iBurst Terminal, Desktop Model (UTD) / USB Model (UTU), Manual
iBurst Terminal, Desktop Model (UTD) / USB Model (UTU), Manual
iBurst Terminal, Desktop Model (UTD) / USB Model (UTU), Manual
iBurst Terminal, Desktop Model (UTD) / USB Model (UTU), Manual
Checked
Designed
Yamamoto
Hirao
Reference:
Revision:
Date:
- 1 -
Q38T-EE-001
June.08.2006
Revision 1.01 --- June.08.2006
1.01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iBurst UTD and is the answer not in the manual?

Questions and answers

Related Manuals for Kyocera iBurst UTD

Summary of Contents for Kyocera iBurst UTD

  • Page 1 Terminal, Desktop Model (UTD) / USB Model (UTU), Manual iBurst Terminal, Desktop Model (UTD) / USB Model (UTU), Manual Approved Checked Designed Koyama Yamamoto Hirao Reference: Q38T-EE-001 Revision: 1.01 Date: June.08.2006 Kyocera Corporation Revision 1.01 --- June.08.2006 - 1 -...
  • Page 2 Terminal, Desktop Model (UTD) / USB Model (UTU), Manual iBurst Terminal, Desktop Model (UTD) / USB Model (UTU), Manual Revision Record Revision Author Date Detail 1.00 Hirao May.10.2006 First Release 1.01 Miyasaka June.08.2006 Correct some writings Kyocera Corporation Revision 1.01 --- June.08.2006 - 2 -...

  • Page 3: Table Of Contents

    FCC Compliance Statement FCC Compliance Statement FCC Compliance Statement FCC RF Radiation Exposure Statement FCC RF Radiation Exposure Statement ..................121 FCC RF Radiation Exposure Statement FCC RF Radiation Exposure Statement Kyocera Corporation Revision 1.01 --- June.08.2006 - 3 -...

  • Page 4: Safety Precautions On Iburst Terminal

    Windows is a registered trademark of Microsoft Corporation. • In addition, the name of the software carried in this document and peripheral equipment is • each company’s trademark, or a registered trademark. Kyocera Corporation Revision 1.01 --- June.08.2006 - 4 -...
  • Page 5 Do not place things or put cloth on the top of the plug. It may heat and break the plastic • and/or the rubber, causing fire or electric shock. Kyocera Corporation Revision 1.01 --- June.08.2006 - 5 -...
  • Page 6 Do not use it in the intense place of vibration. It becomes the cause of failure. • Kyocera Corporation Revision 1.01 --- June.08.2006 - 6 -...
  • Page 7 Both a USB and an Ethernet interface cannot be used simultaneously in case a UTD • model. When using UTD model, Please put the antenna at vertical position as shown in the below • diagrams so that the unit could acquire proper antenna characteristics. Kyocera Corporation Revision 1.01 --- June.08.2006 - 7 -...

  • Page 8: Chapter 1 Introduction Chapter 1 Introduction

    This chapter describes what shoul describes what shoul d be confirmed d be confirmed before before using iBurst Terminal using iBurst Terminal..using iBurst using iBurst Terminal Terminal Kyocera Corporation Revision 1.01 --- June.08.2006 - 8 -...

  • Page 9: Components List

    Notes iBurst Terminal Unit of UTU model Refer to the pictures shown in next page. USB Cable Type: USB1.1 (Mini B for UTU side) Length: 1m Pictures of Accessories AC/DC Adapter Kyocera Corporation Revision 1.01 --- June.08.2006 - 9 -...

  • Page 10: Outlook Of Iburst Terminal

    Outlook of iBurst Terminal Outlook of iBurst Terminal UTD model Antenna Power switch Back side view Power Indicator Link/Communication Indicator USB port PC Connection Indicator 10Base-T port only on UTD model DC Power Input Kyocera Corporation Revision 1.01 --- June.08.2006 - 10 -...

