle Brake system button (ESC OFF ) for more than 3 seconds. ESC OFF indicator light (ESC OFF ) will illuminate and ESC OFF warning chime will sound. At this state, the car stability control function does not operate any more.
Page 319: Vehicle Stability Management (Vsm) System
Driving your vehicle Brake system ESC OFF usage ing responses under the following condition: When driving when driving on a slippery road or ESC should be turned on for daily when a change in the coefficient driving whenever possible. of friction between left and right To turn ESC off while driving, wheels is detected.
Page 320 No system, no light ( ) or EPS warning light matter how advanced, can compen- sate for all driver error and/or driv- remains on, take your vehicle to an ing conditions. Always drive authorized Kia dealer and have the responsibly. system checked.
Page 321: Trailer Stability Assist (Tsa) System
Driving your vehicle Brake system Trailer Stability Assist (TSA) sys- Assist Control (HAC) prevents the vehicle from rolling back by applying the brakes automatically for about The Trailer Stability Assist (TSA) is 2 seconds. operated as vehicle stability control system. The TSA has an effort to The brakes are released when the stabilize the vehicle and trailer when accelerator pedal is engaged or...
Page 322 Kia dealer for assistance. Under some conditions your park- Don't coast down hills with the ing brake can freeze in the vehicle out of gear.
Page 323: Idle Stop And Go (Isg) System
Driving your vehicle Idle Stop and Go (ISG) system Idle Stop and Go (ISG) system The Idle Stop and Go (ISG) system reduces fuel consumption by auto- matically shutting down the engine when the vehicle is at a standstill. (For example: red light, stop sign and traffic jam) The engine starts automatically as soon as the starting conditions are...
Page 324: Auto Start
Driving your vehicle Idle Stop and Go (ISG) system OON058134NR OON058135NR If you move the transmission The engine will start and the green lever from N to D (Manual mode) AUTO STOP indicator ( ) on the or R without depressing the brake instrument cluster will go out.
Page 325: Operating Conditions
Driving your vehicle Idle Stop and Go (ISG) system If you unfasten the seat belt or Deactivating the ISG open the driver's door while depressing the brake pedal. Operating conditions The ISG will operate under the fol- lowing condition: The driver's seat belt is fastened. The driver's door and engine hood are closed.
Page 326: Battery Sensor Deactivation
Driving your vehicle Idle Stop and Go (ISG) system The yellow AUTO STOP ( ) indi- cator on the instrument cluster will stay on after blinking for 5 seconds. The light on the ISG OFF button will illuminate. When the engine is in Idle Stop mode, it's possible to restart the engine without the driver taking any action.
Page 327: Drive Mode Integrated Control System (Fwd)
If this occurs, have the ISG system checked by an authorized Kia dealer. CAUTION Use only a genuine Kia ISG battery for replacement. If not, the ISG sys- OON058003NR tem may not normally operate. The mode changes whenever the Do not recharge the ISG battery DRIVE MODE knob is turned.
Page 328 Driving your vehicle Drive mode integrated control system (FWD) If it is in Eco mode, Eco mode will be SMART mode selects the proper driving mode set when the engine is restarted. among ECO, COMFORT and SPORT by judging the SMART mode driver's driving habits (i.e., mild or dynamic) from the brake pedal or...
Page 329 Driving your vehicle Drive mode integrated control system (FWD) Various driving situations, which period of time for next accelera- you may encounter in SMART mode tion. Thus, it is a normal driving situation, not indicating any mal- The driving mode automatically function.
Page 330 Driving your vehicle Drive mode integrated control system (FWD) mode, because the transmission and transmission control logic are condition is out of normal opera- changed to maximize fuel efficiency. tion condition. When ECO mode is selected by turning the Drive mode knob, the ECO indicator (green color) will SPORT mode illuminate.
Page 331: Drive Mode Integrated Control System (Awd)
Driving your vehicle Drive mode integrated control system (AWD) Drive mode integrated control system (AWD) The drive mode may be selected according to the driver's preference or road condition. OON058150NR OON058033NR The Drive mode is activated by turning the knob. The Drive mode is changes when- ever the knob is turned.
Page 332 Driving your vehicle Drive mode integrated control system (AWD) COMFORT mode: COMFORT mode provides soft driving and com- fortable riding. SPORT mode: SPORT mode pro- vides sporty but firm riding. ECO mode: ECO mode improves fuel efficiency for eco-friendly driving. The driving mode will be set to COMFORT or ECO mode when the OON058112NR...
Page 333 Driving your vehicle Drive mode integrated control system (AWD) torque, in accordance with the terns, when the vehicle starts to driver's driving habits. drive on an upward slope of a cer- tain angle. The driving mode NOTICE automatically returns to SMART ECO mode, when the vehicle When you mildly drive the vehicle enters a leveled road.
Page 334 Driving your vehicle Drive mode integrated control system (AWD) Limitation of SMART mode logic for enhanced driver perfor- mance. The SMART mode may be limited in When SPORT mode is selected by following situations. (The OFF indi- cator illuminates in those situa- turning the knob, the SPORT indi- tions.) cator (orange color) will illumi-...
Page 335: Forward Collision-Avoidance Assist (Fca) Sensor Fusion Type (Front Camera + Front Radar Type) System
Driving your vehicle Forward Collision-Avoidance Assist (FCA) Sensor fusion type (front Camera + front radar type) system Forward Collision-Avoidance NOTICE Assist (FCA) Sensor fusion type Fuel efficiency depends on the (front Camera + front radar driver's driving habit and road condi- type) system tion.
Page 336: Setting And Activating The Fca
When the warning light remains ON placing the ENGINE START/STOP with the FCA activated, take your button to the ON position and by vehicle to an authorized Kia dealer selecting: and have the system checked. 1. Press the MODE button (...
Page 337: Prerequisite For The Fca Activation
Driving your vehicle Forward Collision-Avoidance Assist (FCA) Sensor fusion type (front Camera + front radar type) system sitively. If you feel the warning vehicle condition. If you select activates too early, set the For- "Warning only", the FCA activates and produces only warning alarms ward Collision Warning to in accordance with the collision 'Later'.
Page 338 Driving your vehicle Forward Collision-Avoidance Assist (FCA) Sensor fusion type (front Camera + front radar type) system cle in front, insufficient braking dis- forward vehicle. (Depending on tance, pedestrian or cyclist the condition of the vehicle ahead and the environment surrounding detection.
Page 339: Brake Operation
Driving your vehicle Forward Collision-Avoidance Assist (FCA) Sensor fusion type (front Camera + front radar type) system Additionally, some vehicle system Brake operation intervention occurs by the engine In an urgent situation, the braking management system to help decel- system enters into the ready status erate the vehicle.
Page 340: Fca Front Radar / Camera Sensor
FCA system may not operate correctly. In this case, a warning message may not be dis- played. Have the vehicle inspected by an authorized Kia dealer. If the front bumper becomes damaged in the area around the radar sensor, the FCA system...
Page 341: Warning Message And Warning Light
In this Warning message and warning light case, have your vehicle inspected When the sensor cover is blocked by an authorized Kia dealer. with dirt, snow, or debris, the FCA Use only genuine parts to repair system operation may stop tempo- or replace a damaged sensor or rarily.
Page 342: Fca Malfunction
) will illu- the brake control function of the minate. In this case, take your vehi- FCA system, the vehicle's basic cle to an authorized Kia dealer and braking performance will operate have the system checked. normally. However, brake control...
Page 343: Limitations Of The Fca
Driving your vehicle Forward Collision-Avoidance Assist (FCA) Sensor fusion type (front Camera + front radar type) system The FCA system may activate reduce the driving speed in order to during braking and the vehicle maintain a safe distance. may stop suddenly shifting loose objects toward the passengers.
Page 344 Driving your vehicle Forward Collision-Avoidance Assist (FCA) Sensor fusion type (front Camera + front radar type) system The vehicle in front is too small to The vehicle drives inside a build- be detected (for example a ing, such as a basement parking motorcycle etc.) lot.
Page 345 Driving your vehicle Forward Collision-Avoidance Assist (FCA) Sensor fusion type (front Camera + front radar type) system When vehicle's front part is raised brake pedal to reduce your driving or lowered depending on loading speed in order to maintain a safe conditions distance.
Page 346 Driving your vehicle Forward Collision-Avoidance Assist (FCA) Sensor fusion type (front Camera + front radar type) system Driving on a slope Changing lanes OON058026NR OON058022NR The FCA performance may be lim- When a vehicle changes lanes in ited while driving upward or down- front of you, the FCA may not ward on a slope, and may not immediately detect the vehicle,...
Page 347 Driving your vehicle Forward Collision-Avoidance Assist (FCA) Sensor fusion type (front Camera + front radar type) system Recognizing pedestrians or cyclists you. In this case, you must maintain a safe braking distance, and if nec- The sensor may be limited when: essary, depress the brake pedal to The pedestrian or cyclist is not reduce your driving speed in order...
