Page 1 Terminal, Desktop Model (UTD) Manual Approved Checked Designed Koyama Yamamoto Hirao Reference: QS13T-EE-001 Revision: 1.02 Date: Feb.17.2009 Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 1 -...
Page 2 Author Date Detail 1.00 Hirao May.10.2006 First Release 1.01 Miyasaka June.08.2006 Correct some writings 1.02 Honma Feb.17.2009 Add FCC Part24 required information AC/DC Adaptor Update The description of UTU is deleted Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 2 -...
Page 3: Table Of Contents
PC hang-up when eject iBurst Terminal from Win98 USB port..............118 Mac ..............................119 Data rate............................119 Chapter 7 Information.................... 120 FCC Compliance Statement......................121 FCC RF Radiation Exposure Statement ..................122 Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 3 -...
Page 4: Safety Precautions On Iburst Terminal
Mac OS X is a registered trademark of Apple Computer, Inc. Windows is a registered trademark of Microsoft Corporation. In addition, the name of the software carried in this document and peripheral equipment is each company’s trademark, or a registered trademark. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 4 -...
Page 5 Do not place things or put cloth on the top of the plug. It may heat and break the plastic and/or the rubber, causing fire or electric shock. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 5 -...
Page 6 Do not use it in the intense place of vibration. It becomes the cause of failure. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 6 -...
Page 7 Both a USB and an Ethernet interface cannot be used simultaneously in case a UTD model. When using UTD model, Please put the antenna at vertical position as shown in the below diagrams so that the unit could acquire proper antenna characteristics. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 7 -...
Page 8: Chapter 1 Introduction
Terminal, Desktop Model (UTD) Manual Chapter 1 Introduction This chapter describes what should be confirmed before using iBurst Terminal. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 8 -...
Page 9: Components List
Cable Length of output side: 2m Power Cable Length: 2m USB Cable Type: USB1.1 Length: 1m 10-Base-T Ethernet Cable Type: Straight through/ Category 5 Length: 2m Pictures of Accessories AC/DC Adapter Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 9 -...
Page 10: Outlook Of Iburst Terminal
Terminal, Desktop Model (UTD) Manual Outlook of iBurst Terminal Antenna Power switch Back side view Power Indicator Link/Communication Indicator USB port PC Connection Indicator 10Base-T port only on UTD model DC Power Input Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 10 -...
Page 11: Indicators
Amber No signal receiving Yellow Weak signal receiving Blinking when communicating. Green Strong signal receiving Blinking when communicating. PC Connection Indicator Any port not active Amber USB port Green 10Base-T port Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 11 -...
Page 12: Requirements On Your Pc
Windows XP or Mac OS X. Please read through every sections related with the operating system for details. USB Connection Back side of UTD USB port USB Cable 10Base-T Ethernet Connection 10Base-T port Category 5 Cable (Straight cable) Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 12 -...
Page 13: Chapter 2 Setup Procedure
Terminal, Desktop Model (UTD) Manual Chapter 2 Setup Procedure This chapter describes how to install iBurst software, then guides you how to make a network connection so as to use data communication service. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 13 -...
Page 14: Iburst Software Installation
3. Insert the Software Utility CD provided by the network operator into your CD-ROM drive; or execute the appropriate installation software. 4. iBurst Terminal Setup starts. Click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 14 -...
Page 15 6. Click the [Next >] button after appearing dialog window as shown below. To install to a different folder, click [Browse…] and specify another folder. NOTE: 7. Click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 15 -...
Page 16 The iBurst Terminal will be recognized and will be ready to use automatically. If the PC request to restart again, click [Yes] to restart the PC. NOTE: To connect to the Internet, refer to page 62. NOTE: Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 16 -...
Page 17: Installation For Windows 2000
3. Insert the Software Utility CD provided by the network operator into your CD-ROM drive; or execute the appropriate installation software. 4. iBurst Terminal Setup starts. Click the [Next >] button. 5. Select [I accept the terms the license agreement], click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 17 -...
Page 18 To install to a different folder, click [Browse…] and specify another folder. NOTE: 7. Click the [Next >] button. 8. The following dialog window will appear, and installation of software begins. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 18 -...
Page 19 The iBurst Terminal will be recognized and will be ready to use automatically. If the PC request to restart again, click [Yes] to restart the PC. NOTE: To connect to the Internet, refer to page 67. NOTE: Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 19 -...
