Snapper 19E01 Parts Manual page 7

HANDLES, DECK, MOTOR, & WHEELS
Item Part No Qty
39 7090799 3
40 7011791 3
41 7090188 3
42 7090851 3
43 7090187 2
44 7091511 2
45 7090541 3
46 7090053 3
47 7090095 3
48 7090233 3
49 7090480 3
50 -- 2
51 7090894 2
52 7015114 2
Footnotes:
*NOTE: Purchase engine components directly from engine manufacturer dealer.
Available through Briggs & Stratton
19" 120 VOLT ELECTRIC
SERIES 1
Description
BOLT, 5/16-18 x 5/8" Short Neck Carriage
RETAINER, 5/16 Bolt
WASHER, 5/16 Flat
HTLN, NYLON, 5/16C ZP
SLW, .318X.583X.078 ZP
HN, 5/16C GR5 YZ
SCREW, 1/4-28 x 3/4" Hex Cap
WASHER, 1/4 Internal Tooth
NUT, 1/4-28 Hex
SCREW, 5/16-24 x 3/4" Hex Cap
NUT, 5/16-24 Hex Flange Lock
NUT, #10-24 Hex
SCREW, #10-24 x 1-3/8" Slotted Cap
INSULATOR, Handle
7
Note
Was 90196
Not available from Snapper,
check B&S engine manual.
Manual No. 7015175
TP 400-5108-1-WB-N