Page 348 Kia dealer If the bicycle material is not and have the system checked. reflected well on the radar.
Page 349: Radio Frequency Radiation Exposure Information
Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system Smart Cruise Control (SCC) with NOTICE Stop & Go system In some instances, the FCA system The Smart Cruise Control (SCC) is may be canceled when subjected to designed to allow you to program electromagnetic interference.
Page 350 Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system difficult to drive at a constant WARNING speed Smart Cruise Control system Lim- - When driving on rainy, icy, or itations snow-covered roads The Smart Cruise Control system is - When driving on a steep down- not a substitute for safe driving hill or uphill...
Page 351: Scc Switch
Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system Always pay continuous attention 1. Press the MODE button ( ) sev- to road and driving conditions eral times on the steering wheel even when the Smart Cruise Con- until 'User Settings' menu appears trol system is being operated.
Page 352: Converting To Cruise Control Mode
Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system Converting to Cruise Control mode WARNING When using the Cruise Control mode, you must manually adjust the distance to other vehicles by depressing the brake pedal. The system does not automatically adjust the distance to vehicles in front of you Setting the SCC speed...
Page 353: Increasing The Scc Set Speed
Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system to vehicle distance on the LCD condition ahead and driving condi- screen will illuminate. tion. The speed is set to 20 mph (30 km/h) when there is a preceding car in the front direction, and when it is set in the situation where the car is 0 ~20 mph (0~30...
Page 354: Decreasing The Scc Set Speed
Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system Accelerating temporarily with the CAUTION SCC on Check the traffic and driving condi- If you want to speed up tempo- tions before using the toggle switch. rarily when the cruise control is Driving speed may sharply increase, on, depress the accelerator pedal.
Page 355 Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system Canceled manually The ESC, ABS or Traction Control System (TCS) is operating. The ESC is turned off. The sensor or the cover is dirty or blocked with foreign matter. When the vehicle is stopped for over 5 minutes.
Page 356: Resuming The Scc Set Speed
NOTICE If the Smart Cruise Control is can- celed during a situation is that is not described above, take your vehicle to an authorized Kia dealer and have the system checked. OON058031NR If any method other than the "RES+" or "SET-" lever was used...
Page 357: Turning The Scc Off
Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system Turning the SCC off Select the appropriate distance according to road conditions and vehicle speed. Each time the button is pressed, the vehicle to vehicle distance changes as follows: For example, if you drive at 56 mph (90 km/h), the distance OON058029NR...
Page 358: When The Lane Ahead Is Clear
Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system When the lane ahead is clear: OON058085NR OON058092NR The vehicle speed will maintain the set speed. When there is a vehicle ahead of you in your lane: OON058084NR Your vehicle speed will slow down or speed up to maintain the selected distance.
Page 359 Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system WARNING OON058088NR If the vehicle ahead (vehicle speed: OON058079NR less than 20 mph (30 km/h) moves When using the Smart Cruise Con- to the next lane, the warning chime trol system: will sound and a message will The warning message appears...
Page 360: Radar To Detect Distance To The Vehicle Ahead
Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system starts moving, your vehicle will Always keep the area in front of the start as well. However, if the vehi- sensor clean. cle stops for more than 3 sec- onds, you must depress the Warning message accelerator pedal or push up the...
Page 361: Scc Malfunction Message
Smart Cruise Control system may not operate properly. If this occurs, take your vehicle to an authorized Kia dealer OON058089NR and have the system checked. The message will appear when the...
Page 362 Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system Driving on a slope The Smart Cruise Control system may not detect a moving vehicle in your lane, and then your vehicle could accelerate to the set speed. Also, the vehicle speed will decrease when the vehicle ahead is recog- nized suddenly.
Page 363 Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system A vehicle which moves into your lane Slow-moving vehicles or sudden- from an adjacent lane cannot be decelerating vehicles Stopped vehicles recognized by the sensor until it is in Vehicles with small rear profiles the sensor's detection range.
Page 364 Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system OON058023NR OON058040NR When driving in stop-and-go traffic, Always be cautious when approach- and a stopped vehicle in front of you ing vehicles that are taller with merges out of the lane, the system higher clearance, or vehicles carry- may not immediately detect the ing loads that stick out of the back...
Page 365 Driving your vehicle Smart Cruise Control (SCC) with Stop & Go system The Smart Cruise Control system Do not use Smart Cruise Control cannot recognize a stopped vehi- when the vehicle is towed. cle, pedestrians or an oncoming vehicle. NOTICE Always look ahead cautiously to prevent unexpected and sudden The Smart Cruise Control system...
Page 366: Radio Frequency Radiation Exposure Information
Driving your vehicle Leading vehicle departure alert system Radio frequency radiation exposure Leading vehicle departure alert information: system (if equipped) This equipment complies with FCC The leading vehicle departure alert radiation exposure limits set forth system alerts the driver of the for an uncontrolled environment.
Page 367: Operating Conditions
Driving your vehicle Leading vehicle departure alert system Operating conditions The vehicle departs automatically if the accelerator pedal is depressed or [RES +] or [SET -] switch is acti- vated when there is a vehicle in front. The SCC is deactivated if the accel- erator pedal is depressed or [RES +] or [SET -] switch is activated when there is no vehicle in front.
Page 368: Lane Following Assist (Lfa) System
Inspection or modification may be required when replacing parts related to the windshield or front camera. Have the system be inspected by an authorized Kia dealer. Depending on your surroundings and road conditions, the LFA sys- OON058018NR...
Page 369: Activating/Deactivating The Lfa
Driving your vehicle Lane Following Assist (LFA) system Keeping your hands off the wheel Operating conditions while driving will trigger the The system is activated when the hands-off warning and deactivate Lane Following Assist is selected the steering-assist system. from the User settings menu when the following conditions are satis- When driving at a high speed, the fied:...
Page 370: Warning Message
Driving your vehicle Lane Following Assist (LFA) system Once the LFA recognizes the lanes, the color of the lane on the screen will change from gray to white. WARNING The LFA system is designed to help the vehicle stay in its detected lane. It is a supplemental system only and is not a substitute for safe driving.
Page 371: Lfa Malfunction
OON058125NR wheel may occur. In this case, have the system Once the LFA is turned on or the checked by an authorized Kia dealer. lane is changed, the vehicle should be in the center of the road to CAUTION switch to the steering assist mode.
Page 372 Driving your vehicle Lane Following Assist (LFA) system If either of the lanes is not recog- When there are two or more lane nized, the steering is not assisted markings such as a construction If the radius is too small for the section, a designated lane, etc.
Page 373: Highway Driving Assist (Hda) System
Driving your vehicle Highway Driving Assist (HDA) system If there is not enough distance Highway Driving Assist (HDA) between the front car or if the system (if equipped) lane is covered by the car ahead The Highway Driving Assist (HDA) of me.
Page 374: Operating Conditions
Driving your vehicle Highway Driving Assist (HDA) system Steering control Operating conditions If you activate the HDA in the instrument cluster and the following conditions are met, the HDA system will be ready to operate, and the indicator light will come on green in the cluster.
Page 375 Driving your vehicle Highway Driving Assist (HDA) system Warning related to steering wheel When the hands-off warning lasts for a certain period of time OON058093NR The hands-off warning appears OON058141NR when the system detects that the If you keep your hands off the driver's hands are not on the steer- steering wheel even with the ing wheel while the HDA is in work.
Page 376 "AUTO" symbol will be dis- HDA, so have your vehicle inspected played in green with an indicative by an authorized Kia dealer. sound) CAUTION In the automatic speed setting mode, the set speed is automati-...
Page 377 Driving your vehicle Highway Driving Assist (HDA) system the highway, the HDA is automat- If the navigation system does not ically turned off so it requires operate properly, the HDA will not caution of the driver. work. When the type of road changes as the vehicle enters an urban high- WARNING way, a national road, or a general...
Page 378: Lane Keeping Assist (Lka) System
Driving your vehicle Lane Keeping Assist (LKA) system and the route is not automati- Lane Keeping Assist (LKA) sys- cally re-searched. - The speed limits have been The Lane Keeping Assist (LKA) is changed in some highway sec- designed to detect the lane markers tions.
Page 379 If so, the vehicle cle to an authorized Kia dealer may move out of its lane. Obey and have the system checked to speed limit when using LKA.
Page 380: Activating/Deactivating The Lka
Driving your vehicle Lane Keeping Assist (LKA) system Activating/deactivating the LKA If the function is turned off in User settings, the system will not operate. If you select Lane Keep- ing Assist / Lane Departure Warn- ing in User settings, the selected function will be activated.
Page 381 Driving your vehicle Lane Keeping Assist (LKA) system rely on the system but always check the road conditions when driving. OON058095NR If the vehicle leaves a lane, the lane marker you cross will blink on the OON058094NR LCD display and the warning sound is provided.
Page 382: Warning Message
Driving your vehicle Lane Keeping Assist (LKA) system The vehicle is between the lane If the vehicle leaves a lane, the lane markers. marker you cross will blink on the LCD display with steering wheel If the LKA can assist steering, a indi- vibration warning.
