- Page 1 QUICK START GUIDE POOL & SPA CONTROL Designed, Engineered & 2200 E. Sturgis Road, Oxnard, CA 93030 • Phone 805.981.0262 • Fax 805.981.9403 Manufactured waterway@waterwayplastics.com • www.waterwayplastics.com in the USA. 810-0484.0319 ©2019 Waterway Plastics...
- Page 2 • Each successive relay from the left is: - Filter Pump If using Filter Pump other than Waterway, High Voltage must be wired directly from Breaker. Pump will be controlled with Low Voltage communication cable. - Aux 1 (Water Feature, etc...) - Aux 2 (Spa pump, etc…)
- Page 3 (Type of LIGHT that can be chosen; On/Off, IntelliBrite, Jandy Color, Jandy LED, Color Logic). - Other devices can be assigned to: None, Pool, Spillover, or Spa mode. This will put the OASIS in that Mode when the device is turned on.
- Page 4 Down arrows can be used to adjust this setting. • When adjustments are made, press HOME to return to the main screen. For more information on configuring/programming the OASIS, use the QR code below or visit www.youtube.com/watch?v=gInl5vTJCYQ&t Designed, Engineered &...
