- Page 1 SPIDER LASER USER MANUAL Please read this manual carefully before use!
- Page 2 SPIDER LASER USER MANUAL Contents Introduction and caution-------------------------------------------------------- P2 Symbol Instruction On The Device ----------------------------------------- P3 Safety instruction and product specification----------------------------- P4 Display menu operation & function------------------------------------------P5 DMX512 channel table-----------------------------------------------------------P6-7 DMX connection---------------------------------------------------------------------P8 Rigging and product dimension-----------------------------------------------P9 Cleaning & maintenance, warranty card---------------------------------P10...
- Page 3 SPIDER LASER USER MANUAL Introduction Thank you for your patronage. We are confident that our excellent products and service can satisfy you. For your own safety, please read this user manual carefully before installing the device. In order to install , operate, and maintain the lighting safety and correctly. We suggest that the installation and operation should be done by the verified technician and follow the instruction strictly.
- Page 4 SPIDER LASER USER MANUAL Symbol Instruction On The Device --------------------------------------------------------------------------------- CE compliant --------------------------------------------------------------------------- Only indoor using ------------------------------------------------------------------------------- RoHS certificate ------------------------------ The minimum distance from lighted objects (meter) ------------------------------------------------------------------ Max ambient Temp --------------------------------------------------------------- Max housing Temp ------------------------------------------------------------------------------- Safety caution ------------------------------------------------------------------------- Be careful of burn...
-
Page 5: Safety Instructions
SPIDER LASER USER MANUAL ---- Do not install directly on the surface of ordinary combustible materials 1. Safety Instructions Please open and check whether break or not for transport once receive this fixture, if yes, don ‘t use it and contact dealer or manufacture as soon as possible. - Page 6 SPIDER LASER USER MANUAL 2. Fuse：BGDP ￠5x20mm 250VAC T2A 3. Power consumption:70W 4. Control mode: auto/sound/DMX512/Master-slave 5. DMX channels：12/16CH 6. Scanning：step motor 7. Working temperature:10℃~40℃ 8. Storage temperature: 1℃~40℃ 9. Modulation: TTL 10. Inner box size:73 *30*24cm 11. Master carton size:75*32*52cm (2pcs/carton) 12.
-
Page 7: Dmx Channel Table
SPIDER LASER USER MANUAL Inv 2: ON/OFF Corr Cor 1: 0-254 correction Cor 2: 0-254 correction Deft Yes (default) Rest Yes (reset) Version Software version : Ver 1.0 6、DMX channel table 12DMX channels Channel Value Function Motor A 0-255 motor A position choose... - Page 8 SPIDER LASER USER MANUAL 16 DMX channel table Channel Value Function 0-127 DMX mode Mode choose 128-255 Sound activated mode Motor A 0-255 motor A position choose Motor A 2-255 motor A speed (slow to fast) Motor B 0-255 motor B position choose...
- Page 9 SPIDER LASER USER MANUAL 0-127 Laser B-3 OFF CH15 Laser B-3 128-255 Laser B-3 ON 0-127 Laser B-4 OFF CH16 Laser B-4 128-255 Laser B-4 ON 7. DMX-512 control connection Connect the provided XLR cable to the male 3-pin XLR output of your controller and the other side to the female 3-pin XLR input of the light.You can chain multiple lights together through serial linking,...
- Page 10 SPIDER LASER USER MANUAL Welding a 120 ohm resistor between 2 and 3 pins male XLR , and insert it into the signal output of the last device 9. Rigging: ►The applicable temperature for the fixture is between -25°C to 45°C. Do not use the lighting under or above this temperature range.
-
Page 11: Cleaning And Maintenance
SPIDER LASER USER MANUAL 9. Cleaning and maintenance Cleaning should be performed every 15-day period, by using a sponge which is dipped with alcohol, rather than wet cloth or other chemical liquid, to clean the mirror. CAUTION Cut off power before cleaning and maintenance! - Page 12 SPIDER LASER USER MANUAL We will provide 1 year warranty under the condition that user has operated the light normally and lifetime service. We won't provide warranty if the damage is caused by artificial or force majeasure event. Please cut this warranty card and shipped it along with the product to our factory when applying for warranty.