Page 383: Warning Light And Message
LKA is not working The LKA cannot assist steering if properly. In this case, have the sys- the vehicle follows lane marker tem checked by authorized Kia too close continuously before dealer. transition to steering assist mode.
Page 384: Driver's Attention
Driving your vehicle Lane Keeping Assist (LKA) system The steering will not be assisted - The lane marker is very thick or thin. when the lane is very wide or nar- row. - The lane marker is not visible There are more than two lane due to snow, rain, stain, a pud- markers such as a construction dle or other factors.
Page 385: Lka Function Change
Driving your vehicle Lane Keeping Assist (LKA) system cle ahead covers up the lane 3. Select one of the following options: line. Lane Keeping Assist: The Lane - You drive on a steep grade or a Keeping Assist mode guides the sharp curve.
Page 386: Driver Attention Warning (Daw) System
Driving your vehicle Driver Attention Warning (DAW) system Driver Attention Warning (DAW) system The Driver Attention Warning (DAW) system displays the condition of the driver's fatigue level and inattentive. Setting and activating the DAW To turn ON the DAW. 1. Press the MODE button ( ) sev- OON058100NR eral times on the steering wheel...
Page 387: Taking A Break
Driving your vehicle Driver Attention Warning (DAW) system Taking a break The driver unfastens the seat belt and then opens the driver's door. The "Consider taking a break" mes- Stop lasting more than 10 min- sage appears on the LCD display and utes.
Page 388 OON058104NR In this case, take your vehicle to an or attaching any types of coat- authorized Kia dealer and have the ings and accessories. If you dis- system checked. assemble a camera and assemble it again, take your...
Page 389: Blind-Spot Collision Warning (Bcw)/Blind-Spot Collision-Avoidance Assist (Bca) System
Driving your vehicle Blind-Spot Collision Warning (BCW)/Blind-Spot Collision-Avoidance Assist (BCA) system Blind-Spot Collision Warning CAUTION (BCW)/Blind-Spot Collision- The Driver Attention Warning sys- Avoidance Assist (BCA) system tem may not provide alerts in the following situations: The Blind-Spot Collision Warning (BCW)/Blind-Spot Collision-Avoid- Not properly recognize lane.
Page 390: Blind-Spot Collision-Avoidance Assist (Bca)
Driving your vehicle Blind-Spot Collision Warning (BCW)/Blind-Spot Collision-Avoidance Assist (BCA) system around you, the warning will not occur. 2) Closing at high speed OON058153NR The BCA may activate the Electronic Stability Control (ESC) in accordance with a colliding possibility with an approaching vehicle while changing OON058043NR lanes.
Page 391: Activating/Deactivating The Bca And Bcw
Driving your vehicle Blind-Spot Collision Warning (BCW)/Blind-Spot Collision-Avoidance Assist (BCA) system proper and safe driving. Always BCW/BCA button is extin- drive safely and use caution when guished. changing lanes or backing up the If you press BCW/BCA button vehicle. The Blind-Spot Collision while 'Active assist' or 'Warning Warning (BCW) system and Blind- only' is selected the indicator on...
Page 392: Setting Initial Warning Activation Time
Driving your vehicle Blind-Spot Collision Warning (BCW)/Blind-Spot Collision-Avoidance Assist (BCA) system First stage alert Setting initial warning activation time 1. Press the MODE button ( ) sev- eral times on the steering wheel until 'User Settings' menu appears on the LCD. 2.
Page 393 Driving your vehicle Blind-Spot Collision Warning (BCW)/Blind-Spot Collision-Avoidance Assist (BCA) system WARNING The warning light on the outside rearview mirror will illuminate whenever a vehicle is detected at the rear side by the system. To avoid accidents, do not focus only on the warning light and neglect to see the surrounding of the vehicle.
Page 394: Bca Operation
Driving your vehicle Blind-Spot Collision Warning (BCW)/Blind-Spot Collision-Avoidance Assist (BCA) system BCA operation The vehicle direction is changed against the possible-colliding point. The steering wheel is abruptly moved. The brake pedal is depressed. After a certain period of time The driver should drive the vehicle in the middle of the vehicle lanes to keep the BCA in the ready status.
Page 395: Detecting Sensor (Camera And Radar)
Driving your vehicle Blind-Spot Collision Warning (BCW)/Blind-Spot Collision-Avoidance Assist (BCA) system Front camera is the responsibility of the driver to always drive cautiously to pre- The front camera is a sensor that vent unexpected and sudden situ- can detect lanes. If the sensor is ations from occurring.
Page 396: Warning Messages
In this case, a warning message may not be dis- played. Have the vehicle inspected by an authorized Kia dealer. Do not apply foreign objects such as a bumper sticker or a bumper guard near the radar sensor or apply paint to the sensor area.
Page 397 If the BCW/BCA still does not oper- ate normally, have your vehicle OON058108NR inspected by an authorized Kia If there is a problem with the BCW, a dealer. warning message will appear and the light on the switch will turn off.
Page 398: Limitations Of The Bcw/Bca
In this peripheral ground) abnormally case, have your vehicle inspected by contains metallic components an authorized Kia dealer. (i.e., possibly due to subway con- struction). Limitations of the BCW/BCA There is a fixed object near the The driver must be cautious in the vehicle, such as a guardrail.
Page 399 Driving your vehicle Blind-Spot Collision Warning (BCW)/Blind-Spot Collision-Avoidance Assist (BCA) system Driving on a curve away moves to the next lane from you. A motorcycle or bicycle is near. A flat trailer is near. If there are small objects in the detecting area such as a shopping cart or a baby stroller.
Page 400 Driving your vehicle Blind-Spot Collision Warning (BCW)/Blind-Spot Collision-Avoidance Assist (BCA) system Driving where the road is merging/ Also, in certain instances the BCW/ dividing BCA may wrongly recognize the ground or structures. Always pay attention to road and driving conditions, while driving. Driving where the heights of the lanes are different OON058051NR...
Page 401: Rear Cross-Traffic Collision Warning (Rccw) / Rear Cross-Traffic Collision-Avoidance Assist (Rcca) System
Driving your vehicle Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Collision-Avoidance Assist (RCCA) system Driving where there is a structure Rear Cross-Traffic Collision beside the road Warning (RCCW) / Rear Cross- Traffic Collision-Avoidance Assist (RCCA) system (if equipped) When your vehicle is in reverse, Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Colli- sion-Avoidance Assist (RCCA) is...
Page 402: Rear Cross-Traffic Collision-Avoidance Assist (Rcca)
Driving your vehicle Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Collision-Avoidance Assist (RCCA) system Rear Cross-Traffic Collision-Avoid- Setting and activating the RCCW/ ance Assist (RCCA) RCCA The RCCA monitors approaching The driver can activate the systems cross traffic from the left and right by placing the ENGINE START/STOP side of the vehicle when your vehicle button to the ON position and by...
Page 403: Setting The Warning Volume Of The Rccw
Driving your vehicle Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Collision-Avoidance Assist (RCCA) system until 'User Settings' menu appears NOTICE on the LCD. If you change the warning volume, 2. Select 'Driver Assistance → Warn- the warning volume of other sys- ing Timing' with the MOVE switch ) and the OK button on tems may change.
Page 404: Rccw Alert
Driving your vehicle Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Collision-Avoidance Assist (RCCA) system RCCW alert Right If the vehicle detected by the sen- sors approaches from the rear left/ right side of your vehicle, the warn- ing chime will sound, the warning light on the outer side view mirror will blink and a message will appear on the LCD display.
Page 405: Rcca Alert
Driving your vehicle Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Collision-Avoidance Assist (RCCA) system RCCA alert Right If the risk of collision is detected while the RCCW is generated, brake control may be activated. The instrument cluster will inform the driver of the brake control.
Page 406 Driving your vehicle Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Collision-Avoidance Assist (RCCA) system Brake control is activated once for If any other warning sound such each right/left approach after as seat belt warning chime is shifting the shift lever to R already generated, the Rear (Reverse).
Page 407: Detecting Sensor
In this case, a When there is inclement weather warning message may not be dis- such as heavy snow or rain. played. Have the vehicle inspected by an authorized Kia dealer.
Page 408: Limitations Of The Rccw/Rcca
BCW turns off inspected by an authorized Kia due to malfunction. Have your vehi- dealer. cle inspected by an authorized Kia dealer. NOTICE Turn off the BCW and RCCW system Limitations of the RCCW/RCCA when a trailer or carrier is installed.
Page 409 Driving your vehicle Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Collision-Avoidance Assist (RCCA) system The rear bumper where the sen- Driving on a road where the sor is located is covered with a guardrail or wall is in double foreign object such as a bumper structure.
Page 410 Driving your vehicle Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Collision-Avoidance Assist (RCCA) system When the vehicle is in a complex The vehicle severely vibrates parking environment while driving over an uneven/ bumpy road, or concrete patch. The vehicle drives on a slippery surface due to snow, water pud- dle, or ice.