  • Page 11: Indicators Indicators

    Yellow Weak signal receiving Blinking when communicating. Green Strong signal receiving Blinking when communicating. PC Connection Indicator Any port not active (Only on UTD model) Amber USB port Green 10Base-T port Kyocera Corporation Revision 1.01 --- June.08.2006 - 11 -...

  • Page 12: Requirements On Your Pc

    X. Please read through every sections related with the operating system for details. USB Connection Back side of UTD USB port USB Cable 10Base-T Ethernet Connection 10Base-T port Category 5 Cable (Straight cable) Kyocera Corporation Revision 1.01 --- June.08.2006 - 12 -...

  • Page 13: Chapter 2 Setup Procedure Chapter 2 Setup Procedure

    Kyocera Corporation Revision 1.01 --- June.08.2006 - 13 -...

  • Page 14: Iburst Software Installation

    3. Insert the Software Utility CD provided by the network operator into your CD-ROM drive; or execute the appropriate installation software. 4. iBurst Terminal Setup starts. Click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 14 -...
  • Page 15 6. Click the [Next >] button after appearing dialog window as shown below. To install to a different folder, click [Browse…] and specify another folder. NOTE: 7. Click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 15 -...
  • Page 16 The iBurst Terminal will be recognized and will be ready to use automatically. If the PC request to restart again, click [Yes] to restart the PC. NOTE: To connect to the Internet, refer to page 62. NOTE: Kyocera Corporation Revision 1.01 --- June.08.2006 - 16 -...

  • Page 17: I I I I Nstallation For Windows 2000 Nstallation For Windows 2000 Nstallation For Windows 2000

    3. Insert the Software Utility CD provided by the network operator into your CD-ROM drive; or execute the appropriate installation software. 4. iBurst Terminal Setup starts. Click the [Next >] button. 5. Select [I accept the terms the license agreement], click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 17 -...
  • Page 18 To install to a different folder, click [Browse…] and specify another folder. NOTE: 7. Click the [Next >] button. 8. The following dialog window will appear, and installation of software begins. Kyocera Corporation Revision 1.01 --- June.08.2006 - 18 -...
  • Page 19 The iBurst Terminal will be recognized and will be ready to use automatically. If the PC request to restart again, click [Yes] to restart the PC. NOTE: To connect to the Internet, refer to page 67. NOTE: Kyocera Corporation Revision 1.01 --- June.08.2006 - 19 -...

