- Page 1 AX6W-15J19 User Manual AX6W-15J19 User Manual...
- Page 2 About the Product AX6W-15J19 a multifunctional touch POS terminal with optional POS peripherals like MSR, customer display and the second screen. To meet the specialized needs of different users, it is the ideal choice for retail and catering entertainment industry, etc.
- Page 3 AX6W-15J19 User Manual Outward Diagram Front view DESCRIPTION TFT LCD and Touch Screen Magnet Stripe Reader(Optional) Rear view DESCRIPTION Customer Display Cover Power Switch Base HDD Cover...
- Page 4 AX6W-15J19 User Manual IOPort 1 DESCRIPTION COM3Port COM3 12V Power USB(Optional) PS2 KB Cash Drawer Port +12V Output Jack 12VOUT AC Adapter Jack COM4Port COM4 3G Antenna VGA Port COM1 COM1 Port LAN Port USB Ports USB Ports...
- Page 5 AX6W-15J19 User Manual IOPort 2 DESCRIPTION COM3 Port COM3 12V Power USB(Optional) Cash Drawer Port 12VOUT +12V Output Jack AC Adapter Jack COM1 COM1 Port 3G Antenna Line-out/Microphone OTG Jack HDMI HDMI Jack LAN Port USB Ports Note: IO port 1 for X86 models, IO port 2 for Android models.
- Page 6 AX6W-15J19 User Manual HDD Dismantlement 1. Dismantle the HDD cover, and find the HDD bracket. 2. Remove the screws M3*4 which is to fix the bracket 3. Pull out the HDD bracket.
-
Page 7: Msr Installation
AX6W-15J19 User Manual Customer Display Installation 1. Connect the data cable of customer display to the seat of 4 Pins on the pinboard. 2. Connect the customer display on the rear cover with 4pcs M4*11.5 screws. MSR Installation 1. Connect the data cable of MSR to the seat of pinboard. - Page 8 1. Double-click the icon, open the program, the system will automatically scan the card reader connected to the motherboard interface. The two interfaces of AX6W-15J19 are connected with USB port by default when the machines are produced. As shown in the figure: Green words represent connected, red words represent not connected.
-
Page 9: Troubleshooting
AX6W-15J19 User Manual Troubleshooting A few common hardware problems and suggested solutions are presented in the table below: PROBLEM SOLUTION Make sure that the Power LED is on and The display is dark. machine is not in sleeping mode. The following message...