Page 411 Driving your vehicle Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Collision-Avoidance Assist (RCCA) system When the vehicle is parked diago When the vehicle is on/near a slope nally OON058063NR The RCCW/RCCA may not operate OON058062NR [A]: Vehicle properly when the vehicle is on/near a slope.
Page 412 Driving your vehicle Rear Cross-Traffic Collision Warning (RCCW) / Rear Cross-Traffic Collision-Avoidance Assist (RCCA) system The RCCW/RCCA may not operate This device complies with Part 15 of the FCC rules. properly when pulling in the vehicle to the parking space where there is Operation is subject to the following a structure at the back or side of two conditions:...
Page 413: Special Driving Conditions
Driving your vehicle Special driving conditions Special driving conditions narrower track to make them capa- ble of performing in a wide variety If driving conditions deteriorate due of offroad applications. to poor weather or road conditions, Specific design characteristics give you should pay even more attention them a higher center of gravity than than usual to your driving.
Page 414 Driving your vehicle Special driving conditions Utility vehicles have a significantly Rocking the vehicle higher rollover rate than other If it is necessary to rock the vehicle types of vehicles. to free it from snow, sand, or mud, Specific design characteristics first turn the steering wheel right (higher ground clearance, nar- and left to clear the area around...
Page 415 Driving your vehicle Special driving conditions h). Spinning the wheels at high improperly aimed headlights will speeds when the vehicle is station- make it much more difficult to see ary could cause a tire to overheat at night. which could result in tire damage Avoid staring directly at the head- that WARNING - Sudden may injure lights of oncoming vehicles.
Page 416 Driving your vehicle Special driving conditions If you believe you may have got- Avoid using worn or damaged tires which may result in reduced traction ten your brakes wet, apply them or tire failure. lightly while driving until normal Never exceed the maximum tire braking operation returns.
Page 417: Winter Driving
Driving your vehicle Winter driving Winter driving Tire chains are not legal in all states. Check state laws before fitting tire Severe weather conditions in the chains. winter result in greater wear and other problems. Snow tires To minimize the problems of winter If you mount snow tires on your driving, you should follow these vehicle, make sure they are radial...
Page 418 Driving your vehicle Winter driving Tire chains driving force, but will not prevent side skids. Do not install studded tires with- out first checking local and munic- ipal regulations for possible restrictions against their use. CAUTION When using AutoSock (fabric snow chain): OON058070NR Wrong size chains or improperly...
Page 419 Avoid sharp turns or lockedwheel best battery service" on page 7-29). braking. The level of charge in your battery can be checked by an authorized Kia CAUTION dealer or a service station. Chains that are the wrong size or improperly installed can damage your vehicle's brake lines, suspen- sion, body and wheels.
Page 420 Win- the items you may want to carry dow washer anti-freeze is available include tow straps or chains, flash- from an authorized Kia dealer and light, emergency flares, sand, most auto parts outlets. Do not use shovel, jumper cables, window...
Page 421: Trailer Towing
Your vehicle can tow a trailer. To types of vehicles or apparatus may identify what the vehicle trailering differ. Ask an authorized Kia dealer capacity is for your vehicle, you for further details before towing. should read the information in "Weight of the trailer"...
Page 422: Hitches
Use only a frame-mounted hitch maintain them properly. that does not attach to the Don't tap into or modify your bumper. Kia trailer hitch accessory is avail- vehicle's brake system. able at an authorized Kia dealer. WARNING Safety chains Trailer brakes...
Page 423: Driving With A Trailer
Driving your vehicle Trailer towing Following distance up the brake system. This is not a task for amateurs. Use an experi- Stay at least twice as far behind the enced, competent trailer shop for vehicle ahead as you would when this work.
Page 424 Use only an approved your transmission. trailer wiring harness. An authorized Kia dealer can assist Towing uphill you in installing the wiring harness. When towing a trailer on steep grades (in excess of 6%) pay close...
Page 425: Maintenance When Trailer Towing
Driving your vehicle Trailer towing temperature gauge to ensure the 4. Place chocks under the trailer wheels on the down hill side of engine does not overheat. the wheels. If the needle of the coolant tem- 5. Start the vehicle, hold the brakes, perature gauge moves across the shift to neutral, release the park- dial towards "H"...
Page 426: If You Do Decide To Pull A Trailer
Most When towing a trailer, be sure to importantly, all hitch nuts and bolts consult an authorized Kia dealer should be tight. for further information on addi - tional requirements such as a CAUTION towing kit, etc.
Page 427 Driving your vehicle Trailer towing To identify what the vehicle traile- Gross Axle Weight Gross Vehicle Weight ring capacity is for your vehicle, you should read the information in "Weight of the trailer" on page 5- 149. Weight of the trailer Tongue Load Total Trailer Weight OON058157NR...
Page 428: Vehicle Load Limit
Driving your vehicle Vehicle load limit Vehicle load limit WARNING The vehicle load limit is displayed on Trailer the tire and loading information Always follow the loading instruc- label on the driver's door. tions provided with your trailer. Improper loading can effect vehicle Tire and loading information label operation and result in an accident.
Page 429: Steps For Determining Correct Load Limit
Driving your vehicle Vehicle load limit ever, the seating capacity may be reduced based upon the weight of all of the occupants, and the weight of the cargo being carried or towed. Do not overload the vehicle as there is a limit to the total weight, or load limit including occupants and cargo, the vehicle can carry.
Page 430 Driving your vehicle Vehicle load limit 3. Subtract the combined weight of Example 1 the driver and passengers from XXX lbs. or XXX kg. 4. The resulting figure equals the available amount of cargo and luggage load capacity. For exam- ple, if the "XXX"...
Page 431: Certification Label
Driving your vehicle Vehicle load limit Certification label Item Description Total The certification label is located on 849 lbs. (385 the driver's door sill at the center Vehicle Capacity Weight pillar. Subtract Occupant 750 lbs. (340 Weight 150 lbs. (68 kg) 5 Available Cargo and Lug- 99 lbs.
Page 432: Vehicle Weight
Driving your vehicle Vehicle weight Vehicle weight WARNING This chapter will guide you in the Over loading proper loading of your vehicle and/ Never exceed the GVWR for your or trailer, to keep your loaded vehi- vehicle, the GAWR for either the cle weight within its design rating front or rear axle and vehicle capac- capability, with or without a trailer.
Page 433 Driving your vehicle Vehicle weight weight that can be carried by a sin- gle axle (front or rear). These num- bers are shown on the compliance label. The total load on each axle must never exceed its GAWR. GVW (Gross Vehicle Weight) This is the Base Curb Weight plus actual Cargo Weight plus passengers.
Page 435 What to do in an emergency What to do in an emergency Road warning................6-3 Hazard warning flasher............6-3 In case of an emergency while driving........6-4 If the vehicle stalls while driving .......... 6-4 If the engine stalls at a crossroad or crossing ....6-4 If you have a flat tire while driving........
Page 436: What To Do In An Emergency
What to do in an emergency Towing..................6-26 Towing without wheel dollies when using a towing service..................6-27...
Page 437: What To Do In An Emergency
What to do in an emergency Road warning WHAT TO DO IN AN EMER- located in the center fascia panel. All turn signal lights will flash simulta- GENCY neously. The hazard warning flasher oper- Road warning ates whether your vehicle is run- When in an emergency situation ning or not.
Page 438: In Case Of An Emergency While Driving
P. an authorized Kia dealer or seek 5. Have all passengers get out of the other qualified assistance. vehicle. Be sure they all get out on...
Page 439: If The Engine Will Not Start
(Neutral) or P (Park) and the 4. If the engine still does not start, emergency brake is set. call an authorized Kia dealer or 2. Check the battery connections to seek other qualified assistance. be sure they are clean and tight.
Page 440: Emergency Starting
What to do in an emergency Emergency starting Emergency starting WARNING When the vehicle will not start Frozen batteries because of low battery power, you Do not attempt to jump start the may need to jump start the vehicle. vehicle if the discharged battery is frozen as the battery may rupture Jump-starting or explode.
Page 441: Push-Starting
This acid is poisonous charging is not apparent, you should and highly corrosive. have your vehicle checked by an authorized Kia dealer. Jump-starting NOTICE 1. Make sure the booster battery is Make sure to connect one end of the...
Page 442: If The Engine Overheats
3. If the air conditioning is on, turn it authorized Kia dealer for assis- off. tance. 4. If engine coolant is running out 8. If you cannot find the cause of...
Page 443: Tire Pressure Monitoring System (Tpms)
Serious loss of coolant indicates there is a leak in the cooling system and this should be checked as soon as possible by an authorized Kia dealer. OON068002NR OON068003NR 1. Low tire pressure telltale / TPMS malfunction indicator 2.
Page 444: Effective Use Of The Tpms
What to do in an emergency Tire Pressure Monitoring System (TPMS) Tire Pressure Indicator vehicle control resulting in an acci- dent You can check the tire pressure in the assist mode on the cluster. Each tire, including the spare (if pro- - Refer to "User Settings mode"...