  • Page 20: Installation For Windows Me Installation For Windows Me

    3. Insert the Software Utility CD provided by the network operator into your CD-ROM drive; or execute the appropriate installation software. 4. iBurst Terminal Setup starts. Click the [Next >] button. 5. Select [I accept the terms the license agreement], click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 20 -...
  • Page 21 To install to a different folder, click [Browse…] and specify another folder. NOTE: 7. Click the [Next >] button. 8. The following dialog window will appear, and installation of software begins. Kyocera Corporation Revision 1.01 --- June.08.2006 - 21 -...
  • Page 22 You can see indications of the iBurst Terminal over Ethernet. See page 87 for the method. 11. Connect the iBurst Terminal with your PC through a USB cable. Windows will detect the iBurst Terminal as a new hardware so that [Add New Hardware Wizard] will begin. Kyocera Corporation Revision 1.01 --- June.08.2006 - 22 -...
  • Page 23 13. Select [Search for the best driver for your device.(Recommended)], then check [Specify a location] and click the [Browse] button. 14. Select [C:\Program Files\iBurst Terminal\bin], and click the [OK] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 23 -...
  • Page 24 15. Click the [Next >] button. 16. Confirm that the device name [iBurst Terminal] is displayed in the dialog window, then click the [Next >] button. 17. Click the [Finish] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 24 -...
  • Page 25 NOTE: If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. 19. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Add New Hardware]. 20. Click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 25 -...
  • Page 26 If the dialog window shown below appears, select [No, the device isn’t in the list] NOTE: and click the [Next >] button. 22. Select [No, I want to select the hardware from a list], and click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 26 -...
  • Page 27 Terminal, Desktop Model (UTD) / USB Model (UTU), Manual 23. Select [Ports (COM & LPT)], and click the [Next >] button. 24. Click the [Have Disk..] button. 25. Click the [Browse...] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 27 -...
  • Page 28 You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. 27. Click the [OK] button. 28. Select [iBurst Terminal Virtual COM Port], and click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 28 -...
  • Page 29 31. The dialog window shown below will appear, click the [Yes] button to SHUTDOWN SHUTDOWN SHUTDOWN SHUTDOWN your PC. NOTE: If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. 32. Turn your PC on again. Kyocera Corporation Revision 1.01 --- June.08.2006 - 29 -...
  • Page 30 33. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Modems]. If the dialog window as shown below appears, click the [Add] button. NOTE: Kyocera Corporation Revision 1.01 --- June.08.2006 - 30 -...
  • Page 31 Terminal, Desktop Model (UTD) / USB Model (UTU), Manual 34. Check [Don’t detect my modem; I will select it from a list], and click the [Next >] button. 35. Click the [Have Disk..] button. 36. Click the [Browse…] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 31 -...
  • Page 32 You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. 38. Click the [OK] button. 39. Select [iBurst Terminal Virtual MODEM], and click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 32 -...
  • Page 33 If the dialog window as shown below appears, type a dummy number in “What NOTE: are (or city) code are you in now ?” and then click the [Next >] button. 41. Click the [Finish] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 33 -...
  • Page 34 Terminal, Desktop Model (UTD) / USB Model (UTU), Manual 42. Click the [OK] button. 43. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Network]. Kyocera Corporation Revision 1.01 --- June.08.2006 - 34 -...
  • Page 35 Terminal, Desktop Model (UTD) / USB Model (UTU), Manual 44. Click the [Add…] button on [Configuration] tab. 45. Select [Protocol] and click the [Add…] button. 46. Click the [Have Disk…] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 35 -...
  • Page 36 48. Select [C:\Program Files\iBurst Terminal\bin], and click the [OK] button. You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. 49. Click the [OK] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 36 -...
  • Page 37 Terminal -> iBurst Terminal” must be added automatically. For Ethernet connection with iBurst Terminal, “NDIS(PPPoE) User mode I/O Protocol for iBurst Terminal -> The name of the Ethernet Network Interface Card or Port” shall be added automatically. Kyocera Corporation Revision 1.01 --- June.08.2006 - 37 -...
  • Page 38 52. The dialog window shown below will appear, click the [Yes] button, and restart your PC. If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. NOTE: To connect to the Internet, refer to page 67. NOTE: Kyocera Corporation Revision 1.01 --- June.08.2006 - 38 -...