Page 20: Installation For Windows Me
3. Insert the Software Utility CD provided by the network operator into your CD-ROM drive; or execute the appropriate installation software. 4. iBurst Terminal Setup starts. Click the [Next >] button. 5. Select [I accept the terms the license agreement], click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 20 -...
Page 21 To install to a different folder, click [Browse…] and specify another folder. NOTE: 7. Click the [Next >] button. 8. The following dialog window will appear, and installation of software begins. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 21 -...
Page 22 You can see indications of the iBurst Terminal over Ethernet. See page 87 for the method. 11. Connect the iBurst Terminal with your PC through a USB cable. Windows will detect the iBurst Terminal as a new hardware so that [Add New Hardware Wizard] will begin. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 22 -...
Page 23 13. Select [Search for the best driver for your device.(Recommended)], then check [Specify a location] and click the [Browse] button. 14. Select [C:\Program Files\iBurst Terminal\bin], and click the [OK] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 23 -...
Page 24 15. Click the [Next >] button. 16. Confirm that the device name [iBurst Terminal] is displayed in the dialog window, then click the [Next >] button. 17. Click the [Finish] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 24 -...
Page 25 NOTE: If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. 19. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Add New Hardware]. 20. Click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 25 -...
Page 26 If the dialog window shown below appears, select [No, the device isn’t in the list] NOTE: and click the [Next >] button. 22. Select [No, I want to select the hardware from a list], and click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 26 -...
Page 27 Terminal, Desktop Model (UTD) Manual 23. Select [Ports (COM & LPT)], and click the [Next >] button. 24. Click the [Have Disk..] button. 25. Click the [Browse...] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 27 -...
Page 28 You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. 27. Click the [OK] button. 28. Select [iBurst Terminal Virtual COM Port], and click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 28 -...
Page 29 31. The dialog window shown below will appear, click the [Yes] button to SHUTDOWN your PC. NOTE: If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. 32. Turn your PC on again. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 29 -...
Page 30 33. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Modems]. If the dialog window as shown below appears, click the [Add] button. NOTE: Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 30 -...
Page 31 Terminal, Desktop Model (UTD) Manual 34. Check [Don’t detect my modem; I will select it from a list], and click the [Next >] button. 35. Click the [Have Disk..] button. 36. Click the [Browse…] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 31 -...
Page 32 You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. 38. Click the [OK] button. 39. Select [iBurst Terminal Virtual MODEM], and click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 32 -...
Page 33 If the dialog window as shown below appears, type a dummy number in “What NOTE: are (or city) code are you in now ?” and then click the [Next >] button. 41. Click the [Finish] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 33 -...
Page 34 Terminal, Desktop Model (UTD) Manual 42. Click the [OK] button. 43. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Network]. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 34 -...
Page 35 Terminal, Desktop Model (UTD) Manual 44. Click the [Add…] button on [Configuration] tab. 45. Select [Protocol] and click the [Add…] button. 46. Click the [Have Disk…] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 35 -...
Page 36 48. Select [C:\Program Files\iBurst Terminal\bin], and click the [OK] button. You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. 49. Click the [OK] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 36 -...
Page 37 Terminal -> iBurst Terminal” must be added automatically. For Ethernet connection with iBurst Terminal, “NDIS(PPPoE) User mode I/O Protocol for iBurst Terminal -> The name of the Ethernet Network Interface Card or Port” shall be added automatically. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 37 -...
Page 38 52. The dialog window shown below will appear, click the [Yes] button, and restart your PC. If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. NOTE: To connect to the Internet, refer to page 67. NOTE: Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 38 -...
Page 39: Installation For Windows 98Se
3. Insert the Software Utility CD provided by the network operator into your CD-ROM drive; or execute the appropriate installation software. 4. iBurst Terminal Setup starts. Click the [Next >] button. 5. Select [I accept the terms the license agreement], click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 39 -...
Page 40 To install to a different folder, click [Browse…] and specify another folder. NOTE: 7. Click the [Next >] button. 8. The following dialog window will appear, and installation of software begins. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 40 -...
Page 41 You can see indications of the iBurst Terminal over Ethernet. See page 87 for the method. 11. Connect the iBurst Terminal with your PC through a USB cable. Windows will detect the iBurst Terminal as a new hardware so that [Add New Hardware Wizard] will begin. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 41 -...