Page 445: Low Tire Pressure Telltale
If any of the below happens, have mination of the TPMS low tire pres- the system checked by an autho- sure telltale. rized Kia dealer. Your vehicle has also been equipped 1. The low tire pressure telltale / with a TPMS malfunction indicator...
Page 446: Tpms Malfunction Indicator
What to do in an emergency Tire Pressure Monitoring System (TPMS) stopping distances. You should stop the outside temperature is and check your tires as soon as pos- extremely high or low sible. When filling tires with more air, con- ditions to turn off the low tire pres- Inflate the tires to the proper pres- sure telltale may not be met.
Page 447: Tire Replacement With Tpms
Repair Agents may illuminate together with the Never use a puncture-repairing TPMS malfunction indicator. agent not approved by Kia to repair Have the system checked by an and/or inflate a low pressure tire. authorized Kia dealer as soon as The sealant not approved by Kia...
Page 448 Never use tire sealant if your vehicle after a few minutes of driving, is equipped with a TPMS. The liquid please visit an authorized Kia dealer. sealant can damage the tire pres- sure sensors. If an original mounted tire is...
Page 449: If You Have A Flat Tire (With Spare Tire)
What to do in an emergency If you have a flat tire (with spare tire) This device complies with Part 15 If you have a flat tire (with of the FCC rules. spare tire) Operation is subject to the following If you have a flat tire, you can two conditions: change the flat tire to a spare tire...
Page 450: Jack And Tools
What to do in an emergency If you have a flat tire (with spare tire) Jack and tools WARNING Changing tires Never attempt vehicle repairs in the traffic lanes of a public road or highway. Always move the vehicle com- pletely off the road and onto the shoulder before trying to change a tire.
Page 451 What to do in an emergency If you have a flat tire (with spare tire) can easily roll off the jack. Use vehi- To prevent the jack from "rattling" cle support stands. while the vehicle is in motion, store it properly. WARNING NOTICE Changing tires...
Page 452: Storing The Spare Tire
What to do in an emergency If you have a flat tire (with spare tire) Turn the tool counterclockwise Storing the spare tire until the spare tire reaches the ground. OON068010NR 1. Place the wheel under the vehicle and install the retainer through OON068007NR 4.
Page 453 What to do in an emergency If you have a flat tire (with spare tire) the vehicle completely off the 4. Remove the wheel lug nut wrench, jack and spare tire from road on level, firm ground away the vehicle. from traffic before trying to change a tire.
Page 454 What to do in an emergency If you have a flat tire (with spare tire) no person remain in a vehicle that is being jacked. 6. Loosen the wheel lug nuts coun- terclockwise one turn each, but do not remove any nut until the tire has been raised off the ground.
Page 455 What to do in an emergency If you have a flat tire (with spare tire) the wheel slightly and get the top Make sure the wheel makes good hole in the wheel lined up with the contact with the hub when top stud.
Page 456 CAUTION OON068015NR Reusing lug nuts 18.After changing wheels, have an authorized Kia dealer tighten the Make certain during wheel removal wheel nuts to their proper torque that the same nuts that were as soon as possible.
Page 457: Important - Use Of Compact Spare Tire
What to do in an emergency If you have a flat tire (with spare tire) WARNING WARNING Wheel studs Spare tire If the studs are damaged, they may The compact spare tire is for emer- lose their ability to retain the wheel. gency use only.
Page 458 What to do in an emergency If you have a flat tire (with spare tire) Do not exceed the vehicle's maxi- The compact spare tire should not mum load rating or the load-car- be used on any other wheels, nor rying capacity shown on the should standard tires, snow tires, sidewall of the compact spare...
Page 459: Jack Label
What to do in an emergency If you have a flat tire (with spare tire) Jack label Type A OSK3068043NR Type B OSK3068044NR Type C OSK3068045NR * The actual jack label in the vehicle may differ from the illustration. For more detailed specifications, refer to the label attached to the jack.
Page 460 If the EPB does not release normal- ly, take your vehicle to an author- mended. ized Kia dealer by loading the vehi- On Front Wheel Drive (FWD) vehi- cle on a flatbed tow truck and have cles, it is acceptable to tow the vehi- the system checked.
Page 461 What to do in an emergency Towing Towing without wheel dollies when CAUTION using a towing service Towing When towing your vehicle in an emergency without wheel dollies: 1. Set the ENGINE START/STOP but- ton to ACC position. 2. Place the transmission shift lever in N (Neutral).
Page 463: Maintenance
Maintenance Maintenance Engine compartment ............... 7-4 Maintenance services............... 7-5 Owner maintenance ..............7-7 Scheduled maintenance service ..........7-9 Explanation of scheduled maintenance items....7-13 Engine oil and filter ..............7-17 Checking the engine oil level..........7-17 Changing the engine oil and filter........7-18 Engine coolant .................
Page 464: Maintenance
Maintenance Checking tire inflation pressure .........7-33 Tire rotation ................7-34 Wheel alignment and tire balance ........7-35 Tire replacement ..............7-35 Wheel replacement ..............7-36 Tire traction................7-36 Tire maintenance..............7-36 Tire sidewall labeling ............7-37 Tire terminology and definitions ........7-40 All season tires..............7-42 Summer tires ................7-43 Snow tires ................7-43 Tire chains................7-43 Radial-ply tires..............7-44...
Page 465 Maintenance Replacing turn signal lamp (bulb Type) bulb....7-64 Replacing Stop and tail lamp bulb (Rear combination lamp Type A) ................. 7-65 Replacing Stop and tail lamp bulb (Rear combination lamp Type B) ................. 7-65 Replacing Back lamp bulb (Rear combination lamp Type A/B) ................
Page 466: Engine Compartment
Maintenance Engine compartment MAINTENANCE Engine compartment Open the hood to see the engine compartment. Gasoline Engine (Lambda Ⅱ 3.8L - GDI) OON078001NR * The actual engine cover in the vehicle may differ from the illustration. 1. Engine coolant reservoir 2. Engine oil filler cap 3.
Page 467: Maintenance Services
An authorized Kia dealer has fac- We recommend you have your vehi- tory-trained technicians and genu- cle maintained and repaired by an ine Kia parts to service your vehicle authorized Kia dealer. Authorized properly. For expert advice and Kia dealers meet Kia's high service...
Page 468 As explained earlier in this section, serious bodily injury. Turn the vehi- several procedures can be done only cle off and wait until the metal parts by an authorized Kia dealer with cool down to perform maintenance special tools. work on the vehicle.
Page 469: Owner Maintenance
Be careful when checking your be performed by the owner or an engine coolant level when the authorized Kia dealer. They should engine is hot. Scalding hot coolant be performed at the indicated fre- and steam may blow out under quencies to help ensure the safe pressure.
Page 470 Maintenance Owner maintenance At least monthly: Inspect and lubricate automatic transmission linkage and controls. Check the coolant level in the Clean the battery and terminals. coolant reservoir. Check the brake fluid level. Check the operation of all exterior Visually inspect steering, suspen- lights, including the stoplights, sion, and chassis components for turn signals and hazard warning...
Page 471: Scheduled Maintenance Service
Maintenance Scheduled maintenance service Scheduled maintenance service If your vehicle is operated in any of the prior listed conditions, you Follow the Normal Maintenance should inspect, replace or refill more Schedule if the vehicle is usually frequently, using the severe usage operated where none of the follow- maintenance schedule instead of ing conditions apply.
Page 472 Maintenance Scheduled maintenance service Normal maintenance schedule - Non Turbo Models The following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services to protect your warranty. Where both mileage and time are shown, the frequency of service is determined by whichever occurs first.
Page 473 *1. The drive belt should be replaced when cracks occur or tension is reduced. *2. If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.
Page 474 Maintenance Scheduled maintenance service Maintenance Under Severe Usage Conditions - Non Turbo Models The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropri- ate maintenance intervals. R: Replace I: Inspect and if necessary, adjust, correct, clean or replace Maintenance...
Page 475: Explanation Of Scheduled Maintenance Items
Drive belts should be checked peri- odically for proper tension and adjusted as necessary. Fuel filter Kia gasoline vehicle is equipped with a lifetime fuel filter that is inte- grated with the fuel tank. Regular maintenance or replacement is gen- erally not needed.
Page 476 Air cleaner filter age. Have an authorized Kia dealer replace any damaged or leaking A Genuine Kia air cleaner filter is parts immediately. recommended when the filter is replaced. Vapor hose and fuel filler cap...
Page 477 Kia dealer in accordance which will prevent brake hose and to the scheduled maintenance at brake line failures due to corrosion the beginning of this section.
Page 478: Brake Fluid Reservoir
Maintenance Explanation of scheduled maintenance items Brake fluid Steering gear box, linkage & boots/ lower arm ball joint Check the brake fluid level in the With the vehicle stopped and off, brake fluid reservoir. The level check for excessive free-play in the should be between "MIN"...
