MODELS: ED-48/P
COOK/HOLD/SERVE SYSTEMS BY
.
.
.
P R I N T E D I N U
S
A
HOT DISPLAY CASE
— SELF-SERVICE (PASS-THROUGH)
ED-72/P
ED-72/PL
W164 N9221 Water Street
Menomonee Falls, Wisconsin 53052-0450
: ( 2 6 2 ) 2 5 1 - 3 8 0 0
®
P H O N E
: ( 2 6 2 ) 2 5 1 - 7 0 6 7
F A X
OPERATION
CARE MANUAL
ED-72/PR
ED-96/PL
ED-96/PR
P.O. Box 450
•
( 8 0 0 ) 5 5 8 - 8 7 4 4
( 8 0 0 ) 3 2 9 - 8 7 4 4
www.alto-shaam.com
AND
U.S.A.
•
.
.
./
U
S
A
C A N A D A
.
.
./
U
S
A
C A N A D A
®
®
# 8 8 1 - 3
0 8 / 0 1
Advertisement
Related Manuals for Alto-Shaam ED-96/PR
Summary of Contents for Alto-Shaam ED-96/PR
- Page 1 ® OPERATION CARE MANUAL HOT DISPLAY CASE — SELF-SERVICE (PASS-THROUGH) MODELS: ED-48/P ED-72/PR ED-72/P ED-96/PL ED-96/PR ED-72/PL COOK/HOLD/SERVE SYSTEMS BY ® W164 N9221 Water Street P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 U.S.A. • : ( 2 6 2 ) 2 5 1 - 3 8 0 0 ( 8 0 0 ) 5 5 8 - 8 7 4 4 ®...
- Page 2 SELF-SERVICE HOT DISPLAY CASES ® 2. PLACE DIVIDERS and SERVING PANS IN CASE U N PA C K I N G Refer to the pan layout diagrams for different types of pan a n d S E T- U P accommodations.
- Page 3 C. Clean the interior metal surfaces of the cabinet with 4650 Watts, 21.1 Amps BARE END — NO PLUG a damp cloth and any good alkaline or alkaline ED-96/PL; ED-96/PR chlorinated based commercial detergent or grease solvent at the recommended strength. 120/208-240 V.A.C. — 60 Hz, 1 ph At 208V: 5100 Watts, 22.5 Amps...
- Page 4 S A N I TAT I O N G U I D E L I N E S G E N E R A L H O L D I N G G U I D E L I N E S Food flavor and aroma are usually so closely related that it Chefs, cooks and other specialized food service personnel is difficult, if not impossible, to separate them.
- Page 5 Operation and Care Manual #881-3 P g . 4...
- Page 6 Operation and Care Manual #881-3 P g . 5...
- Page 7 Operation and Care Manual #881-3 P g . 6...
- Page 8 I NSTALLATION I NSTR UCTIONS — OPTIONAL SCALE PLATFOR M Disconnect the unit from the power source. Lift hood glass up to access the outer top. Position the platform mounting bracket in the desired location along the upper rear edge on the outer top, making sure that the bracket is tight against the bend in the top.
-
Page 9: Safety Alert
ED-72/P, ED-72/PL, ED-72 /PR - ED-96/PL, ED-48/P ED-96/PR Cable Kit Cable Kit Cable Heating Service Kit 4881 Cable Heating Service Kit 4880 includes: includes: CB-3045 Cable Heating Element ....210 feet CB-3045 Cable Heating Element . - Page 10 ED-48/P PASS-THROUGH 0 4 / 2 7 / 0 1 Alto-Shaam Alto-Shaam Part Description Qty. Part No. Part Description Qty. Part No. 1. CORD, (120/240V), 7' (2134mm) CD-3291 20. CAPILLARY COVER PLATE 11160 CORD, (220V), 7’ (2134mm) CD-3545 CAPILLARY PLATE MOUNTING SCREWS SC-2459 CONNECTOR: 1/2"...
- Page 11 P g . 1 0 Operation and Care Manual #881-3...
- Page 12 P g . 1 1 Operation and Care Manual #881-3...
- Page 13 ED-72/P PASS-THROUGH Alto-Shaam Alto-Shaam Part Description Qty. Part No. Part Description Qty. Part No. 1. CORD, (120/240V), 7’ (2134mm) CD-3557 19. GLASS, FRONT GL-2962 CORD, (220V), 7’ (2134mm) CD-3607 20. LIGHT GUARD 4832 CONNECTOR: 3/4” CABLE (120-240V) CR-3293 CONNECTOR: 1/2” CABLE (220V) CR-33542 21.
- Page 14 Operation and Care Manual #881-3 P g . 1 3...
- Page 15 ED-72/PL PASS-THROUGH — LEFT SIDE 0 4 / 2 7 / 0 1 Alto-Shaam Alto-Shaam Part Description Qty. Part No. Part Description Qty. Part No. 1. CORD, (120/240V), 7’ (2134mm) CD-3557 22. CAPILLARY COVER PLATE 11160 CORD, (220V), 7’ (2134mm) CD-3607 CAPILLARY PLATE MTG.
- Page 16 P g . 1 5 Operation and Care Manual #881-3...
- Page 17 ED-72/PR PASS-THROUGH — RIGHT SIDE 0 4 / 2 7 / 0 1 Alto-Shaam Alto-Shaam Part Description Qty. Part No. Part Description Qty. Part No. 1. CORD, (120/240V), 7’ (2134mm) CD-3557 22. CAPILLARY COVER PLATE 11160 CORD, (220V), 7’ (2134mm) CD-3607 CAPILLARY PLATE MTG.
- Page 18 P g . 1 7 Operation and Care Manual #881-3...
- Page 19 P g . 1 8 Operation and Care Manual #881-3...
- Page 20 ED-96/PL PASS-THROUGH — LEFT SIDE 0 4 / 2 7 / 0 1 Alto-Shaam Alto-Shaam Part Description Qty. Part No. Part Description Qty. Part No. 1. CORD, (120/240V), 7’ (2134mm) CD-3557 24. CUTTING BOARD ASSEMBLY 4016 CORD, (220V), 7’ (2134mm) CD-3304 25.
- Page 21 P g . 2 0 Operation and Care Manual #881-3...
- Page 22 17. GLASS DOOR ASSEMBLY, INCLUDES DR-25038 — L.H. INNER DOOR DR-25041 — L.H. OUTER DOOR DR-25039 SERVICE VIEW • ED-96/PR — PAGE 22 — R.H. OUTER DOOR DR-25040 — R.H. INNER DOOR DR-25042 — OPTIONAL MIRRORED GLASS DOR ASB. DR-25043 —...
- Page 23 P g . 2 2 Operation and Care Manual #881-3...
- Page 24 P g . 2 3 Operation and Care Manual #881-3...
- Page 25 P g . 2 4 Operation and Care Manual #881-3...
- Page 26 P g . 2 5 Operation and Care Manual #881-3...
- Page 27 P g . 2 6 Operation and Care Manual #881-3...
- Page 28 Operation and Care Manual #881-3 P g . 2 7...
- Page 29 Operation and Care Manual #881-3 P g . 2 8...
- Page 30 P g . 2 9 Operation and Care Manual #881-3...
- Page 31 P g . 3 0 Operation and Care Manual #881-3...
- Page 32 P g . 3 1 Operation and Care Manual #881-3...
-
Page 33: Limited Warranty
T R A N S P O RTAT I O N ® D A M A G E a n d C L A I M S L I M I T E D WA R R A N T Y All Alto-Shaam equipment Alto-Shaam, Inc.