Page 42 12. Click the [Next >] button in the dialog window. 13. Select [Search for the best driver for your device.(Recommended)], and then check the [Next >] button. 14. Check [Specify a location] and click the [Browse] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 42 -...
Page 43 15. Select [C:\Program Files\iBurst Terminal\bin], and click the [OK] button. 16. Click the [Next >] button. 17. Confirm that the device name [iBurst Terminal] is displayed in the dialog window, then click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 43 -...
Page 44 18. Click the [Finish] button. 19. The dialog window shown below will appear, click the [Yes] button, and restart your PC. NOTE: If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 44 -...
Page 45 20. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Add New Hardware]. 21. Click the [Next >] button. 22. Click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 45 -...
Page 46 [Next >] button. 23. Select [No, I want to select the hardware from a list.], and click the [Next >] button. 24. Select [Ports (COM & LPT]], and click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 46 -...
Page 47 26. Click the [Browse…] button. 27. Select [C:\Program Files\iBurst Terminal\bin], and click the [OK] button. You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 47 -...
Page 48 Terminal, Desktop Model (UTD) Manual 28. Click the [OK] button. 29. Select [iBurst Terminal Virtual COM Port], and click the [Next >] button. 30. Click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 48 -...
Page 49 31. Click the [Finish] button. 32. The dialog window shown below will appear, click the [Yes] button to SHUTDOWN your PC. NOTE: If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 49 -...
Page 50 34. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Modems]. If the dialog window as shown below appears, click the [Add] button. NOTE: Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 50 -...
Page 51 35. Select [Other], and click the [Next >] button. 36. Check [Don’t detect my modem, I will select it from a list] and click the [Next >] button. 37. Click the [Have Disk…] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 51 -...
Page 52 You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. 40. Click the [OK] button. 41. Select [iBurst Terminal Virtual MODEM], and click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 52 -...
Page 53 If the dialog window as shown below appears, type a dummy number in “What NOTE: are (or city) code are you in now ?” and then click the [Next >] button. 43. Click the [Finish] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 53 -...
Page 54 Terminal, Desktop Model (UTD) Manual 44. Click the [OK] button. 45. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Network]. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 54 -...
Page 55 Terminal, Desktop Model (UTD) Manual 46. Click the [Add] button on [Configuration] tab. 47. Select [Protocol] and click the [Add…] button. 48. Click the [Have Disk…] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 55 -...
Page 56 50. Select [C:\Program Files\iBurst Terminal\bin], and click the [OK] button. You don’t have to select a file name. Windows will find an appropriate file NOTE: automatically. 51. Click the [OK] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 56 -...
Page 57 For Ethernet connection with iBurst Terminal, “NDIS(PPPoE) User mode I/O Protocol for iBurst Terminal -> The name of the Ethernet Network Interface Card or Port” shall be added in this stage. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 57 -...
Page 58 54. The dialog window shown below will appear, click the [Yes] button, and shut down your PC, then turn on your PC again. If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. NOTE: To connect to the Internet, refer to page 67. NOTE: Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 58 -...
Page 59: Installation For Mac Os X
3. Insert the Software Utility CD provided by the network operator into your CD-ROM drive; or execute the appropriate installation software. NOTE: If the window shown below appears, click “Click the lock to make changes”. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 59 -...
Page 60 Click [Continue] button. 5. In case of version 10.2 or older, “Authenticate” dialog will appear. Enter an administrator name and password, and then click the [OK] button. 6. Click the [Continue] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 60 -...
Page 61 Terminal, Desktop Model (UTD) Manual 7. Click the [Continue] button. 8. The following dialog will appear, click the [Agree] button. 9. Select a destination disk, and then click the [Continue] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 61 -...
Page 62 NOTE: In case of version 10.4, Authentication dialog will appear at here. 11. Click the [Continue installation] button. 12. When finish installing, the dialog shown below will appear. Click the [Restart] button. To connect to the Internet, refer to page 69. NOTE: Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 62 -...
Page 63: Connection Establishment
2. Click the [Start] button, followed by selecting [Control Panel] as shown below. 3. Click [Network and Internet Connections] in the [Control Panel] display. 4. Next, click [Set up or Change your Internet connection]. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 63 -...
Page 64 6. [New Connection Wizard] will begin and the dialog window as shown below will appear. Click the [Next >] button in the dialog window. 7. Select [Connect to the Internet] and click the [Next >] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 64 -...