Page 479: Checking The Engine Oil Level
Maintenance Engine oil and filter Engine oil and filter cloth. When mixed with debris, it can cause engine damage. The engine oil and filter should be The brake fluid constantly changed at the intervals specified in absorbs moisture from the air. the maintenance schedule.
Page 480: Changing The Engine Oil And Filter
Changing the engine oil and filter the beginning of the winter season, Have engine oil and filter changed by and before traveling to a colder cli- an authorized Kia dealer according mate. to the Maintenance Schedule at the WARNING beginning of this chapter.
Page 481: Checking The Coolant Level
Maintenance Engine coolant The cooling circuit of a vehicle Engine room rear view equipped with a heat pump sys- tem may freeze in extremely low temperature when the concen- tration of the antifreezing liquid is below 45%. For mixture percentage, refer to the following table.
Page 482: Changing The Coolant
8. If the coolant level is low, add enough specified coolant to pro- vide protection against freezing and corrosion. Bring the level to F, but do not overfill. If frequent additions are required, see an authorized Kia dealer for a cooling system inspection.
Page 483: Brake Fluid
Kia dealer. operate smoothly. Use only the specified brake fluid. Checking the brake fluid level (Refer to "Recommended lubricants...
Page 484: Washer Fluid
Maintenance Washer fluid Washer fluid WARNING Washer fluid is used when wiping Flammable Fluid the windshield of the vehicle with a Do not allow the washer fluid to windshield wiper. You should check come in contact with open flames or and refill washer fluid periodically to sparks.
Page 485: Parking Brake
Maintenance Parking brake Parking brake Air cleaner filter Inspect the parking brake system A Genuine Kia air cleaner filter is including the parking brake lever (or recommended when the filter is pedal) and cables. replaced. 1. Check whether the stroke is...
Page 486 When removing the air cleaner fil- ter, be careful that dust or dirt does not enter the air intake, or damage may result. Use a Kia genuine part. Use of a non-genuine part could damage OON078011NR the air flow sensor.
Page 487: Climate Control Air Filter
Maintenance Climate control air filter Climate control air filter The climate control air filter should be replaced according to the main- tenance schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced ear- lier.
Page 488: Wiper Blades
Maintenance Wiper blades 5. Reassemble in the reverse order Wiper blades of disassembly. When the wipers no longer clean When replacing the climate control adequately, the blades may be worn air filter install it properly. Other- or cracked, and require replacement. wise, the system may produce noise To prevent damage to the wiper and the effectiveness of the filter...
Page 489: Front Windshield Wiper Blade
Maintenance Wiper blades are not wiping properly, clean both Replacing front windshield wiper blade the window and the blades with a good cleaner or mild detergent, and Type A rinse thoroughly with clean water. 1. Raise the wiper arm and turn the wiper blade assembly to expose the plastic locking clip.
Page 490: Replacing Rear Window Wiper Blade
Maintenance Wiper blades 3. Lift it off the arm. 3. Install the new blade assembly. ODEEV098015NR ODEEV098017NR 4. Install the blade assembly in the 4. Return the wiper arm on the reverse order of removal. windshield. 5. Turn ignition to the ON position Type B and wiper arms will return to the 1.
Page 491: Battery
To prevent damage to the wiper OON078017NR Keep the battery securely arms or other components, have an mounted. authorized Kia dealer replace the Keep the battery top clean and wiper blade. dry. Keep the terminals and connec- tions clean, tight, and coated with petroleum jelly or terminal grease.
Page 492 Do not dispose of it after bustible gas which will use. Please return the bat- explode if it comes in contact with a tery to an authorized Kia dealer to flame or spark. be recycled. Keep batteries out of the...
Page 493 AGM battery serviced by The battery must be removed a professional workshop. Kia rec- from the vehicle and placed in an ommends to visit an authorized area with good ventilation.
Page 494: Tires And Wheels
Maintenance Tires and wheels mends to visit an authorized Kia Tires and wheels dealer. For proper maintenance, safety, and Do not open or remove the cap on maximum fuel economy, you must top of the battery. This may always maintain the recommended...
Page 495: Checking Tire Inflation Pressure
Maintenance Tires and wheels Tire pressure Always observe the following: Check tire pressure when the tires are cold. (After vehicle has been parked for at least three hours or hasn't been driven more than 1 mile (1.6 km) since startup.) Check the pressure of your spare tire each time you check the pres- sure of other tires.
Page 496: Tire Rotation
Maintenance Tires and wheels tires are properly inflated simply by leading to accidents, injuries, and looking at them. Radial tires may even death. The recommended cold look properly inflated even when tire pressure for your vehicle can be they're underinflated. found in this manual and on the tire label located on the driver's side Check the tire's inflation pressure...
Page 497: Wheel Alignment And Tire Balance
Maintenance Tires and wheels CAUTION Wheel weight Improper wheel weights can dam- age your vehicle's aluminum wheels. Use only approved wheel weights. ODEEV098029NR Rotate radial tires that have an asymmetric tread pattern only from Tire replacement front to rear and not from right to If the tire is worn evenly, a tread left.
Page 498: Wheel Replacement
Control (ESC) to work irregularly. Wheels It is best to replace all four tires at Wheels that do not meet Kia specifi- the same time. If that is not possi- cations may fit poorly and result in ble, or necessary, then replace the damage to the vehicle or unusual two front or two rear tires as a pair.
Page 499: Tire Sidewall Labeling
Maintenance Tires and wheels Tire sidewall labeling nator could vary depending on your vehicle.) This information identifies and describes the fundamental charac- P235/65R17 108T teristics of the tire and also provides P: Applicable vehicle type (tires the Tire Identification Number (TIN) marked with the prefix "P"...
Page 500 Maintenance Tires and wheels tires. The speed rating is part of the DOT XXXX XXXX 1618 represents tire size designation on the sidewall that the tire was produced in the of the tire. This symbol corresponds 16th week of 2018. to that tire's designed maximum safe operating speed.
Page 501 Maintenance Tires and wheels 6. Maximum load rating on the government course as a tire graded 100. This number indicates the maximum The relative performance of tires load in kilograms and pounds that depends upon the actual conditions can be carried by the tire. When of their use.
Page 502: Tire Terminology And Definitions
Maintenance Tires and wheels Sustained high temperature can Bead The tire bead contains steel cause the material of the tire to wires wrapped by steel cords that degenerate and reduce tire life, and hold the tire onto the rim. excessive temperature can lead to Bias Ply Tire A pneumatic tire in sudden tire failure.
Page 503 Maintenance Tires and wheels Intended Outboard Sidewall The side designed to seat multiplied by 150 of an asymmetrical tire that must lbs. (68 kg). always face outward when mounted Occupant Distribution Designated on a vehicle. seating positions. Kilopascal (kPa) The metric unit for Outward Facing Sidewall The side of air pressure.
Page 504: All Season Tires
Tread The portion of a tire that All season tires comes into contact with the road. Kia specifies all season tires on some models to provide good per- Treadwear Indicators Narrow bands, formance for use all year round, sometimes called "wear bars,"...
Page 505: Summer Tires
Maintenance Tires and wheels Summer tires WARNING Kia specifies summer tires on some Do not use summer tires at tem- models to provide superior perfor- peratures below 45 F (7 C) or mance on dry roads. when driving on snow or ice. At...
Page 506: Radial-Ply Tires
Maintenance Tires and wheels chain to avoid contact with the Longer wearing tires can be more vehicle body. susceptible to irregular tread wear. To prevent body damage, It is very important to follow the tire retighten the chains after driving rotation interval shown in this sec- 0.3~0.6 miles (0.5~1.0 km).
Page 507: Fuses
If the tire is impacted, we recom- damage by fuses. mend that you inspect the tire condition or contact an authorized Blade type Kia dealer. To prevent damage to the tire, inspect the tire condition and pressure every 1,900 miles (3,000 km).
Page 508 Kia dealer. A higher capacity fuse could cause damage and possibly a fire. CAUTION Never install a wire or aluminum...
Page 509: Replacing Inner Panel Fuse
Electrical wiring repairs OON078018NR All electrical repairs should be per- 3. Pull the suspected fuse straight formed by authorized Kia dealer- out. Use the removal tool pro- ships using approved Kia parts. vided on the engine fuse panel Using other wiring components, cover.
Page 510: Replacing Engine Compartment Fuse
NOTICE If the headlamp, fog lamp, turn sig- nal lamp, or tail lamp malfunction even without any problem to the lamps, have the vehicle checked by an authorized Kia dealer for assis- tance. Replacing engine compartment OON078064NR fuse 4. Check the removed fuse; replace it if it is blown.
Page 511 Listen for the audible click- a fire. Have the vehicle checked by ing sound to ensure fuse panel cover an authorized Kia dealer. is securely fastened. Main fuse Multi fuse OON078022NR...
