- Page 1 COPYRIGHT © 2005 SNAPPER PRODUCTS, INC. ALL RIGHTS RESERVED. Parts Manual for 19" 120 VOLT ELECTRIC WALK BEHIND MOWERS McDonough, GA, 30253 U.S.A. Revision 1, 9/16/2005 SERIES 7 MODEL 19E07B LWE07B Manual No. 7006112 TP 400-5098-1-WB-N...
- Page 3 PAGE GROUP Upper, Middle & Lower Handles Deck, Wheels, & Motor Grass Bag, Adapter & Decals 19" 120 VOLT ELECTRIC SERIES 7 Table Of Contents Manual No. 7006112 TP 400-5098-1-WB-N...
- Page 4 Upper, Middle & Lower Handles Manual No. 7006112 19" 120 VOLT ELECTRIC TP 400-5098-1-WB-N SERIES 7...
- Page 5 Upper, Middle & Lower Handles Item Part No Description 7051884 ASSEMBLY Upper Handle 7014903 TUBING, Heat Shrink CONTROL, Electric 7014879 DECAL, Starting Procedure 7014907 DECAL, Circuit Breaker Reset 7014894 STRAIN-RELIEF, Harness 7015114 INSULATOR, Handle 7090894 SCREW, #10-24 x 1-3/8" Slotted Cap 7012080 TIE, Cable 7036350...
- Page 6 Deck, Wheels, & Motor Manual No. 7006112 19" 120 VOLT ELECTRIC TP 400-5098-1-WB-N SERIES 7...
- Page 7 SCREW, 5/16-24 x 3/4" Hex Cap 7090480 NUT, 5/16-24 Hex Flange Lock 14895 NUT, #10-24 Hex 7044640 NAME PLATE, SNAPPER Footnotes: *NOTE: Purchase engine components directly from engine manufacturer dealer. Available through Briggs & Stratton 19" 120 VOLT ELECTRIC SERIES 7...
- Page 8 Grass Bag, Adapter & Decals Manual No. 7006112 19" 120 VOLT ELECTRIC TP 400-5098-1-WB-N SERIES 7...
- Page 9 Grass Bag, Adapter & Decals Item Part No Description 7059322 KIT, Grass Bag Catcher 7061918 KIT, Grass Bag Catcher 7059322 ASSEMBLY, Grass Bag 7017069 BAG, Door Type 7051906 ASSEMBLY, Bag Wire 7042489 CONNECTOR, Grass Bag 7053681 ADAPTER, Grass Bag 7014808 DECAL, Warning 7015263 DECAL, CPSC Warning...
- Page 12 19" 120 VOLT ELECTRIC WALK BEHIND MOWERS SERIES 7 IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