Page 65 10. Fill in [ISP Name] edit box with an ISP Name, followed by clicking the [Next >] button. Note that any ISP name is acceptable. ISP Name is “iBurst” for example. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 65 -...
Page 66 Nothing in case SP2 of Windows XP. 12. Click the [Finish] button. Check it if you want. 13. When the [Network and Internet Connection] window pane appears again, click [Set up change your Internet Connection]. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 66 -...
Page 67 Internet. 16. When the connection establishment process is complete, a message indicating completion of the connection will appear at the task tray as shown below. iBurst Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 67 -...
Page 68: Connection Establishment For Windows 2000/Me/98Se
“iBurst Terminal” shall be selected. In case of Ethernet connection: “Ethernet Adaptor Name” shall be selected. ‘Cancel’ to close the dialog. NOTE: ‘Property’ to open properties of the dial-up connection for iBurst Terminal. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 68 -...
Page 69 Terminal, Desktop Model (UTD) Manual 4. While connecting to network, the following connection status window is displayed. 5. When logging on successfully, a network connection icon will be displayed at the task tray. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 69 -...
Page 70: Connection Establishment For Mac Os X
3. Click [Network] in the [System Preferences] window. 4. After the 1st connection with the iBurst Terminal via USB cable, you will find the pop-up shown below. Take note the name of the new port. Click [OK]. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 70 -...
Page 71 Check [Save password] If you require the computer to remember your password. Check [Show PPPoE status in menu bar]. NOTE: If uncheck this option, you cannot see the icon described in the step 9. And then, click [PPPoE Options…] Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 71 -...
Page 72 7. Click the [Apply Now] button. 8. At this point, the connection configuration is completed. When you open any internet application software, e.g. a web browser, the internet connectivity will be activated automatically. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 72 -...
Page 73 11. When the box [Show PPPoE status in menu bar] is checked, PPPoE Status [Connected] will be displayed after having finished connection. However, Ethernet Adaptor display will little differ by OS Version. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 73 -...
Page 74: Chapter 3 Utility Software
Terminal, Desktop Model (UTD) Manual Chapter 3 Utility Software This chapter describes the features and usage of the Utility Software for iBurst Terminal. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 74 -...
Page 75: Using Utility Software
[Link Info] pane will be displayed as shown below. 2. To close the utility dialog window, click the [OK] button or the [Cancel] button or the ‘X’ button at upper-right corner of the dialog window. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 75 -...
Page 76 (3) Link Speed This indicates current bandwidth allocated automatically between the iBurst Terminal and a radio base station. (4) Frame Error Rate This indicates current Frame Error Rate on the downlink air. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 76 -...
Page 77 Total Byte Received indicates the total number of bytes received from the access point since the communication link is established. (8) Total Byte Sent Total Byte Sent indicates the total number of bytes transmitted to the access point since the communication link is established. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 77 -...
Page 78 [Apply] button activates every setting above. [Reset] button enables and activates all settings above. [OK] button activates every setting above and close the dialog. [Cancel] button closes the dialog without activation of the settings. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 78 -...
Page 79 (1) This shows the version number and the build date of this Utility Software. (2) This shows the firmware version and the build date of the iBurst Terminal. (3) This shows the hardware version and the manufactured date of the iBurst Terminal. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 79 -...
Page 80 Pointing on the iBurst icon on the task tray, a baloon indicates Link Status, Total Byte Received, Total Byte Sent and Signal Strength as shown below, but depending on the settings on the [Setup] pane. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 80 -...
Page 81: Using Utility Software For Mac Os X
Using Utility Software for Mac OS X To open the utility dialog. 1. Click the iBurst Terminal UTL icon on the Dock. 2. The iBurst_Terminal UTL dialog appears as shown in next page. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 81 -...
Page 82 (3) Link Speed This indicates current bandwidth allocated automatically between the iBurst Terminal and a radio base station. (4) Frame Error Rate This indicates current Frame Error Rate on the downlink air. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 82 -...
Page 83 Total Byte Received indicates the total number of bytes received from the access point since the communication link is established. (8) Total Byte Sent Total Byte Sent indicates the total number of bytes transmitted to the access point since the communication link is established. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 83 -...
Page 84 All are [ON] as the default. Selecting [OFF] disables the corresponding indicator on the Link Info pane. [Apply] button activates every setting above. [Reset] button enables and activates all settings above. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 84 -...