Page 512: Fuse/Relay Panel Description
CAUTION a fire. Have the vehicle checked by Visually inspect the battery cap to an authorized Kia dealer. ensure it is securely closed. If the battery cap is not securely closed, Battery fuse moisture may enter the system and damage the electrical components.
Page 513 Maintenance Fuses Driver's side fuse panel NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label on the inside of the fuse cover.
Page 514 Maintenance Fuses Refer to the following table for a description of the fuse. Description Fuse rating Protected component ATM (Auto Transmission) Shift Lever Switch, Stop Lamp MODULE 4 7.5 A Switch, Driver Door Module SRS (Supplemental Restraint System) Control Module, Pas- AIR BAG 1 15 A senger Occupant Detection Sensor...
Page 515 Maintenance Fuses Description Fuse rating Protected component MDPS 10 A MDPS (Motor Driven Power Steering) Unit E/R Junction Block (Blower FRT Relay, Blower RR Relay, PTC 7.5 A Heater 1/2 Relay), Front A/C Control Module, Rear A/C Con- trol Module ICM (Integrated Circuit Module) Relay Box (Child Lock/Unlock CHILD LOCK 15 A...
Page 516 Maintenance Fuses Engine compartment fuse panel OON078027NR OON078028NR...
Page 517 Maintenance Fuses Refer to the following table for a description of the fuse. Fuse Name Fuse rating Circuit Protected MDPS 80 A MDPS (Motor Driven Power Steering) Unit COOLING FAN 80 A Cooling Fan Controller 60 A ESC (Electronic Stability Control) Module ICU Junction Block (IPS 8/IPS 10/IPS 11/IPS 12/IPS 13/IPS 50 A 14/IPS 15)
Page 518 Maintenance Fuses Fuse Name Fuse rating Circuit Protected BLOWER FRT 2 10 A Front A/C Control Module WIPER FRT 1 30 A Wiper FRT Relay B/ALARM HORN 15 A B/Alarm Horn Relay FUEL PUMP 20 A Fuel Pump Relay ACC 1 40 A ACC 1 Relay ACC 2...
Page 519 Maintenance Fuses Refer to the following table for the relay type. Relay Name Type Blower FRT Relay MINI Rear Heated Relay MINI Start Relay MICRO PTC Heater 1 Relay MICRO PTC Heater 2 Relay MICRO H/LAMP HI Relay MICRO Blower RR Relay MICRO Wiper Lo Relay MICRO...
Page 520 Maintenance Fuses Battery terminal cover OON078031NR NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
Page 521: Light Bulbs
Maintenance Light bulbs Light bulbs rating. Otherwise, it may cause damage to the fuse or electric wir- Light bulbs are installed in various ing system. parts of the vehicle to provide light- Fully install light bulbs and any parts ing inside and outside the vehicle as used to secure them.
Page 522 Kia dealer after an accident or after Do not install extra lamps or LEDs to the headlight assembly is rein- the vehicle. If additional lights are stalled.
Page 523 Maintenance Light bulbs Light bulb position (Rear) Headlamp Type B Rear combination lamp - Type A OON078035NR Fog lamp OON078040NR Rear combination lamp - Type B OON078037NR 1. Headlamp (Bulb Type) (Low/High) OON078042NR 2. Position lamp / Daytime running Rear turn signal lamp lamp (LED Type) 3.
Page 524: Headlamp Bulb
Maintenance Light bulbs High Mounted Stop Lamp (HMSL) Light bulb position (Side) OON078047NR OON078050NR License plate lamp 1. Side repeater lamp (LED type) Headlamp bulb OON078049NR 1. Tail lamp (Bulb Type) 2. Stop lamp (Bulb Type) OSK3078081NR 3. Back up lamp (Bulb Type) 4.
Page 525: Replacing Headlamp (Low/High) / Position Lamp / Daytime Running Lamp / Turn Signal Lamp (Led Type) Bulb (Headlamp Type B)
5. Connect the bulb socket-connec- authorized Kia dealer. tor. Replacing Position lamp + DRL (LED type) bulb (Headlamp Type A) If the position lamp + DRL (LED) (1) does not operate, have the vehicle checked by an authorized Kia dealer. OON078051NR OON078065NR...
Page 526: Replacing Front Fog Lamp Bulb
Replacing side repeater lamp (LED Type) bulb If the side repeater lamp (LED), does not operate, have the vehicle checked by an authorized Kia dealer. OON078057NR If the rear turn signal lamp (Bulb Type) does not operate, have the vehicle checked by an authorized Kia...
Page 527: Replacing Stop And Tail Lamp Bulb (Rear Combination Lamp Type A)
If the Stop and tail lamp (LED Type) 2. Loosen the lamp assembly retain- does not operate, have your vehicle ing screws with a screwdriver. checked by an authorized Kia dealer. 3. Remove the rear combination lamp assembly from the body of Replacing Back lamp bulb (Rear the vehicle.
Page 528: Replacing High Mounted Stop Lamp (Led Type) Bulb
2. Remove the bulb by pulling it (LED) (1), does not operate, have straight out. the vehicle checked by an autho- 3. Install a new bulb in the socket. rized Kia dealer. 4. Install the lamp assembly to inte- rior. Replacing map lamp (bulb type) bulb...
Page 529: Replacing Map Lamp (Led Type) Bulb
If the map lamp (LED type) does not operate, have your vehicle checked by an authorized Kia dealer. The LED lamps cannot be replaced as a single unit because it is an inte- grated unit. The LED lamps has to OON078058NR be replaced with the unit.
Page 530: Replacing Room Lamp (Bulb Type) Bulb
Replacing room lamp (LED type) bulb If the Room lamp (LED) does not operate, have the vehicle checked by an authorized Kia dealer. OON078060NR If the personal lamp (LED) does not operate, have the vehicle checked by an authorized Kia dealer.
Page 531: Replacing Glove Box Lamp
4. Install the lamp assembly to inte- rior. CAUTION Be careful not to dirty or damage the lens, lens tab, and plastic hous- OON078067NR ings. If the luggage lamp (LED) (1) does not operate, have the vehicle checked by an authorized Kia dealer.
Page 532: Appearance Care
Maintenance Appearance care The LED lamps cannot be replaced Appearance care as a single component because they Use the information in the following are part of an integrated unit. The sections to keep the exterior and LED lamps have to be replaced with interior of your vehicle clean.
Page 533 Maintenance Appearance care Insects, tar, tree sap, bird droppings, High-pressure washing industrial pollution and similar When using high-pressure washers, deposits can damage your vehicle's make sure to maintain sufficient finish if not removed immediately. distance from the vehicle. Even prompt washing with plain Insufficient clearance or excessive water may not completely remove pressure can lead to component...
Page 534 Maintenance Appearance care Removing oil, tar, and similar mate- CAUTION rials with a spot remover will usually Wetting engine compartment strip the wax from the finish. Be sure to re-wax these areas even if the rest of the vehicle does not yet need waxing.
Page 535 Maintenance Appearance care The National Highway Traffic Safety NOTICE Administration has warned all vehi- If your vehicle is damaged and cle owners of all brands of the need requires any metal repair or to take the following steps: replacement, be sure the body shop Wash the undercarriage of your applies anti-corrosion materials to vehicle regularly during the winter...
Page 536 Maintenance Appearance care Use only a mild soap or neutral which leave unprotected metal detergent, and rinse thoroughly exposed to corrosion. with water. Also, be sure to clean High-corrosion areas the wheels after driving on salted roads. This helps prevent corro- If you live in an area where your sion.
Page 537 Maintenance Appearance care To help prevent corrosion and not be trapped inside to accel- erate corrosion. You can help prevent corrosion from beginning by observing the follow- ing: Keep your garage dry Don't park your vehicle in a damp, Keep your vehicle clean poorly ventilated garage.
Page 538: Interior Care
Maintenance Appearance care fertilizers, cleaning materials or CAUTION chemicals in the vehicle. Leather These should be carried only in When cleaning leather products proper containers and any spills or (steering wheel, seats etc.), use leaks should be cleaned up, flushed neutral detergents or low alcohol with clean water and thoroughly content solutions.
Page 539 Maintenance Appearance care Cleaning the leather seats and moderate pressure using a soft sponge or microfiber cloth. Remove all contaminations instantly. Refer to instructions Velcro closures on clothing or sharp below for removal of each contami- objects may cause snagging or nant.
Page 540: Emission Control System
Do not scrape or scratch the inside maintained by an authorized Kia of the rear window. This may result dealer in accordance with the main- in damage of the rear window tenance schedule in this manual.
Page 541 Maintenance Emission control system 1. Crankcase emission control sys- Purge Control Solenoid Valve (PCSV) The Purge Control Solenoid Valve (PCSV) is controlled by the Engine The Positive Crankcase Ventilation Control Module (ECM); when the system is employed to prevent air engine coolant temperature is low pollution caused by blow-by gases during idling, the PCSV closes so...
