- Page 1 ORKABOUT RFID Reader HF-AM2-G2 User Manual...
- Page 2 Psion Teklogix™ is a trademark of Psion Teklogix Inc. Other product names mentioned in this document may be trademarks of Psion Teklogix Inc. or trademarks or registered trademarks of other hardware, software, or service providers and are used herein for identification purposes only.
-
Page 3: Table Of Contents
Table of Content I. Important – read carefully..................... 4 II. Overview ........................4 II.1. Bill of Material ......................... 4 II.2. Interface Board installation ....................5 II.3. Reader Board Installation ....................6 II.3.1. HF-AM2-G2 Endcap .......................6 II.3.2. SAGEM endcap dual reader with slot..................6 III. -
Page 4: Important - Read Carefully
I. Important – read carefully All Approval and safety information is outlined in the ‘Workabout pro G2 Handheld-computer User Manual’ – part number 8100140A. This manual available website www.psionteklogix.com through the Teknet extranet II. Overview II.1. Bill of Material RFID Reader HF-AM2-G2 is composed of :... -
Page 5: Ii.2. Interface Board Installation
II.2. Interface Board installation The interface Board has to be installed in the Workabout Pro: Specific end Flex cable to reader board Interface Board Built-in scanner flex cable RFID Reader HF-AM2-G2 – User Manual TS-A00350-A00 Page 5/19... -
Page 6: Ii.3. Reader Board Installation
II.3. Reader Board Installation The reader board has to be installed in a specific endcap depending of the configuration: II.3.1. HF-AM2-G2 Endcap II.3.2. SAGEM endcap dual reader with slot RFID Reader HF-AM2-G2 – User Manual TS-A00350-A00 Page 6/19... -
Page 7: Hardware Installation
III. Hardware installation III.1. Preparing Before installing a module in the WORKABOUT PRO G2, all power sources must be turned off. Remove the batteries. If your unit is using Slide the switch to position OFF to shut off internal AC power, disconnect it. -
Page 8: Iii.2. Interface Board Installation
III.2. Interface Board installation Insert the bard as shown and screw the 4 Plug the flex cable as shown provided screws III.3. Reader Board installation The reader board intends to fit in a specific endcap which depends on the desired configuration. Each following paragraph describes how to assemble every configuration. - Page 9 Place the rubber inside the endcap… and press strongly Put silicon between the rubber and the reader in order to ensure a good holding board …. Stick the sticker on the top of the endcap RFID Reader HF-AM2-G2 – User Manual TS-A00350-A00 Page 9/19...
-
Page 10: Iii.3.2. Sagem Endcap Dual Reader With Slot Assembly
III.3.2. SAGEM endcap dual reader with slot assembly The following drawing shows the whole assembly Here are the required parts 1 MSO sensor 1 Top moulding 1 MSO plate 1 biometric endcap 1 8-ways MSO cable 4 self tapping screws 4 thorx screws 4 washers 1 smart card board... - Page 11 The first step is to build the fingerprint unit (top- subassembly) Here are the required parts 1 MSO sensor 1 Top moulding 1 MSO plate 1 8-ways MSO cable 4 self tapping screws 4 washers 2 gaskets Prepare the gasket and the MSO sensor Place the gasket on the sensor as shown Place the sensor in the top moulding Check the gasket positioning...
- Page 12 Connect the MSO cable to the MSO sensor Prepare the MSO plate and its gasket Put the gasket on the plate as shown Place the cover on the top moulding Screw the 4 self tappings screws with their Put silicon in the MSO cable window to ensure washer proper sealing RFID Reader HF-AM2-G2 –...
- Page 13 It is now time to perform final assembly: Insert the reader board in the rubber Insert the assembly in the endcap slot Stick the gasket around the smart card board Place the smart card board on the top of the connector endcap The smart card board and the reader board are...
-
Page 14: Iii.4. Endcap Connection
Close the endcap with the fingerprint unit and Finish the endcap sealing with a silicon screw the 4 thorx screws injection in the 8-way cable window. III.4. Endcap connection The endcap has to be connected to the interface board: III.4.1. HF-AM2-G2 Endcap Connect the flex cable from the interface board to Screw then endcap the reader board. -
Page 15: Iii.4.2. Sagem Endcap Dual Reader With Slot
III.4.2. SAGEM endcap dual reader with slot Connect the flex cable from the interface board to Screw then endcap the reader board. And the MSO cable in the dedicated connector III.5. Final steps Slide the switch located in the battery casing to Put back the batteries and close the position ON battery cover. -
Page 16: Reading Area
IV. Reading Area This area depend of the TAG type, TAG packaging, configuration of the WORKABOUT PRO (scanner, Compact flash…), environment (metallic or not). V. RFID Regulatory Information RFID Reader HF-AM2-G2 – User Manual TS-A00350-A00 Page 16/19... - Page 17 RFID Reader HF-AM2-G2 – User Manual TS-A00350-A00 Page 17/19...
- Page 18 RFID Reader HF-AM2-G2 – User Manual TS-A00350-A00 Page 18/19...
- Page 19 IMPORTANT NOTE FOR NORTH AMERICA: The RFID must not be used whilst the host WORKABOUT PRO is being powered by the ac/dc adaptor. FCC Information to Users: This product and it antennas must not be co-located or operated in conjunction with any other antenna or transmitter.