Page 85 (1) This shows the version number and the build date of this Utility Software. (2) This shows the firmware version and the build date of the iBurst Terminal. (3) This shows the hardware version and the manufactured date of the iBurst Terminal. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 85 -...
Page 86 The menu is used to control enabling/disabling to show each indication on the [Link Info] pane. The function is the same as the [Setup] pane of the dialog. (3) Help menu The [Help] window will appear when help menu is selected. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 86 -...
Page 87 Terminal is connected with your PC,and Signal Strength is Fair. iBurst Terminal is connected with your PC,and Signal Strength is Good. iBurst Terminal is connected with your PC,and Signal Strength is Excellent. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 87 -...
Page 88: Status Indication Over Ethernet
Terminal and your PC, the settings shown below are recommended as an example. IP address: 192.168.250.1 Subnet mask: 255.255.255.0 Default gateway: (blank) 8) Click “OK” to close the TCP/IP properties. 9) Click “OK” to close the connection properties. 10) Close “Network Connections” window. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 88 -...
Page 89 Terminal and your PC, the settings shown below are recommended as an example. IP address: 192.168.250.1 Subnet mask: 255.255.255.0 Default gateway: (blank) 5) Click “OK” to close the TCP/IP properties. 6) Click “OK” to close “Network” dialog. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 89 -...
Page 90 IP address you changed. Now, you are seeing information in the iBurst Terminal. The structure of the information pages is as follows. IP Address Setting Jump Link Information Link Information Configuration Help Help Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 90 -...
Page 91 This page shows current IP address of the iBurst Terminal. You can change the IP address on this page. To change it, type new IP address and click “Submit” button. The page shown below will be shown. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 91 -...
Page 92 ** All information will be updated every 5 seconds. [Configuration] This page indicates similar information described in page 78 of iBurst Terminal utility software. [Help] This navigates you to see the web pages. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 92 -...
Page 93: Chapter 4 Mtu Optimizer Software & Network Property
Terminal, Desktop Model (UTD) Manual Chapter 4 MTU Optimizer Software & Network Property This chapter describes the features and usage of the MTU Optimizer Software for iBurst Terminal. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 93 -...
Page 94: Mtu Optimizer Software & Network Property
MTU size in order to avoid any throughput problem. This function is a part of Kyocera PPPoE dialer and it is available on Windows 98SE, ME and 2000. You need to make a Internet connection through the iBurst Terminal prior to NOTE: start this procedure.
Page 95 A) type a target URL or an IP address of the HOST, which will be notified by the network operator, and click the [Start] button. B) The optimizer starts measuring and every value will be varied automatically. XXX.XXX.XXX.XXX NOTE: ‘Cancel’ to stop measuring. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 95 -...
Page 96 NOTE: ‘Monitor’ to revoke the result and show the current memorized MTU size. 7. Click [Close] to close the dialog. 8. If you updated, you need to restart your PC to take effect. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 96 -...
Page 97: Chapter 5 Uninstallation
Terminal, Desktop Model (UTD) Manual Chapter 5 Uninstallation This chapter describes how to uninstall iBurst software. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 97 -...
Page 98: Ibusrt Software Uninstallation
3. Click the [Start] button, followed by selecting [Control Panel] to open Control Panel, and then double click [Add or Remove Programs]. 4. Select [iBurst Terminal] software, and click the [Remove] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 98 -...
Page 99 6. The following dialog window will appear, and select to delete or not to delete installation history files before uninstallation, then click the [Next >] button. Selecting “Yes” is recommended. 7. The following dialog window will appear, and uninstallation of software begins. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 99 -...
Page 100 Terminal, Desktop Model (UTD) Manual 8. Click the [Finish] button after appearing dialog window as shown below. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 100 -...
Page 101: Uninstallation For Windows Me/98Se
3. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Add/Remove Programs]. 4. Select [iBurst Terminal] software,and click the [Add/Remove] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 101 -...
Page 102 6. The following dialog window will appear, and select to delete or not to delete installation history files before uninstallation, then click the [Next >] button. Selecting “Yes” is recommended. 7. The following dialog window will appear, and uninstallation of software begins. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 102 -...
Page 103 NOTE: In case that the uninstaller shows a selection of restarting your PC, it is recommended to restart it. 9. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [System]. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 103 -...