Page 542 Maintenance Emission control system Engine exhaust gas precautions When the engine stalls or fails to (carbon monoxide) start, excessive attempts to restart the engine may cause Carbon monoxide can be present damage to the emission control with other exhaust fumes. There- system.
Page 543: California Perchlorate Notice
Do not modify or tamper with any part of the engine or emission control system. All inspections and adjustments must be made by an authorized Kia dealer. Avoid driving with an extremely low fuel level. Running out of fuel could cause the engine to misfire, damaging the catalytic converter.
Page 545 Specifications, Consumer information and Reporting safety defects Specifications, Consumer information and Reporting safety defects Dimensions................. 8-2 Engine ..................8-2 Gross Vehicle Weight..............8-2 Luggage volume................ 8-3 Air conditioning system............8-3 Bulb wattage ................8-4 Tires and wheels ............... 8-5 Recommended lubricants and capacities ......8-6 Recommended SAE viscosity number ........
Page 546: Specifications, Consumer Information And Reporting Safety Defects Abbreviation
Specifications, Consumer information and Dimensions Reporting safety defects SPECIFICATIONS, CONSUMER INFORMATION AND REPORTING SAFETY DEFECTS Dimensions Item 7 Seater 8 Seater Overall length 196. 8 in (5,000 mm) ← Overall width 78.3 in (1,990 mm) ← Without Roof rack 68.9 in (1,750 mm) ←...
Page 547: Luggage Volume
Min: Behind 3rd row. Max: Behind front seat to roof. Air conditioning system oz (g) ITEM Weight of volume Classification Refrigerant 33.5 0.9 (950 25) R-1234yf Compressor lubricant 7.4 0.35 (210 10) FD46XG (IDEMITUS) Contact an authorized Kia dealer for more details.
Page 548: Bulb Wattage
Specifications, Consumer information and Bulb wattage Reporting safety defects Bulb wattage Light Bulb Bulb Type Wattage (W) Bulb type High Headlamp LED type High 27/8W Bulb type 1157NA Turn signal lamp Front LED type Day time running lamp/Position lamp Bulb type Side marker LED type Fog lamp*...
Page 549: Tires And Wheels
Specifications, Consumer information and Tires and wheels Reporting safety defects Tires and wheels Inflation pressure [psi (kPa)] Wheel lug nut Load Speed Tire torque Capacity capacity Maximum load Normal load Item Supplier size lbf ft (kgf m, size kg SS km/h Front Rear Front Rear N m) Michelin...
Page 550: Recommended Lubricants And Capacities
Specifications, Consumer information and Recommended lubricants and capacities Reporting safety defects Recommended lubricants and capacities To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy.
Page 551: Recommended Sae Viscosity Number
Specifications, Consumer information and Recommended lubricants and capacities Reporting safety defects Recommended SAE viscosity num- Engine oil viscosity (thickness) has an effect on fuel economy and cold weather operating (engine start and CAUTION engine oil flowability). Lower viscos- ity engine oils can provide better Always be sure to clean the area fuel economy and cold weather per- around any filler plug, drain plug, or...
Page 552: Vehicle Identification Number (Vin)
Specifications, Consumer information and Vehicle Identification Number (VIN) Reporting safety defects Vehicle Identification Number Vehicle certification (VIN) The vehicle certification label attached on the driver's (or front The Vehicle Identification Number passenger's) side center pillar gives (VIN) is the number used in register- the Vehicle Identification Number ing your vehicle and in all legal mat- ters pertaining to its ownership, etc.
Page 553: Tire Specification And Pressure Label
Specifications, Consumer information and Tire specification and pressure label Reporting safety defects Tire specification and pressure Engine Number label The engine number is stamped on the engine block as shown in the The tires supplied on your new vehi- drawing. cle are chosen to provide the best performance for normal driving.
Page 554: Refrigerant Label
The refrigerant label is located on Roadside Assistance is provided on the underside of the hood. all new current model year Kia Vehi- cles from the date the vehicle is delivered to the first retail buyer or otherwise put into use (inservice...
Page 555 Vehicle Identification Number Roadside Assistance benefits are (VIN) to verify coverage at the time not available for any Kia vehicle that of your call. The VIN can be found on has ever been or should be issued a the dash of your vehicle on the "salvage"...
Page 556 3. There may not be an Authorized If you plan to register your vehicle in Kia Dealer in the area in which you a foreign country, you should con- plan to register your vehicle. You firm that it conforms to the regula- may additionally experience diffi- tions in that country.
Page 557: Electrical Equipment (U.s. Only)
The electrical system of your vehicle the proper equipment and installa- is designed to perform under all tion. reasonably expected operating con- Kia motor vehicles are designed and ditions. manufactured to meet or exceed all However, before any additional elec- applicable safety standards.
Page 558: Reporting Safety Defects (U.s. Only)
National Highway Traffic Safety This manual covers maintenance Administration (NHTSA) in addition and recommended procedures for to notifying Kia Motors America, Inc. repair to engine and chassis compo- If NHTSA receives similar com- nents. It is written for the Journey-...
Page 559 Abbreviation Abbreviation...
Page 560 Abbreviation ABBREVIATION Electronic Parking Brake Air conditioning Electronic Power Steering Anti-lock Brake System Electronic Stability Control Auto Defogging System Forward Collision-Avoidance Assist Absorbent Glass Mat Federal Communications Commis- All Wheel Drive sion FMVSS Blind-Spot Collision-Avoidance Federal Motor Vehicle Safety Assist Standards Blind-Spot Collision Warning Front Wheel Drive...
Page 561 Abbreviation RCCW Head-Up Display Rear Cross-Traffic Collision Warn- Idle Stop and Go Rear Occupant Alert LATCH Lower Anchors and Tether for CHildren Smart Cruise Control Lane Departure Warning Safe Exit Assist LDWS Lane Departure Warning System Supplemental Restraint System SRSCM Lane Following Assist SRS Control Module Lane Keeping Assist...
Page 563: Index I
Index Index...
Page 564 INDEX good driving practices 5-17 ignition key interlock system 5-17 moving up a steep grade from a standing start 5-18 overriding the shift lock 5-16 adjusting steering wheel angle shift lock system 5-16 and height 4-53 transmission ranges 5-14 air bags 3-53 automatic ventilation 4-155...
Page 565 power brakes 5-26 displays, see instrument releasing the EPB with EPB cluster 4-64 switch 5-29 door locks 4-15 trailer stability assist (TSA) 5-43 central door lock switch 4-18 vehicle stability management from inside the vehicle 4-16 (VSM) 5-41 from outside the vehicle 4-15 bulb replacement precaution 7-59...
Page 566 push-starting front radar/camera sensor 5-62 emergency while driving limitations 5-65 malfunction 5-64 engine stalls at a crossroad or prerequisite for activation 5-59 crossing setting and activation 5-58 flat tire while driving setting initial warning activation vehicle stalls while driving time 5-58 emission control system 7-78...
Page 567 programming rolling code 4-58 hood 4-40 closing the hood 4-41 lane following assist (LFA) 5-90 hood open warning 4-41 activating/deactivating 5-91 opening the hood 4-40 cautions for driver 5-94 horn 4-54 limitations 5-93 lane keeping assist (LKA) 5-100 activating/deactivating 5-102 driver s attention 5-106 idle stop and go (ISG)
Page 568 light bulbs bulb replacement precaution 7-59 lighting occupant detection system 4-110 auto light 4-111 (ODS) 3-59 battery saver function 4-110 odometer 4-67 daytime running light 4-110 online factory authorized headlight position 4-111 manuals 8-14 high beam assist (HBA) 4-114 operating high beam 4-112 operating front fog light 4-114...
Page 569 rear occupant alert (ROA) vapor hose and fuel filler cap 7-14 scheduled maintenance system 4-21 service rear view monitor 4-106 maintenance under severe usage record your key number conditions 7-12 reducing the risk of a rollover 5-135 normal maintenance schedule 7-10 replacing smart key battery 4-11...
Page 570 smooth cornering supplemental restraint system 5-137 snow tires (SRS) 5-139 3-75 snowy or icy conditions surround view monitoring 5-139 special driving conditions (SVM) 5-135 4-107 driving at night 5-137 driving in flooded areas 5-138 driving in the rain 5-137 tachometer 5-138 driving on unpaved roads 4-65...
Page 571 safety chains 5-144 window opening and closing 4-38 trailer brakes 5-144 windshield defrosting and transmission shift indicator 4-68 defogging 4-151 automatic transmission shift auto defogging system 4-154 Indicator 4-68 defogging logic 4-153 trip computer mode 4-70 windshield washers 4-117 trip information winter driving 5-139 (trip computer)
Page 579 2019 KIA MOTORS AMERICA. INC.

Kia 2020 Telluride Owner's Manual

Table of Contents

Your Vehicle at a Glance 2

Safety Features of Your Vehicle 3

Features of Your Vehicle 4

Driving Your Vehicle 5

Quick Links

Chapters

Related Manuals for Kia 2020 Telluride

Summary of Contents for Kia 2020 Telluride