  • Page 39: Installation For Windows 98Se Installation For Windows 98Se

    3. Insert the Software Utility CD provided by the network operator into your CD-ROM drive; or execute the appropriate installation software. 4. iBurst Terminal Setup starts. Click the [Next >] button. 5. Select [I accept the terms the license agreement], click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 39 -...
  • Page 40 To install to a different folder, click [Browse…] and specify another folder. NOTE: 7. Click the [Next >] button. 8. The following dialog window will appear, and installation of software begins. Kyocera Corporation Revision 1.01 --- June.08.2006 - 40 -...
  • Page 41 You can see indications of the iBurst Terminal over Ethernet. See page 87 for the method. 11. Connect the iBurst Terminal with your PC through a USB cable. Windows will detect the iBurst Terminal as a new hardware so that [Add New Hardware Wizard] will begin. Kyocera Corporation Revision 1.01 --- June.08.2006 - 41 -...
  • Page 42 12. Click the [Next >] button in the dialog window. 13. Select [Search for the best driver for your device.(Recommended)], and then check the [Next >] button. 14. Check [Specify a location] and click the [Browse] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 42 -...
  • Page 43 15. Select [C:\Program Files\iBurst Terminal\bin], and click the [OK] button. 16. Click the [Next >] button. 17. Confirm that the device name [iBurst Terminal] is displayed in the dialog window, then click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 43 -...
  • Page 44 18. Click the [Finish] button. 19. The dialog window shown below will appear, click the [Yes] button, and restart your PC. NOTE: If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. Kyocera Corporation Revision 1.01 --- June.08.2006 - 44 -...
  • Page 45 20. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Add New Hardware]. 21. Click the [Next >] button. 22. Click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 45 -...
  • Page 46 [Next >] button. 23. Select [No, I want to select the hardware from a list.], and click the [Next >] button. 24. Select [Ports (COM & LPT]], and click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 46 -...
  • Page 47 26. Click the [Browse…] button. 27. Select [C:\Program Files\iBurst Terminal\bin], and click the [OK] button. You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. Kyocera Corporation Revision 1.01 --- June.08.2006 - 47 -...
  • Page 48 Terminal, Desktop Model (UTD) / USB Model (UTU), Manual 28. Click the [OK] button. 29. Select [iBurst Terminal Virtual COM Port], and click the [Next >] button. 30. Click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 48 -...
  • Page 49 32. The dialog window shown below will appear, click the [Yes] button to SHUTDOWN SHUTDOWN your PC. SHUTDOWN SHUTDOWN NOTE: If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. Kyocera Corporation Revision 1.01 --- June.08.2006 - 49 -...
  • Page 50 34. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Modems]. If the dialog window as shown below appears, click the [Add] button. NOTE: Kyocera Corporation Revision 1.01 --- June.08.2006 - 50 -...
  • Page 51 35. Select [Other], and click the [Next >] button. 36. Check [Don’t detect my modem, I will select it from a list] and click the [Next >] button. 37. Click the [Have Disk…] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 51 -...
  • Page 52 You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. 40. Click the [OK] button. 41. Select [iBurst Terminal Virtual MODEM], and click the [Next >] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 52 -...
  • Page 53 If the dialog window as shown below appears, type a dummy number in “What NOTE: are (or city) code are you in now ?” and then click the [Next >] button. 43. Click the [Finish] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 53 -...
  • Page 54 Terminal, Desktop Model (UTD) / USB Model (UTU), Manual 44. Click the [OK] button. 45. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Network]. Kyocera Corporation Revision 1.01 --- June.08.2006 - 54 -...
  • Page 55 Terminal, Desktop Model (UTD) / USB Model (UTU), Manual 46. Click the [Add] button on [Configuration] tab. 47. Select [Protocol] and click the [Add…] button. 48. Click the [Have Disk…] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 55 -...
  • Page 56 50. Select [C:\Program Files\iBurst Terminal\bin], and click the [OK] button. You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. 51. Click the [OK] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 56 -...
  • Page 57 For Ethernet connection with iBurst Terminal, “NDIS(PPPoE) User mode I/O Protocol for iBurst Terminal -> The name of the Ethernet Network Interface Card or Port” shall be added in this stage. Kyocera Corporation Revision 1.01 --- June.08.2006 - 57 -...
  • Page 58 54. The dialog window shown below will appear, click the [Yes] button, and shut down your PC, then turn on your PC again. If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. NOTE: To connect to the Internet, refer to page 67. NOTE: Kyocera Corporation Revision 1.01 --- June.08.2006 - 58 -...

  • Page 59: Installation For Mac Os X

    3. Insert the Software Utility CD provided by the network operator into your CD-ROM drive; or execute the appropriate installation software. NOTE: If the window shown below appears, click “Click the lock to make changes”. Kyocera Corporation Revision 1.01 --- June.08.2006 - 59 -...
  • Page 60 Click [Continue] button. 5. In case of version 10.2 or older, “Authenticate” dialog will appear. Enter an administrator name and password, and then click the [OK] button. 6. Click the [Continue] button. Kyocera Corporation Revision 1.01 --- June.08.2006 - 60 -...