Page 104 10. Select [iBurst Terminal Virtual MODEM] on [Device Manager] tab, then click the [Remove] button. 11. Click the [OK] button. NOTE: In case Windows 98 SE, no selection is on the dialog. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 104 -...
Page 105 The ‘X’ in “COM x” above is a COM port number assigned automatically. NOTE: 13. Click the [OK] button. NOTE: “COM3” in the picture below is an example. NOTE: In case Windows 98 SE, no selection is on the dialog. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 105 -...
Page 106 Terminal, Desktop Model (UTD) Manual 14. Click the [Close] button. 15. Click the [Start] -> [Settings] -> [Control Panel] to open Control Panel as shown below, and then double click [Network]. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 106 -...
Page 107 17. Click the [OK] button to close Network dialog. 18. The dialog window shown below will appear, click the [Yes] button, and restart your PC. NOTE: If the PC doesn’t shutdown itself, try to press Alt+Ctrl+Del keys several times. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 107 -...
Page 108: Uninstallation For Mac Os X
2. Disconnect the iBurst Terminal with your PC. 3. Open the folder [Applications\iBurst Terminal\Uninstall], then double click the script file [uninst_iburst_terminal.command]. 4. The terminal window shown below will appear, Type administrator’s [password] and press [Enter] key. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 108 -...
Page 109 6. Press [y] and [Enter] key to restart your computer. Don’t change any properties of MAC Terminal while ATTENTION uninstallation. Otherwise you would have a problem on uninstalling of iBurst Terminal software. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 109 -...
Page 110: Chapter 6 Trouble Shooting
Terminal, Desktop Model (UTD) Manual Chapter 6 Trouble shooting This chapter describes how to solve the trouble when you use iBurst. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 110 -...
Page 111: Windows
USB connection. If you find this phenomenon, you can avoid it by following procedure. 1. Open Network property [Start] -> [Settings] -> [Control Panel] -> [Network]. 2. Select the [TCP/IP->iBurst Terminal] component, then click the [Properties] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 111 -...
Page 112 Terminal, Desktop Model (UTD) Manual 3. Open the [IP Address] tab. 4. Select the [Specify an IP address] then type a private IP address (for example: 192.168.250.11) and type 255.255.255.0 on Subnet Mask. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 112 -...
Page 113 Terminal, Desktop Model (UTD) Manual 5. Click the [OK] button. 6. Click the [Yes] button, and restart your PC. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 113 -...
Page 114: Illegal Hang-Up When Install Iburst Terminal
1. Open Network property [Start] -> [Settings] -> [Control Panel] -> [System]. 2. Select [Device Manager] tab. Disable sound card device and other which will not effect for Windows performance, i.e. network card and modem. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 114 -...
Page 115 [OK] button. 4. Connect iBurst Terminal to USB port. 5. On the [General] tab, uncheck the box labeled the [Disable in this hardware profile], and then click the [OK] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 115 -...
Page 116: Illegal Hang-Up When Set Up Dialer
1. Open Device Manager [Start] -> [Settings] -> [Control Panel] -> [System] -> [Device Manager]. 2. Disable sound card device and other which will not effect for Windows performance, ie network card and modem. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 116 -...
Page 117 4. Re-install iBurst Terminal Virtual COM Port driver according to installation procedure, chapter 2 "Installation for Windows 98SE" step 20. 5. On the [General] tab, uncheck the box labeled the [Disable in this hardware profile], and then click the [OK] button. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 117 -...
Page 118: Pc Hang-Up When Eject Iburst Terminal From Win98 Usb Port
PC running. In this case, please don’t eject iBurst Terminal from USB port during PC running. You should eject iBurst Terminal from USB port after you shutdown your PC. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 118 -...
Page 119: Mac
Terminal would not perform maximum data rate when it connects with Mac PC. This is obviously caused by Mac OS. And typical data rate connecting with Mac is 800Kbps at downlink and 240Kbps at uplink. Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 119 -...
Page 120: Chapter 7 Information
Terminal, Desktop Model (UTD) Manual Chapter 7 Information Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 120 -...
Page 121: Fcc Compliance Statement
OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and operated with at least 20cm and more between the radiator and person s body (excluding extremities: hands, wrists, feet and ankles). Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 121 -...
Page 122: Fcc Rf Radiation Exposure Statement
FCC radiation exposure limits set forth for an uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. [The end of this manual] Kyocera Corporation Revision 1.02 --- Feb.17.2009 - 122 -...
